▶ EngineEngine Manufacturer LS Mtron Kubota Engine Model L4C25-T V2403-CR-E4-GL5 Engine Type In-line vertical, water cooled 4-cycle diesel, CRDI Liquid-cooled, 4-cycle multi valve, diesel, Turbocharged No. of Cylinders 4 4 Displacement 152.85 in³ 148.5 in³ Rated Engine Speed 2500 rpm 2600 rpm Engine Power (Gross) 63 hp 62 hp PTO Power 54.1 hp 53 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Not Published Dry paper, dual element Fuel System Not Published Electronic Common Rail System (CRS) Alternator 70 A, 12 V 45 A, 12 V ▶ HydraulicsPump Type Not Published Tandem pump - gear type Implement Flow 14.5 gpm 9.4 gpm Steering Flow 6.6 gpm 4.7 gpm Total Hydraulic Flow 21.1 gpm 14.1 gpm Overall Hydraulic Pump Flow 21.1 gpm 14.1 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 Pairs (Front), 2 Pairs (Rear) Not Published No. of Optional Remote Valves Not Published Optional, up to 3: double-acting valve or float detent valve, any position ▶ Fluid CapacityFuel Tank Capacity 24.3 gal 13.5 gal Coolant Capacity Not Published 8.7 qt Crankcase Capacity Not Published 9.9 qt Transmission / Hydraulic System Capacity Not Published 11.9 gal Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Live independent (hydraulic clutch) PTO Rear 540 / 540E 540 rpm @ 2400 engine rpm Mid-PTO Availability Not Published Optional Category, 3-Point Hitch Category II SAE Category I & II Hitch Lift Capacity Not Published 3,858 lb Hitch Lift Capacity (at 24”) 3,483 lb 2,976 lb Lift Control Type Position & Draft Position control ▶ Transmission & DrivetrainTransmission Type Electro Power Shuttle Hydrostatic transmission No. of Speeds F16 x R16 3-range, 6 speeds (H-DS), infinitely variable in each Max Travel Speed (Forward) Not Published 16.8 mph Max Travel Speed (Reverse) Not Published 15.2 mph Clutch Not Published Not Published Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Rear differential lock, standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power Steering Hydrostatic power steering Brakes Wet, Multi-disc Wet disc type, mechanically activated Seat Suspension & Adjustability Not Published Suspension seat with swivel function Front Axle Type Not Published 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,433 lb ▶ Dimensions & ManeuverabilityOverall Width 72.6 in 67.3 in Wheelbase 83.1 in 75.4 in Ground Clearance Not Published 15.4 in Min. Turn Radius without Brakes Not Published 9.2 ft (with brake applied) Height to Top of ROPS Not Published 98.0 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 105.4 in Not Applicable Overall Length 140 in (bumper to link) 135.0 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 5,776 lb 3,990 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader 6,966 lb (5,776 + 1,190, computed) Not Published ▶ Tire OptionsTire Size & Options Standard Ag 9.5-24 / 16.9-28; Industrial 10.5/80x18 10PR / 19.5Lx24 8PR; Large Ag 11.2-24 / 16.9-30; R14 320/85R20 119D / 420/75R34 142D Standard R1 (9.5-16 / 14.9-26); options: R1 (9.5-16 / 13.6-28), R4 (10-16.5 / 17.5L-24), R3 (29x12.50-15 / 44x18-20), LSW R3 (LSW305R343 / LSW610R470) R1 Agricultural - Front 9.5-24 (Standard Ag); 11.2-24 (Large Ag) 9.5-16 R1 Agricultural - Rear 16.9-28 (Standard Ag); 16.9-30 (Large Ag) 14.9-26; 13.6-28 R3 Turf - Front Not Published 29X12.50-15 R3 Turf - Rear Not Published 44X18-20 R4 Industrial - Front 10.5/80x18 10PR 10-16.5 R4 Industrial - Rear 19.5Lx24 8PR 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) Loader Model LL5001 LA1055 Loader Lift Height LL5001: 132.9 in (height position); 116.8 in (power position) 112.7 in (at pivot pin) Loader Lift Capacity (Full Height) LL5001: 3,426 lb (height position, at pivot pin, max height); 3,488 lb (power position, at pivot pin, max height) 2,361 lb (at pivot pin) Loader Breakout Force Not Published 3,171 lbf ▶ WarrantyWarranty Length & Coverage Basic 2 years or 750 hours; powertrain 6 years or 1,500 hours Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
