▶ EnginePTO Power 54.1 hp 53.5 hp Alternator 70 A, 12 V 55 A, 12 V Air Cleaner Dry Not Published Engine Type In-line vertical, water cooled 4-cycle diesel, CRDI Four stroke, turbocharged, intercooled, CRDI, water cooled diesel engine, comply with US Tier-4 Final Fuel System Delphi, CRDI CRDI Displacement 152.9 in³ 161.7 in³ No. of Cylinders 4 3 Rated Engine Speed 2500 rpm 2100 rpm Cooling System Type Water-cooled Water-cooled Engine Manufacturer LS Mtron Mahindra Engine Power (Gross) 63 hp 62 hp @ 100 rpm Engine Emissions Constraints Tier 4 US Tier-4 Final; No DPF; No DEF; No regeneration ▶ WeightWeight with ROPS and Loader 6,503 lb 8428 lb Weight with Cab and Loader Not Applicable Not Applicable ▶ WarrantyWarranty Length & Coverage 6-year limited powertrain warranty; 2-year bumper-to-bumper warranty 5-Year limited powertrain warranty ▶ HydraulicsPump Type Gear type, engine drive Not Published Steering Flow 6.8 gpm 4.6 gpm Implement Flow 14.9 gpm 11.1 gpm Total Hydraulic Flow 21.7 gpm 15.7 gpm Hydraulic System Type Open center Open center with position and draft control, telescoping stabilizers and flex links Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 21.7 gpm 15.7 gpm No. of Optional Remote Valves Not Published 1 No. of Standard Remote Valves 2 Pairs (Front), 2 Pairs (Rear) 2 ▶ PTO & HitchPTO Rear 540 / 540E 540 @ 1993 rpm and 540E @ 1469 rpm PTO Type Independent 2-speed independent push button type 1 PTO (wet clutch) Lift Control Type Position & Draft Position & draft control Hitch Lift Capacity 4,079 lbs Not Published Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II CAT I & II Hitch Lift Capacity (at 24”) 3,483 lbs 5952 lb ▶ Tire OptionsR3 Turf - Rear Not Published Not Published R3 Turf - Front Not Published Not Published Tire Size & Options Multiple options available (Standard Ag, Industrial, Large Ag, R14) R1 Agricultural, R4 Industrial R4 Industrial - Rear 19.5LX24 18.4X28 R4 Industrial - Front 10.5/80X18 43X16-20 R1 Agricultural - Rear 16.9-30 16.9X30 R1 Agricultural - Front 11.2-24 11.2X24 ▶ Fluid CapacityCoolant Capacity 3.0 gal Not Published Crankcase Capacity 1.8 gal Not Published Fuel Tank Capacity 24.3 gal 23.8 gal Front Axle Fluid Capacity 2.3 gal Not Published Transmission / Hydraulic System Capacity 16.8 gal Not Published ▶ Loader & AttachmentsLoader Lift Height 132.9 in 133 in Loader Breakout Force Not Published 5000 lb Quick Attach Loader System LL5001: Standard Quick-Attach, Skid-Steer Compatible (SSQA) 1,604.8 gal: Skid steer tool carrier system Loader Lift Capacity (Full Height) 3,488 lb 3609 lb ▶ Transmission & DrivetrainClutch Wet clutch disks Power shuttle with wet clutch and torsional damper No. of Speeds F16 X R16 15F / 15R Transmission Type Electro Power Shuttle Full Synchro Mesh Speed and Constant Mesh Range Max Travel Speed (Forward) Not Published 21.4 mph Max Travel Speed (Reverse) Not Published Not Published Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Not Published ▶ Chassis, Steering & ControlsBrakes Wet, Multi-disc Oil immersed brakes, lever actuated parking brake Steering Hydrostatic Power Steering Hydrostatic power steering with tiltable steering column Frame Type Not Published Not Published Front Axle Type Not Published Not Published Drawbar Capacity Not Published Not Published Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Seat With Suspension & Armrest Not Published ▶ Dimensions & ManeuverabilityWheelbase 83.1 in 87.4 in Overall Width 72.6 in 82 in Ground Clearance Not Published 15.5 in Height to Top of ROPS 113.9 in 106 in Height to Top of Cab Model Not Applicable Not Applicable Height to Top of ROPS (folded) Not Published Not Published Min. Turn Radius without Brakes 12.8 ft (3.9 m) 13.5 ft (4.1 m) Overall Length with 3-Point Hitch 154 in 152.7 in
