Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
LSMT774CPS
No photo
—
LSMT473PS
Comparison loaded for 2 tractors.
Spec
LS TractorMT774CPS
LS TractorMT473PS
PTO Power
65.6 hp
62.9 hp (46.9 kW)
Alternator
14 V, 120 A
12 V, 70 A
Air Cleaner
Dry
Dry
Engine Type
In-line, water-cooled, 4 stroke, CRDI
In-line vertical, water cooled 4-cycle diesel, CRDI
Fuel System
CRDI (Bosch CP4.11)
Delphi, CRDI
Displacement
206.7 in³ (3387 cc)
152.86 in³ (2505 cc)
No. of Cylinders
4
4
Rated Engine Speed
2,200 rpm
2,500 rpm
Cooling System Type
Water-cooled
Water-cooled
Engine Manufacturer
FPT Industrial
LS Mtron
Engine Emissions Constraints
Tier 4
Tier 4
Engine Power (Gross vs. Net HP)
Gross: 73.7 hp (55.0 kW)
Gross: 73.0 hp (54.4 kW)
Tractor Weight with Loader
9,487 lb (4,303 kg)
6,613 lb (3,000 kg)
Weight with Cab and Loader
9,487 lb (4,303 kg)
Not Applicable
Weight with ROPS and Loader
Not Applicable
6,613 lb (3,000 kg)
Pump Type
Gear pump type, engine drive
Gear type, engine drive
Steering Flow
24.4 L/min (6.4 gpm)
25.7 L/min (6.8 gpm)
Implement Flow
58.6 L/min (15.5 gpm)
56.4 L/min (14.9 gpm)
Total Hydraulic Flow
83.0 L/min (21.9 gpm)
82.1 L/min (21.7 gpm)
Hydraulic System Type
Open center
Open center
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
83.0 L/min (21.9 gpm)
82.1 L/min (21.7 gpm)
No. of Optional Remote Valves
1 Pair (Rear)
Not Published
No. of Standard Remote Valves
3 Pairs (Front), 2 Pairs (Rear)
2 Pairs (Front), 2 Pairs (Rear)
R3 Turf - Rear
Not Published
Not Published
R3 Turf - Front
Not Published
Not Published
Tire Size & Options
Multiple options available (Ag, R14)
Multiple options available (Standard Ag, Industrial, Large Ag, R14)
R4 Industrial - Rear
Not Published
19.5LX24
R4 Industrial - Front
Not Published
10.5/80X18
R1 Agricultural - Rear
16.9-30
16.9-30
R1 Agricultural - Front
11.2-24
11.2-24
PTO Rear
540 / 750 / 1,000
540 / 540E
PTO Type
Independent
Independent
Lift Control Type
Position & Draft
Position & Draft
Hitch Lift Capacity
7,253 lb
4,079 lbs
Mid-PTO Availability
Not Published
Not Published
Category, 3-Point Hitch
Category II
Category II
Hitch Lift Capacity (at 24”)
5,181 lb
3,483 lbs
Rear 3-Point Hitch Lift Capacity
7,253 lb
4,079 lbs
Coolant Capacity
3.2 gal (12 L)
3.0 gal (11.5 L)
Crankcase Capacity
1.7–2.1 gal (6.5–8.0 L)
1.8 gal (7.0 L)
Fuel Tank Capacity
30.4 gal (115 L)
24.3 gal (92 L)
Front Axle Fluid Capacity
1.4 gal (5.2 L)
2.3 gal (8.6 L)
Transmission / Hydraulic System Capacity
14.5 gal (55 L)
16.8 gal (63.5 L)
Loader Lift Height
139.9 in (3554 mm)
132.9 in (3376 mm)
Loader Breakout Force
5,313 lb
Not Published
Price for Backhoe Option
Not Applicable
Not Applicable
Price for Mid-Mount Mower
Not Applicable
Not Applicable
Quick Attach Loader System
LL8100: ISO 24410 “Quick Attachment” (lever-lock with latch pins into the attachment latch groove)
LL5001: Standard Quick-Attach, Skid-Steer Compatible (SSQA)
Loader Lift Capacity (Full Height)
5,139 lb
3,488 lb
Clutch
Wet clutch disks
Wet clutch disks
No. of Speeds
F24 X R24
F16 X R16
Transmission Type
Power shuttle with Hi-Lo and Hand clutch
Electro Power Shuttle
Max Travel Speed (Forward)
20.8 mph (33.5 km/h)
Not Published
Max Travel Speed (Reverse)
Not Published
Not Published
Differential Lock & Limited Slip Options
Electro-Hydraulic Differential lock (EHD)
Mechanical differential lock (pedal)
Brakes
Wet, Multi-disc
Wet, Multi-disc
Steering
Hydrostatic
Hydrostatic Power Steering
Frame Type
Not Published
Not Published
Front Axle Type
Not Published
Not Published
Drawbar Capacity
Not Published
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Air suspension seat
Seat With Suspension & Armrest
Wheelbase
90 in (2286 mm)
83.1 in (2111 mm)
Overall Width
78 in (1979 mm)
72.6 in (1844 mm)
Ground Clearance
Not Published
Not Published
Height to Top of ROPS
Not Applicable
113.9 in (2893 mm)
Height to Top of Cab Model
105 in (2667 mm)
Not Applicable
Height to Top of ROPS (folded)
Not Applicable
Not Published
Min. Turn Radius without Brakes
Not Published
12.8 ft (3.9 m)
Overall Length with 3-Point Hitch
171 in (4345 mm)
154 in (3912 mm)
Financing Options
0% financing up to 96 months on select models; cash rebate incentive (offers vary)
0% financing up to 96 months on select models; cash rebate incentive (offers vary)
