▶ EngineEngine Manufacturer Mitsubishi Yanmar Engine Model S3L2 3TNV80F Engine Type 3-cylinder, liquid-cooled, naturally aspirated IDI diesel 3-cylinder, naturally aspirated, liquid-cooled diesel No. of Cylinders 3 3 Displacement 80.4 in³ 77.3 in³ Rated Engine Speed 2500 rpm 3000 rpm Engine Power (Gross) 24.6 hp 24.7 hp PTO Power MT225E (gear): 19.2 hp; MT225HE (HST): 17.2 hp 17.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Pressurized liquid with recirculating bypass Air Cleaner Dry Single-element dry air cleaner Fuel System Indirect injection (IDI) In-line injection pump, indirect injection (swirl chamber) Alternator 50 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Gear pump, engine driven Gear Implement Flow 7.9 gpm 4.6 gpm Steering Flow 4.6 gpm 2.1 gpm Total Hydraulic Flow 12.5 gpm 6.7 gpm Overall Hydraulic Pump Flow 12.5 gpm 6.7 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None standard 0 No. of Optional Remote Valves 1 or 2 optional (double-acting, 2 or 4 quick couplers) 1 ▶ Fluid CapacityFuel Tank Capacity 7.4 gal 6.6 gal Coolant Capacity 1.3 gal 3.49 qt Crankcase Capacity 1.1 gal 3 qt Transmission / Hydraulic System Capacity 8.5 gal 3.3 gal Front Axle Fluid Capacity 1.7 gal 0.5 gal ▶ PTO & HitchPTO Type Independent Independent, electro-hydraulic engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional Standard (2,500 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,808 lb 992 lb Hitch Lift Capacity (at 24”) 1,433 lb 728 lb Lift Control Type Position control Lift-hold-lower ▶ Transmission & DrivetrainTransmission Type MT225E (gear): Synchro shuttle; MT225HE (HST): HST 2-range hydrostatic, dual pedal No. of Speeds MT225E (gear): F12 x R12; MT225HE (HST): 3 ranges (HST) Infinite (2 ranges) Max Travel Speed (Forward) Not Published 9.1 mph Max Travel Speed (Reverse) Not Published 5.5 mph Clutch MT225E (gear): dry single clutch; MT225HE (HST): not applicable Not Published Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Mechanical, foot-operated rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet, multi-disc Wet, multi-disc Seat Suspension & Adjustability Not Published Deluxe high-back seat with armrests and adjustable backrest Front Axle Type Not Published 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 118 in 97.4 in Overall Width 54 in 46.7 in Wheelbase 66 in 56.1 in Ground Clearance Not Published 12 in Min. Turn Radius without Brakes 10.5 ft 94 in Height to Top of ROPS 88 in 90 in Height to Top of ROPS (folded) Not Published 64 in Height to Top of Cab Model Not Published 87.4 in ▶ WeightTractor Weight (Base) MT225E (gear): 2,434 lb; MT225HE (HST): 2,469 lb ROPS: 1,444 lb; Cab: 1,805 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, industrial or turf tires at no additional cost R3 Turf, R4 Industrial R1 Agricultural - Front 7-14 Not Published R1 Agricultural - Rear 11.2-24 Not Published R3 Turf - Front 25x8.5-14 18x8.50-10 R3 Turf - Rear 41x14-20 26x12.0-12 R4 Industrial - Front 25x8.5-14 18x8.50-10 R4 Industrial - Rear 43x16-20 26x12.0-12 ▶ Loader & AttachmentsQuick Attach Loader System LL3300: quick attach loader with skid steer compatible bucket 100LC: Quick Mount system, no tools needed Loader Model LL3300 100LC Loader Lift Height LL3300: 92 in 100LC: 72 in Loader Lift Capacity (Full Height) LL3300: 1,609 lb 100LC: 1,005 lb Loader Breakout Force LL3300: 2,701 lb 100LC: 2,078 lb ▶ WarrantyWarranty Length & Coverage 6-year limited warranty Boomer Guard6 limited warranty: 2 years or 750 hours full coverage plus powertrain coverage to 6 years or 1,500 hours total
