▶ EngineEngine Manufacturer Mitsubishi Yanmar Engine Model S3L2 3TNV80F-ZXKLST Engine Type 3-cylinder, liquid-cooled, naturally aspirated IDI diesel 3-cylinder, indirect injection (swirl chamber), liquid-cooled No. of Cylinders 3 3 Displacement 80.4 in³ 77.3 in³ Rated Engine Speed 2500 rpm 2800 rpm Engine Power (Gross) 24.6 hp 24.7 hp PTO Power MT225E (gear): 19.2 hp; MT225HE (HST): 17.2 hp 19.3 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Dry Fuel System Indirect injection (IDI) In-line injection pump Alternator 50 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Gear pump, engine driven Gear pump, engine driven Implement Flow 7.9 gpm 5.6 gpm Steering Flow 4.6 gpm 3.7 gpm Total Hydraulic Flow 12.5 gpm 9.3 gpm Overall Hydraulic Pump Flow 12.5 gpm 9.3 gpm Hydraulic System Type Not Published Open center system, position control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None standard 0 No. of Optional Remote Valves 1 or 2 optional (double-acting, 2 or 4 quick couplers) 1 pair (optional) ▶ Fluid CapacityFuel Tank Capacity 7.4 gal 6.79 gal Coolant Capacity 1.3 gal 0.9 gal Crankcase Capacity 1.1 gal 0.8 gal Transmission / Hydraulic System Capacity 8.5 gal 4.5 gal Front Axle Fluid Capacity 1.7 gal 0.8 gal ▶ PTO & HitchPTO Type Independent Independent (electro-hydraulic) PTO Rear 540 rpm Standard (540 rpm) Mid-PTO Availability Optional Optional (2,500 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,808 lb 1,896 lb Hitch Lift Capacity (at 24”) 1,433 lb 1,323 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type MT225E (gear): Synchro shuttle; MT225HE (HST): HST Hydrostatic Drive No. of Speeds MT225E (gear): F12 x R12; MT225HE (HST): 3 ranges (HST) 3 ranges Max Travel Speed (Forward) Not Published 12.86 mph Max Travel Speed (Reverse) Not Published 8.45 mph Clutch MT225E (gear): dry single clutch; MT225HE (HST): not applicable Not Published Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Mechanical differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet, multi-disc Wet, multi-disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Front wheel mechanical assist (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 118 in 111.9 in Overall Width 54 in 48.7 in Wheelbase 66 in 63.4 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 10.5 ft 8.2 ft (with brake applied) Height to Top of ROPS 88 in 86.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) MT225E (gear): 2,434 lb; MT225HE (HST): 2,469 lb 1,764 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, industrial or turf tires at no additional cost R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 7-14 7-12 R1 Agricultural - Rear 11.2-24 11.2-16 R3 Turf - Front 25x8.5-14 22x8.50-12 R3 Turf - Rear 41x14-20 31x15.50-15 R4 Industrial - Front 25x8.5-14 23x8.50-12 R4 Industrial - Rear 43x16-20 12-16.5 ▶ Loader & AttachmentsQuick Attach Loader System LL3300: quick attach loader with skid steer compatible bucket LL2300: Bobcat-type (skid-steer style) quick attach bucket carrier; LL2001: Not Published Loader Model LL3300 LL2300; LL2001 Loader Lift Height LL3300: 92 in LL2300: 84.4 in; LL2001: 84.4 in Loader Lift Capacity (Full Height) LL3300: 1,609 lb LL2300: 1,067 lb; LL2001: 1,127 lb (at pivot pin) Loader Breakout Force LL3300: 2,701 lb LL2300: 2,290 lb; LL2001: 1,744 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 6-year limited warranty 6-year limited warranty
