▶ PtoPTO Power — 15 hp Mid PTO (Type / RPM) — Standard (2500 rpm) Rear PTO (Type / RPM) — Standard (540 rpm) ▶ HitchThree-Point Hitch Category — CAT I Lift Capacity at 24 in Behind — 728 lbs ▶ EnginePTO Power — 15 hp Alternator — 40 A, 12 V Air Cleaner — Replaceable paper elements Engine Type — 3-cylinder, Indirect-injection, Water-cooled Fuel System — Mechanical, in-line type Displacement — 68 in³ No. of Cylinders — 3 Rated Engine Speed — 3000 rpm Cooling System Type — Water-cooled Engine Manufacturer — Yanmar Engine Power (Gross) — 21.5 hp Engine Emissions Constraints — Tier 4 ▶ WeightTractor Weight (Base) — 1,433 lbs Tractor Weight with Loader — 1,433 lbs. Weight with Cab and Loader — Not Applicable Weight with ROPS and Loader — Not Published ▶ HydraulicsPump Type — Gear Steering Flow — 2.1 gpm Implement Flow — 4.6 gpm Pump Flow (Total) — 6.7 gpm Pump Flow (Steering) — 2.1 gpm Total Hydraulic Flow — 6.7 gpm Hydraulic System Type — Open center system, Position control Pump Flow (Implement) — 4.6 gpm System Operating Pressure — 1,885.5 psi Rear Remote Hydraulic Flow — Not Published Overall Hydraulic Pump Flow — 6.7 gpm No. of Optional Remote Valves — 1 No. of Standard Remote Valves — 0 ▶ DimensionsWheelbase — 56 in. Overall Width — 47 in. Overall Length — 97 in. Ground Clearance — Not provided in source Height to Top of ROPS — 87 in. ▶ PTO & HitchPTO Rear — Standard (540 rpm) PTO Type — Independent Lift Control Type — Position Hitch Lift Capacity — 970 lbs. (At 24 in: 728) Mid-PTO Availability — Standard (2,500 rpm) Category, 3-Point Hitch — CAT I Hitch Lift Capacity (at 24”) — 728 lb ▶ Tire OptionsR3 Turf - Rear — 26 x 12.0 - 12 R3 Turf - Front — 18 x 8.5 - 10 Tire Size & Options — Front: 18x8.5-10 Industrial; Rear: 26x12.0-12 Industrial R4 Industrial - Rear — 26 x 12.0 - 12 R4 Industrial - Front — 18 x 8.5 - 10 R1 Agricultural - Rear — Not Published R1 Agricultural - Front — Not Published ▶ TransmissionNumber of Speeds — 2 Ranges Transmission Type — Hydrostatic Drive ▶ Fluid CapacityCoolant Capacity — 0.9 gal (0.9U.S.gals) Crankcase Capacity — 0.8 gal (0.8U.S.gals) Fuel Tank Capacity — 6.6 gal. Front Axle Fluid Capacity — 0.5 gal (0.5U.S.gals) Transmission / Hydraulic System Capacity — 3 gal (3.0U.S.gals) Transmission/Hydraulic Capacity — 3 gal (3.0 U.S. gals); 3.4 gal (3.4 U.S. gals) with front-end loader; 4.7 gal (4.7 U.S. gals) with front-end loader and backhoe ▶ Loader & AttachmentsLoader Lift Height — 72.0 in. Loader Breakout Force — 1,960 lbs. Loader Lift Capacity (Full Height) — 1,007 lbs. Price for Backhoe Option — Not Published Price for Mid-Mount Mower — Not Published Quick Attach Loader System — LL1101: Pin-Type Bucket (standard); Quick Attach Assembly (Optional) - Compact Type (dual-lever LH/RH); LL1700: Quick Attach Implement System ▶ Transmission & DrivetrainClutch — Not Applicable No. of Speeds — 2 Ranges Transmission Type — Hydrostatic Drive Max Travel Speed (Forward) — 0 ~ 14.0 Km/h (0 ~ 8.70 mph) Max Travel Speed (Reverse) — 0 ~ 8.4 Km/h (0 ~ 5.22 mph) Differential Lock & Limited Slip Options — Mechanical pedal type ▶ Chassis, Steering & ControlsBrakes — Wet, Multi-disc Steering — Hydrostatic Power Steering Front Axle Type — Front Wheel Mechanical Assist (4WD) Drawbar Capacity — Vertical load: 881.8 lb (882lbs), Horizontal load: 1.6 tonnes (3527lbs) Front Axle Rating — 1433 lb Seat Suspension & Adjustability — High-Back Seat with Foldable Armrest and Retractable Seatbelt; fore/aft adjustable ▶ Dimensions & ManeuverabilityWheelbase — 56 in. Overall Width — 47 in. Height to Top of ROPS — 87 in. Min. Turn Radius without Brakes — 7.87 ft Overall Length with 3-Point Hitch — 97 in. Ground Clearance — Not Published Height to Top of Cab Model — Not Applicable Height to Top of ROPS (folded) — Not Published ▶ Pricing, Financing & WarrantyWarranty Length & Coverage — 6 Year Limited Warranty ▶ Chassis Steering & ControlsBrakes — Wet, Multi-disc Steering — Hydrostatic power steering Frame Type — Not Published Front Axle Type — Not Published Drawbar Capacity — Not Published Front Axle Rating — 1,433 lb max permissible Seat Suspension & Adjustability — High-back seat; reversible for backhoe use ▶ Pricing Financing & WarrantyFinancing Options — 0% financing up to 120 months on MT1 models (limited time; subject to approved credit) Base Price with Loader — Not Published Warranty Length & Coverage — 6-year limited powertrain warranty; 2-year bumper-to-bumper warranty Base Price with Loader + Cab — Not Published ▶ ITC Company AccessoriesAccessories that fit
