▶ EngineEngine Manufacturer FPT (Fiat Power Train) FPT Engine Model F34 F5C Engine Type 4-cylinder, CRDI, water-cooled 4-cylinder diesel, turbocharged No. of Cylinders 4 4 Displacement 206.7 in³ 207 in³ Rated Engine Speed 2200 rpm 2300 rpm Engine Power (Gross) 73.7 hp 74 hp PTO Power 65.6 hp 65 hp Engine Emissions Constraints Not Published US EPA Tier 4B Cooling System Type Water-cooled Liquid-cooled Air Cleaner Not Published Dry Fuel System Not Published Common rail fuel injection Alternator Not Published 120 A ▶ HydraulicsPump Type Gear pump type, engine drive Open center, dual pumps: implement pump plus dedicated steering and services pump Implement Flow 15.7 gpm 12.5 gpm Steering Flow 6.5 gpm 7.3 gpm (mechanical shuttle); 9.5 gpm (power shuttle) Total Hydraulic Flow 22.2 gpm 19.8 gpm (mechanical shuttle; 12.5 + 7.3, computed); 22.0 gpm (power shuttle; 12.5 + 9.5, computed) Overall Hydraulic Pump Flow 22.2 gpm 19.8 gpm (mechanical shuttle; 12.5 + 7.3, computed); 22.0 gpm (power shuttle; 12.5 + 9.5, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 3 Pairs (Front), 2 Pairs (Rear) Not Published No. of Optional Remote Valves Not Published Up to 3 rear remotes ▶ Fluid CapacityFuel Tank Capacity 30.4 gal 23.8 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity 14.5 gal Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Fully independent PTO Rear 540 / 750 / 1,000 540 rpm at 1,958 engine rpm (standard); 540E at 1,592 engine rpm (optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II / I Hitch Lift Capacity 7,275 lb Not Published Hitch Lift Capacity (at 24”) 5,181 lb 3,664 lb Lift Control Type Position & Draft Mechanical draft control; top link draft sensing ▶ Transmission & DrivetrainTransmission Type Power Shuttle 8x8 mechanical synchro shuttle (standard); 8x8 hydraulic power shuttle, 12x12 mechanical synchro shuttle or 12x12 hydraulic power shuttle (optional); creeper available with the power shuttle transmissions No. of Speeds 24 X 24 8F/8R (standard); 12F/12R (optional); 12F/12R or 20F/20R with creeper (optional) Max Travel Speed (Forward) 20.8 mph 20.1 mph (8x8 and 12x12, 20 mph transmissions); 24.1 mph (optional 24 mph 12x12 transmission, 4WD only) Max Travel Speed (Reverse) Not Published 20.1 mph Clutch Wet disks Mechanical dry disc (mechanical shuttle); wet disc (power shuttle) Differential Lock & Limited Slip Options Electro-Hydraulic Differential lock (EHD) Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic power steering Brakes Wet, Multi-disc Hydraulic wet disc Seat Suspension & Adjustability Air suspension seat Optional deluxe air suspension seat with fully integrated armrest and 10° swivel to the right; full-size instructor seat with seatbelt Front Axle Type Not Published Heavy-duty 2WD front axle; electronic 4WD front axle (optional) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 78.7 in Not Published Wheelbase 90 in 85.8 in (2WD); 83.9 in (4WD) Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published 134 in (2WD front axle) Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published 76 to 78.9 in Height to Top of Cab Model 105 in 94.8 to 97.8 in Overall Length 152.2 in (frame to link) 151 in ▶ WeightTractor Weight (Base) 7,827 lb 5,027 lb (2WD ROPS); 5,952 lb (4WD ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader 9,487 lb (7,827 + 1,660, computed; LL8100 loader without bucket) Not Published ▶ Tire OptionsTire Size & Options Ag 11.2-24 / 16.9-30; R14 320/85R24 / 460/85R30 Not Published R1 Agricultural - Front 11.2-24 Not Published R1 Agricultural - Rear 16.9-30 Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Skid-steer-style or Euro-style quick attach faceplate Loader Model LL8100 Factory-fit: 655TL (NSL or MSL); field-fit: 622TL (NSL), 627TL (MSL) Loader Lift Height LL8100: 139.9 in 655TL NSL: 126 in; 655TL MSL: 125 in; 622TL: 121 in; 627TL: 121 in Loader Lift Capacity (Full Height) LL8100: 5,139 lb (at pivot pin) 655TL NSL: 2,478 lb; 655TL MSL: 3,179 lb; 622TL: 1,830 lb; 627TL: 2,557 lb (to max height, at 31.5 in from pivot point) Loader Breakout Force LL8100: 5,313 lb (at pivot pin) 655TL NSL: 3,739 lb; 655TL MSL: 4,665 lb; 622TL: 3,042 lb; 627TL: 3,307 lb ▶ WarrantyWarranty Length & Coverage Basic 2 years or 750 hours; powertrain 5 years or 1,500 hours Not Published
