▶ EngineEngine Manufacturer LS TYM Engine Model L3C19-D2 T1700N6 Engine Type 3-cylinder, liquid-cooled, diesel, naturally aspirated, CRDI 3-cylinder, naturally aspirated diesel No. of Cylinders 3 3 Displacement 114.7 in³ 104.5 in³ Rated Engine Speed 2600 rpm 2100 rpm Engine Power (Gross) 35 hp 35 hp PTO Power 29.7 hp 30 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Not Published Air Cleaner Dry Dry element Fuel System CRDI (Delphi common rail direct injection) IDI (indirect injection) Alternator 70 A, 12 V 50 A, 12 V ▶ HydraulicsPump Type Gear pump, engine driven Dual gear pump Implement Flow 8.2 gpm 7.5 gpm Steering Flow 4.1 gpm 4.0 gpm Total Hydraulic Flow 12.3 gpm 11.5 gpm Overall Hydraulic Pump Flow 12.3 gpm 11.5 gpm Hydraulic System Type Open center system, position control Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None Loader: 4 / Rear: 0 No. of Optional Remote Valves 1 or 2 pairs (optional) Up to 4 ▶ Fluid CapacityFuel Tank Capacity 7.4 gal 8.7 gal Coolant Capacity 1.9 gal 5.3 qt Crankcase Capacity 1.5 gal 4.5 qt Transmission / Hydraulic System Capacity 8.5 gal T3035R: 8.9 gal; T3035H: 9.8 gal Front Axle Fluid Capacity 1.7 gal 6.8 qt ▶ PTO & HitchPTO Type Independent (wet disc clutch) Independent PTO Rear Standard (540 rpm) 540 rpm Mid-PTO Availability Optional (2,000 rpm) Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,808 lb 3,307 lb Hitch Lift Capacity (at 24”) 1,433 lb 2,425 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Synchro Shuttle T3035R: Synchromesh; T3035H: HST No. of Speeds F12 x R12 T3035R: F12 x R12; T3035H: 3-Range Max Travel Speed (Forward) 14.33 mph T3035R: 14.4 mph; T3035H: 18.8 mph Max Travel Speed (Reverse) 13.63 mph Not Published Clutch Dry single clutch T3035R: Dry single plate; T3035H: None (HST) Differential Lock & Limited Slip Options Mechanical pedal type Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic Brakes Wet, multi-disc Wet, multi-disc Seat Suspension & Adjustability Not Published Suspension seat Front Axle Type Front wheel mechanical assist (4WD) Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 54 in 56.3 in Wheelbase 69 in 65.7 in Ground Clearance Not Published 14.4 in Min. Turn Radius without Brakes 10.79 ft (left); 11.02 ft (right) 105.5 in Height to Top of ROPS 88 in 97.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 121 in (frame to link) 120.9 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2,866 lb 2,970 lb (with ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, industrial or turf tires at no additional cost R1 Agricultural 8-16 / 12.4-24; R3 Turf 27x8.5-15 / 41x14.00; R4 Industrial 10-16.5 / 420/70-24 R1 Agricultural - Front 7-14 8-16 R1 Agricultural - Rear 11.2-24 12.4-24 R3 Turf - Front 25x8.50-14 27x8.5-15 R3 Turf - Rear 41x14-20 41x14.00 R4 Industrial - Front 27x8.50-14 10-16.5 R4 Industrial - Rear 43x16-20 420/70-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model LL3302 L3035 Loader Lift Height 94 in L3035: 104.9 in Loader Lift Capacity (Full Height) LL3302: 2,153 lb (at pivot pin, full height) L3035: 2,200 lb (at pivot pin) Loader Breakout Force LL3302: 3,579 lb (at pivot pin) L3035: 3,422 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage 6-year limited warranty Basic 24 months or 2,000 hours, parts and labor; non-commercial, 20 to 70 engine hp: powertrain 72 months or 3,000 hours; loaders, backhoes and mid-mount mowers 12 months
