▶ EngineEngine Manufacturer LS Mtron FPT Engine Model L4C25-T S8000 Engine Type In-line vertical, water cooled 4-cycle diesel, CRDI 3-cylinder, Tier 4 B/Final, FPT turbocharged & aftercooled No. of Cylinders 4 3 Displacement 152.85 in³ 178.8 in³ Rated Engine Speed 2500 rpm 2300 rpm Engine Power (Gross) 63 hp 64 hp PTO Power 54.1 hp 50 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Not Published Not Published Fuel System Not Published Electronic high pressure common rail Alternator 70 A, 12 V 120 A ▶ HydraulicsPump Type Not Published Fixed displacement Implement Flow 14.5 gpm 12.6 gpm Steering Flow 6.6 gpm Not Published Total Hydraulic Flow 21.1 gpm 12.6 gpm Overall Hydraulic Pump Flow 21.1 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 Pairs (Front), 2 Pairs (Rear) 2 No. of Optional Remote Valves Not Published 3 ▶ Fluid CapacityFuel Tank Capacity 24.3 gal 21.7 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 / 540E 540 (standard); 540/540E (optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category I/II Hitch Lift Capacity Not Published 5,952 lb (optional hitch 6,614 lb) Hitch Lift Capacity (at 24”) 3,483 lb 4,300 lb (optional hitch 4,740 lb) Lift Control Type Position & Draft Mechanical Draft Control (MDC), top link sensing ▶ Transmission & DrivetrainTransmission Type Electro Power Shuttle MFD: 12x12 power shuttle (wet clutch); 2WD: 8x8 mechanical shuttle (dry clutch); optional 12x12 mechanical shuttle (dry clutch) or 12x12 with creeper (20x20) No. of Speeds F16 x R16 MFD: 12F/12R; 2WD: 8F/8R; optional 12F/12R mechanical or 20F/20R creeper Max Travel Speed (Forward) Not Published 18.6 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published MFD: wet clutch (12x12 power shuttle); 2WD: dry clutch (8x8 mechanical shuttle) Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Mechanical rear differential lock; MFD engagement electrohydraulic; limited-slip MFD front axle ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power Steering Hydrostatic Brakes Wet, Multi-disc Wet disc Seat Suspension & Adjustability Not Published Mechanical contoured seat, adjustable; optional air-suspension seat Front Axle Type Not Published 2WD or MFD with limited slip Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 72.6 in Not Published Wheelbase 83.1 in 2WD: 82.1 in; MFD: 83.6 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Applicable Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 105.4 in 2WD: 98 in; MFD: 100 in Overall Length 140 in (bumper to link) 155.3 in ▶ WeightTractor Weight (Base) 5,776 lb 2WD Cab: 6,173 lb; MFD Cab: 6,834 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader 6,966 lb (5,776 + 1,190, computed) Not Published ▶ Tire OptionsTire Size & Options Standard Ag 9.5-24 / 16.9-28; Industrial 10.5/80x18 10PR / 19.5Lx24 8PR; Large Ag 11.2-24 / 16.9-30; R14 320/85R20 119D / 420/75R34 142D R-1 (ag tread) bias ply standard; optional R-1W (ag tread) radial R1 Agricultural - Front 9.5-24 (Standard Ag); 11.2-24 (Large Ag) 2WD: 9.5L-15; MFD: 11.2x24 R1 Agricultural - Rear 16.9-28 (Standard Ag); 16.9-30 (Large Ag) 2WD: 16.9R28; MFD: 16.9x30 (optional 16.9R28) R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 10.5/80x18 10PR Not Published R4 Industrial - Rear 19.5Lx24 8PR Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model LL5001 L610 Loader Lift Height LL5001: 132.9 in (height position); 116.8 in (power position) 120 in Loader Lift Capacity (Full Height) LL5001: 3,426 lb (height position, at pivot pin, max height); 3,488 lb (power position, at pivot pin, max height) NSL: 1,828 lb; MSL: 3,153 lb Loader Breakout Force Not Published Not Published ▶ WarrantyWarranty Length & Coverage Basic 2 years or 750 hours; powertrain 6 years or 1,500 hours Not Published
