▶ EngineEngine Manufacturer LS LS Mtron Engine Model L3C19-D2 Not Published Engine Type 3-cylinder, liquid-cooled, diesel, naturally aspirated, CRDI 3-cylinder, Tier 4 B/Final No. of Cylinders 3 3 Displacement 114.7 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 35 hp 35 hp PTO Power 29.7 hp 30.1 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Not Published Air Cleaner Dry Not Published Fuel System CRDI (Delphi common rail direct injection) Not Published Alternator 70 A, 12 V 85 A, 12 V ▶ HydraulicsPump Type Gear pump, engine driven Not Published Implement Flow 8.2 gpm 8.4 gpm Steering Flow 4.1 gpm Not Published Total Hydraulic Flow 12.3 gpm 13.3 gpm Overall Hydraulic Pump Flow 12.3 gpm Not Published Hydraulic System Type Open center system, position control Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None 0 No. of Optional Remote Valves 1 or 2 pairs (optional) 3 ▶ Fluid CapacityFuel Tank Capacity 7.4 gal 12.6 gal Coolant Capacity 1.9 gal Not Published Crankcase Capacity 1.5 gal Not Published Transmission / Hydraulic System Capacity 8.5 gal Not Published Front Axle Fluid Capacity 1.7 gal Not Published ▶ PTO & HitchPTO Type Independent (wet disc clutch) Independent, electro-hydraulic engagement PTO Rear Standard (540 rpm) 540 rpm Mid-PTO Availability Optional (2,000 rpm) Optional, 2,000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,808 lb Not Published Hitch Lift Capacity (at 24”) 1,433 lb 1,596 lb Lift Control Type Position control Mechanical Draft Control (MDC) ▶ Transmission & DrivetrainTransmission Type Synchro Shuttle 3-range hydrostatic (optional) No. of Speeds F12 x R12 3 ranges Max Travel Speed (Forward) 14.33 mph 14.8 mph (with R4 tires) Max Travel Speed (Reverse) 13.63 mph Not Published Clutch Dry single clutch n/a (no clutch on hydrostatic) Differential Lock & Limited Slip Options Mechanical pedal type Mechanical differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Not Published Brakes Wet, multi-disc Not Published Seat Suspension & Adjustability Not Published Adjustable suspension seat Front Axle Type Front wheel mechanical assist (4WD) Mechanical Front Drive (MFD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 54 in 66.5 in Wheelbase 69 in 66.2 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 10.79 ft (left); 11.02 ft (right) 10.5 ft Height to Top of ROPS 88 in 96.2 in Height to Top of ROPS (folded) Not Published 74.2 in Height to Top of Cab Model Not Published Not Published Overall Length 121 in (frame to link) 119.4 in ▶ WeightTractor Weight (Base) 2,866 lb 3,042 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, industrial or turf tires at no additional cost R1 Agricultural, R3 Turf, or R4 Industrial R1 Agricultural - Front 7-14 7x14 R1 Agricultural - Rear 11.2-24 11.2x24 R3 Turf - Front 25x8.50-14 25x8.50-14 R3 Turf - Rear 41x14-20 41x14.00-20 R4 Industrial - Front 27x8.50-14 25x8.50-14 R4 Industrial - Rear 43x16-20 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model LL3302 L340A Loader Lift Height 94 in 98 in Loader Lift Capacity (Full Height) LL3302: 2,153 lb (at pivot pin, full height) 890 lb at 31.5 in forward of pivot pin Loader Breakout Force LL3302: 3,579 lb (at pivot pin) 1,900 lb ▶ WarrantyWarranty Length & Coverage 6-year limited warranty Basic 2 years; powertrain 4 additional years (6-year total)
