▶ EngineEngine Manufacturer LS LS Engine Model L3C19-D2 L3C19-T5 Engine Type 3-cylinder, liquid-cooled, diesel, naturally aspirated, CRDI Vertical, water-cooled, 4-cycle diesel No. of Cylinders 3 3 Displacement 114.7 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 35 hp 35 hp PTO Power 29.7 hp XR3135, XR3135C (gear): 29.7 hp; XR3135H, XR3135HC (HST): 28 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry Dry Fuel System CRDI (Delphi common rail direct injection) CRDI (common rail direct injection) Alternator 70 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Gear pump, engine driven Gear pump, engine driven Implement Flow 8.2 gpm 8.2 gpm Steering Flow 4.1 gpm XR3135, XR3135C (gear): 4.1 gpm; XR3135H, XR3135HC (HST): 5.5 gpm Total Hydraulic Flow 12.3 gpm XR3135, XR3135C (gear): 12.3 gpm; XR3135H, XR3135HC (HST): 13.7 gpm Overall Hydraulic Pump Flow 12.3 gpm XR3135, XR3135C (gear): 12.3 gpm; XR3135H, XR3135HC (HST): 13.7 gpm Hydraulic System Type Open center system, position control Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None 2 pairs No. of Optional Remote Valves 1 or 2 pairs (optional) Optional (2 or 6 quick couplers) ▶ Fluid CapacityFuel Tank Capacity 7.4 gal XR3135, XR3135H (ROPS): 10.6 gal; XR3135C, XR3135HC (cab): 12.4 gal Coolant Capacity 1.9 gal 1.9 gal Crankcase Capacity 1.5 gal 1.5 gal Transmission / Hydraulic System Capacity 8.5 gal 7.9 gal Front Axle Fluid Capacity 1.7 gal 1.7 gal ▶ PTO & HitchPTO Type Independent (wet disc clutch) Independent PTO Rear Standard (540 rpm) 540 rpm (3-speed 540/750/1000 optional) Mid-PTO Availability Optional (2,000 rpm) Optional, 2000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,808 lb 1,808 lb Hitch Lift Capacity (at 24”) 1,433 lb 1,433 lb Lift Control Type Position control Position and draft control ▶ Transmission & DrivetrainTransmission Type Synchro Shuttle XR3135, XR3135C (gear): Synchro shuttle; XR3135H, XR3135HC (HST): HST No. of Speeds F12 x R12 XR3135, XR3135C (gear): F12 x R12; XR3135H, XR3135HC (HST): 3 ranges (HST) Max Travel Speed (Forward) 14.33 mph Not Published Max Travel Speed (Reverse) 13.63 mph Not Published Clutch Dry single clutch Mechanical: dry single clutch; HST: not applicable Differential Lock & Limited Slip Options Mechanical pedal type Mechanical differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet, multi-disc Wet, multi-disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Front wheel mechanical assist (4WD) Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 54 in 62 in Wheelbase 69 in 69 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 10.79 ft (left); 11.02 ft (right) 9.2 ft (with brake applied) Height to Top of ROPS 88 in 94 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 86.6 in Overall Length 121 in (frame to link) 128.3 in (bumper to link) ▶ WeightTractor Weight (Base) 2,866 lb XR3135 (gear, ROPS): 3,175 lb; XR3135H (HST, ROPS): 3,285 lb; XR3135C (gear, cab): 3,589 lb; XR3135HC (HST, cab): 3,655 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, industrial or turf tires at no additional cost Ag, industrial or turf tires at no additional cost R1 Agricultural - Front 7-14 7-14 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 25x8.50-14 25x8.5-14 R3 Turf - Rear 41x14-20 41x14-20 R4 Industrial - Front 27x8.50-14 25x8.5-14 R4 Industrial - Rear 43x16-20 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System Not Published LL3106, LL3116: quick attach, skid steer compatible Loader Model LL3302 LL3106; LL3116 Loader Lift Height 94 in LL3106: 92.7 in; LL3116: 94.4 in Loader Lift Capacity (Full Height) LL3302: 2,153 lb (at pivot pin, full height) LL3106: 2,178 lb; LL3116: 2,185 lb (at pivot pin) Loader Breakout Force LL3302: 3,579 lb (at pivot pin) LL3106: 3,450 lb; LL3116: 3,612 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 6-year limited warranty 6-year limited warranty
