▶ EngineEngine Manufacturer Mitsubishi Yanmar Engine Model S3L2 3TNV80F Engine Type 3-cylinder, liquid-cooled, naturally aspirated IDI diesel 3 Cylinder, Water-Cooled, Diesel No. of Cylinders 3 3 Displacement 80.4 in³ 77.3 in³ Rated Engine Speed 2500 rpm 3000 rpm Engine Power (Gross) 24.6 hp 24.6 hp PTO Power MT225E (gear): 19.2 hp; MT225HE (HST): 17.2 hp 18.8 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Water-cooled, forced circulation Air Cleaner Dry Single element, dry Fuel System Indirect injection (IDI) Indirect injection Alternator 50 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Gear pump, engine driven Gear pump Implement Flow 7.9 gpm 4.2 gpm Steering Flow 4.6 gpm 2.8 gpm Total Hydraulic Flow 12.5 gpm 7.0 gpm Overall Hydraulic Pump Flow 12.5 gpm 6.95 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None standard Not Published No. of Optional Remote Valves 1 or 2 optional (double-acting, 2 or 4 quick couplers) Not Published ▶ Fluid CapacityFuel Tank Capacity 7.4 gal 5.8 gal Coolant Capacity 1.3 gal 0.95 gal Crankcase Capacity 1.1 gal 0.71 gal Transmission / Hydraulic System Capacity 8.5 gal 3.83 gal Front Axle Fluid Capacity 1.7 gal 0.85 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional Standard, 2,000 rpm Category, 3-Point Hitch Category I Category I (N) Hitch Lift Capacity 1,808 lb 1,323 lb Hitch Lift Capacity (at 24”) 1,433 lb 1,101 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type MT225E (gear): Synchro shuttle; MT225HE (HST): HST Hydrostatic (HST) with mechanical H/L constant-mesh range No. of Speeds MT225E (gear): F12 x R12; MT225HE (HST): 3 ranges (HST) 2 range (H/L) Max Travel Speed (Forward) Not Published 10.5 mph (H range, Ag tires) Max Travel Speed (Reverse) Not Published Not Published Clutch MT225E (gear): dry single clutch; MT225HE (HST): n/a None (HST) Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Rear differential lock (bevel gears with diff-lock) ▶ Chassis, Steering & ControlsFrame Type Not Published Sub-compact tractor; selectable 4WD Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet, multi-disc Wet disc, foot operated Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Selectable 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 54 in 45.8 in Wheelbase 66 in 57.5 in Ground Clearance Not Published 9.4 in Min. Turn Radius without Brakes 10.5 ft Not Published Height to Top of ROPS 88 in 91.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 118 in (frame to link) 104 in ▶ WeightTractor Weight (Base) MT225E (gear): 2,434 lb; MT225HE (HST): 2,469 lb 1,638 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, industrial or turf tires at no additional cost R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 7-14 6-12 R1 Agricultural - Rear 11.2-24 9.5-16 R3 Turf - Front 25x8.5-14 20x8-10 R3 Turf - Rear 41x14-20 29x12.5-15 R4 Industrial - Front 25x8.5-14 23x8.5-12 R4 Industrial - Rear 43x16-20 12-16.5 ▶ Loader & AttachmentsQuick Attach Loader System LL3300: quick attach loader with skid steer compatible bucket Quick attach front loader Loader Model LL3300 BBL105 Loader Lift Height LL3300: 91.1 in 75.5 in Loader Lift Capacity (Full Height) LL3300: 1,609 lb (at pivot pin) 992 lb (at pivot pin) Loader Breakout Force LL3300: 2,701 lb (at pivot pin) 1,531 lbf ▶ WarrantyWarranty Length & Coverage 6-year limited warranty Basic 24 months or 1,000 hours; powertrain 84 months or 2,000 hours; loader and backhoe 24 months from shipment, 12 months from sale, or 500 hours
