▶ EngineEngine Manufacturer LS YANMAR Engine Model L3C19-D2 3TNV88C-MLST Engine Type 3-cylinder, liquid-cooled, diesel, naturally aspirated, CRDI 3-cylinder, liquid-cooled No. of Cylinders 3 3 Displacement 114.7 in³ 100.2 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 35 hp 31.7 hp PTO Power 29.7 hp 26.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Dry Fuel System CRDI (Delphi common rail direct injection) CRDI (common rail direct injection) Alternator 70 A, 12 V 55 A, 12 V ▶ HydraulicsPump Type Gear pump, engine driven Gear pump Implement Flow 8.2 gpm 6.7 gpm Steering Flow 4.1 gpm 5.0 gpm Total Hydraulic Flow 12.3 gpm 11.7 gpm Overall Hydraulic Pump Flow 12.3 gpm 11.7 gpm Hydraulic System Type Open center system, position control Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None 1 pair No. of Optional Remote Valves 1 or 2 pairs (optional) Not Published ▶ Fluid CapacityFuel Tank Capacity 7.4 gal 11.4 gal Coolant Capacity 1.9 gal Not Published Crankcase Capacity 1.5 gal Not Published Transmission / Hydraulic System Capacity 8.5 gal Not Published Front Axle Fluid Capacity 1.7 gal Not Published ▶ PTO & HitchPTO Type Independent (wet disc clutch) Independent PTO Rear Standard (540 rpm) Standard (540 rpm) Mid-PTO Availability Optional (2,000 rpm) Available (option) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,808 lb 1,808 lb Hitch Lift Capacity (at 24”) 1,433 lb 1,433 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Synchro Shuttle HST No. of Speeds F12 x R12 3 ranges Max Travel Speed (Forward) 14.33 mph Not Published Max Travel Speed (Reverse) 13.63 mph Not Published Clutch Dry single clutch Not Published Differential Lock & Limited Slip Options Mechanical pedal type Mechanical differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet, multi-disc Wet, multi-disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Front wheel mechanical assist (4WD) Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 54 in 66 in Wheelbase 69 in 69 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 10.79 ft (left); 11.02 ft (right) 11.5 ft (3.5 m) Height to Top of ROPS 88 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 90 in Overall Length 121 in (frame to link) 125 in (frame to link) ▶ WeightTractor Weight (Base) 2,866 lb 3,721 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, industrial or turf tires at no additional cost Ag, Industrial, VT and Turf; VT same size as Industrial R1 Agricultural - Front 7-14 7-14 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 25x8.50-14 25x8.50-14 R3 Turf - Rear 41x14-20 41x14.00-20 R4 Industrial - Front 27x8.50-14 27x8.50-15 R4 Industrial - Rear 43x16-20 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System Not Published LL3003: ISO 24410 Quick Attaching Coupler Loader Model LL3302 LL3003, LL3004 Loader Lift Height 94 in LL3003, LL3004: 94.3 in Loader Lift Capacity (Full Height) LL3302: 2,153 lb (at pivot pin, full height) LL3003, LL3004: 2,063 lb (at pivot pin, maximum height) Loader Breakout Force LL3302: 3,579 lb (at pivot pin) LL3003, LL3004: 3,723 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 6-year limited warranty Two-year bumper to bumper; six-year limited powertrain
