▶ EngineEngine Manufacturer LS LS Mtron Engine Model L3C19-D2 L3C19-T5 Engine Type 3-cylinder, liquid-cooled, diesel, naturally aspirated, CRDI Diesel, 3-cylinder, turbocharged No. of Cylinders 3 3 Displacement 114.7 in³ 115.9 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 35 hp 35 hp PTO Power 29.7 hp 28 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Not Published Air Cleaner Dry Replaceable dry element Fuel System CRDI (Delphi common rail direct injection) Common rail direct injection Alternator 70 A, 12 V 70 A ▶ HydraulicsPump Type Gear pump, engine driven Not Published Implement Flow 8.2 gpm 8.2 gpm Steering Flow 4.1 gpm 5.3 gpm Total Hydraulic Flow 12.3 gpm 13.5 gpm (8.2 + 5.3, computed) Overall Hydraulic Pump Flow 12.3 gpm Not Published Hydraulic System Type Open center system, position control Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None 1 No. of Optional Remote Valves 1 or 2 pairs (optional) 2 ▶ Fluid CapacityFuel Tank Capacity 7.4 gal 10.5 gal Coolant Capacity 1.9 gal Not Published Crankcase Capacity 1.5 gal Not Published Transmission / Hydraulic System Capacity 8.5 gal Not Published Front Axle Fluid Capacity 1.7 gal Not Published ▶ PTO & HitchPTO Type Independent (wet disc clutch) Independent rear PTO, electro-hydraulic engagement PTO Rear Standard (540 rpm) 540 rpm Mid-PTO Availability Optional (2,000 rpm) Optional, 2000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,808 lb Not Published Hitch Lift Capacity (at 24”) 1,433 lb 1,808 lb Lift Control Type Position control Mechanical draft control (MDC) ▶ Transmission & DrivetrainTransmission Type Synchro Shuttle 3-range hydrostatic (HST) No. of Speeds F12 x R12 Infinitely variable, 3 ranges Max Travel Speed (Forward) 14.33 mph 14.8 mph Max Travel Speed (Reverse) 13.63 mph Not Published Clutch Dry single clutch Not Applicable Differential Lock & Limited Slip Options Mechanical pedal type Mechanical differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Wet, multi-disc Wet multi-disc Seat Suspension & Adjustability Not Published Adjustable suspension seat Front Axle Type Front wheel mechanical assist (4WD) Mechanical Front Drive (MFD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 54 in 66.4 in Wheelbase 69 in 66 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 10.79 ft (left); 11.02 ft (right) Not Published Height to Top of ROPS 88 in 93.5 in Height to Top of ROPS (folded) Not Published 74.1 in Height to Top of Cab Model Not Published Not Applicable Overall Length 121 in (frame to link) 122.5 in ▶ WeightTractor Weight (Base) 2,866 lb 3,175 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, industrial or turf tires at no additional cost R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 7-14 7-14 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 25x8.50-14 25x8.50-14 R3 Turf - Rear 41x14-20 41x14.00-20 R4 Industrial - Front 27x8.50-14 25x8.50-14 R4 Industrial - Rear 43x16-20 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Quick-Attach faceplate; mid-mount frame with fast loader connect and disconnect (L350A) Loader Model LL3302 L350A Loader Lift Height 94 in 105 in Loader Lift Capacity (Full Height) LL3302: 2,153 lb (at pivot pin, full height) 1,540 lb at 31.5 in forward of pivot pin Loader Breakout Force LL3302: 3,579 lb (at pivot pin) 2,640 lb ▶ WarrantyWarranty Length & Coverage 6-year limited warranty Basic 2 years; powertrain 4 additional years (6-year, 72-month total)
