▶ EngineEngine Manufacturer LS LS Mtron Engine Model L3C19-T4 L3C19-T Engine Type 3-cylinder, liquid-cooled, diesel, turbocharged (TC), CRDI 3 Cylinder, Liquid-cooled, Diesel, TC, CRDI No. of Cylinders 3 3 Displacement 114.7 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 40 hp 42 hp PTO Power 34 hp H, HC: 35.7 hp; C: 33.6 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Dry Fuel System CRDI (Delphi common rail direct injection) Common rail direct injection (CRDI) Alternator 70 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Gear pump, engine driven Gear pump, engine drive Implement Flow 8.2 gpm 8.2 gpm Steering Flow 4.1 gpm H: 5.5 gpm; HC: 6.8 gpm; C: 4.1 gpm Total Hydraulic Flow 12.3 gpm H: 13.7 gpm; HC: 15.0 gpm; C: 12.3 gpm Overall Hydraulic Pump Flow 12.3 gpm H: 13.7 gpm; HC: 15.0 gpm; C: 12.3 gpm Hydraulic System Type Open center system, position control Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None 2 Pair (1 Detent, 1 STD) No. of Optional Remote Valves 1 or 2 pairs (optional) Not Published ▶ Fluid CapacityFuel Tank Capacity 7.4 gal H: 10.6 gal; HC, C: 12.4 gal Coolant Capacity 1.9 gal 2.3 gal Crankcase Capacity 1.5 gal 1.6 gal Transmission / Hydraulic System Capacity 8.5 gal 11.4 gal Front Axle Fluid Capacity 1.7 gal 2.2 gal ▶ PTO & HitchPTO Type Independent (wet disc clutch) Independent PTO Rear Standard (540 rpm) 540 rpm Mid-PTO Availability Optional (2,000 rpm) Optional (2,000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,808 lb 2,755 lb Hitch Lift Capacity (at 24”) 1,433 lb 2,469 lb Lift Control Type Position control Position & Draft ▶ Transmission & DrivetrainTransmission Type Synchro Shuttle H, HC: Hydrostatic (HST); C: Synchro shuttle No. of Speeds F12 x R12 H, HC: 3 ranges (HST); C: F16 x R16 Max Travel Speed (Forward) 14.33 mph Not Published Max Travel Speed (Reverse) 13.63 mph Not Published Clutch Dry single clutch Gear: Dry single clutch; HST: Not Applicable Differential Lock & Limited Slip Options Mechanical pedal type Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic Power Steering Brakes Wet, multi-disc Wet, Multi-disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Front wheel mechanical assist (4WD) Mechanical front-wheel drive (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 54 in 62.5 in Wheelbase 69 in 73.2 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 10.79 ft (left); 11.02 ft (right) 10.3 ft Height to Top of ROPS 88 in H: 95 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published HC, C: 90 in Overall Length 121 in (frame to link) 133 in (frame to link) ▶ WeightTractor Weight (Base) 2,881 lb H: 3,935 lb; HC: 4,446 lb; C: 4,380 lb Weight with ROPS and Loader Not Published H: 4,715 lb (3,935 + 780, computed); LL4106 loader without bucket Weight with Cab and Loader Not Published HC: 5,226 lb (4,446 + 780, computed); C: 5,160 lb (4,380 + 780, computed); LL4106 loader without bucket ▶ Tire OptionsTire Size & Options Ag, industrial or turf tires at no additional cost Agricultural, Turf, Industrial R1 Agricultural - Front 7-14 9.5-16 R1 Agricultural - Rear 11.2-24 13.6-24 R3 Turf - Front 25x8.50-14 28x8.5-15 R3 Turf - Rear 41x14-20 41x14-20 R4 Industrial - Front 27x8.50-14 12-16.5 R4 Industrial - Rear 43x16-20 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published LL4106, LL4001: 2-lever skid-steer coupler, fits universal skid-steer attachments Loader Model LL3302 LL4106; LL4001 Loader Lift Height LL3302: 94 in LL4106: 94.4 in; LL4001: 104.3 in Loader Lift Capacity (Full Height) LL3302: 2,153 lb (at pivot pin, full height) LL4106: 2,680 lb (at pivot pin); LL4001: 2,998 lb (at pivot pin) Loader Breakout Force LL3302: 3,579 lb (at pivot pin) LL4106: 4,063 lb (at pivot pin); LL4001: 4,295 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 6-year limited warranty 6-year limited powertrain warranty
