▶ EngineEngine Manufacturer Mitsubishi MHI Engine Model S3L2 S3L2-W463GTAC Engine Type 3-cylinder, liquid-cooled, naturally aspirated IDI diesel 3-cylinder, liquid-cooled, diesel, naturally aspirated, IDI No. of Cylinders 3 3 Displacement 80.4 in³ 80.4 in³ Rated Engine Speed 2500 rpm 2500 rpm Engine Power (Gross) 24.6 hp 24.6 hp PTO Power MT225E (gear): 19.2 hp; MT225HE (HST): 17.2 hp 19.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Dry Fuel System Indirect injection (IDI) IDI (indirect injection) Alternator 50 A, 12 V 50 A, 12 V ▶ HydraulicsPump Type Gear pump, engine driven Gear pump Implement Flow 7.9 gpm 7.9 gpm Steering Flow 4.6 gpm 4.6 gpm Total Hydraulic Flow 12.5 gpm 12.5 gpm Overall Hydraulic Pump Flow 12.5 gpm 12.5 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None standard None No. of Optional Remote Valves 1 or 2 optional (double-acting, 2 or 4 quick couplers) 1 pair (optional) ▶ Fluid CapacityFuel Tank Capacity 7.4 gal 10.6 gal Coolant Capacity 1.3 gal Not Published Crankcase Capacity 1.1 gal Not Published Transmission / Hydraulic System Capacity 8.5 gal Not Published Front Axle Fluid Capacity 1.7 gal Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm Standard (540 rpm) Mid-PTO Availability Optional Available (option) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,808 lb 1,808 lb Hitch Lift Capacity (at 24”) 1,433 lb 1,433 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type MT225E (gear): Synchro shuttle; MT225HE (HST): HST Synchro Shuttle No. of Speeds MT225E (gear): F12 x R12; MT225HE (HST): 3 ranges (HST) F12 x R12 Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch MT225E (gear): dry single clutch; MT225HE (HST): n/a Dry Single Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Mechanical differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet, multi-disc Wet, multi-disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 54 in 66 in Wheelbase 66 in 66 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 10.5 ft 10.8 ft (3.3 m) Height to Top of ROPS 88 in 95 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 118 in (frame to link) 119 in (frame to link) ▶ WeightTractor Weight (Base) MT225E (gear): 2,434 lb; MT225HE (HST): 2,469 lb 2,985 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, industrial or turf tires at no additional cost Ag, Industrial, VT and Turf; VT same size as Industrial R1 Agricultural - Front 7-14 7-14 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 25x8.5-14 25x8.50-14 R3 Turf - Rear 41x14-20 41x14.00-20 R4 Industrial - Front 25x8.5-14 27x8.50-15 R4 Industrial - Rear 43x16-20 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System LL3300: quick attach loader with skid steer compatible bucket LL3001, LL3002: ISO 24410 Quick Attaching Coupler Loader Model LL3300 LL3002 Loader Lift Height LL3300: 91.1 in LL3002: 94.3 in Loader Lift Capacity (Full Height) LL3300: 1,609 lb (at pivot pin) LL3002: 1,599 lb (at pivot pin, maximum height) Loader Breakout Force LL3300: 2,701 lb (at pivot pin) LL3002: 2,962 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 6-year limited warranty Two-year bumper to bumper; six-year limited powertrain
