▶ EngineEngine Manufacturer LS Mtron Yanmar Engine Model L3C19-T 3TNV86CT-KJPT Engine Type 3 Cylinder, Liquid-cooled, Diesel, TC, CRDI 4-cycle, inline, water-cooled diesel, turbocharged No. of Cylinders 3 3 Displacement 114.7 in³ 95.8 in³ Rated Engine Speed 2600 rpm 2800 rpm Engine Power (Gross) 42 hp 41.6 hp PTO Power 35.7 hp 36.3 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid Air Cleaner Dry Dry Fuel System Common rail direct injection (CRDI) Direct injection Alternator 70 A, 12 V 55 A, 12 V ▶ HydraulicsPump Type Not Published Two single-section external gear pumps, one either side of the engine Implement Flow 8.2 gpm 5.9 gpm Steering Flow 4.1 gpm 4.4 gpm Total Hydraulic Flow 12.3 gpm 10.3 gpm Overall Hydraulic Pump Flow 12.3 gpm 10.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 Pair (1 Detent, 1 STD) None No. of Optional Remote Valves Not Published Loader mast mounted SCV (optional); 4th/5th SCV (optional) ▶ Fluid CapacityFuel Tank Capacity 10.6 gal 9.7 gal Coolant Capacity Not Published Not Published Crankcase Capacity 1.6 gal 1.1 gal Transmission / Hydraulic System Capacity Not Published 9.2 gal Front Axle Fluid Capacity Not Published 1.0 gal ▶ PTO & HitchPTO Type Independent Transmission driven PTO Rear 540 rpm 540 rpm at 2800 rpm engine (rated) Mid-PTO Availability Optional (2,000 rpm) Not Published Category, 3-Point Hitch Not Published Category I Hitch Lift Capacity 2,755 lb Not Published Hitch Lift Capacity (at 24”) 2,469 lb 1,670 lb Lift Control Type Position & Draft Position control ▶ Transmission & DrivetrainTransmission Type Synchro shuttle 8F/8R synchromesh shuttle shift gear transmission No. of Speeds F16 x R16 8F/8R Max Travel Speed (Forward) Not Published 12.9 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Single dry traction (mechanical) Differential Lock & Limited Slip Options Mechanical rear differential lock Differential lock: Yes ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power Steering Power steering Brakes Wet, Multi-disc Wet disk Seat Suspension & Adjustability Not Published Not Published Front Axle Type Mechanical front-wheel drive (4WD) 4WD Front Axle Rating Not Published 1,940 lb Drawbar Capacity Not Published 1,102 lb (maximum static vertical load) ▶ Dimensions & ManeuverabilityOverall Width 62.5 in 57.3 in Wheelbase 73.2 in 62 in Ground Clearance Not Published 14 in Min. Turn Radius without Brakes Not Published 6.9 ft (with brake applied) Height to Top of ROPS 95 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 133 in (frame to link) 111.2 in ▶ WeightTractor Weight (Base) 3,869 lb 2,800 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural, Turf, Industrial R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front 9.5-16 7-14 R1 Agricultural - Rear 13.6-24 11.2-24 R3 Turf - Front 28x8.5-15 27X8.50-15 R3 Turf - Rear 41x14-20 Not Published R4 Industrial - Front 12-16.5 25X8.50-14 R4 Industrial - Rear 17.5L-24 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System LL4106, LL4001: 2-lever skid-steer coupler, fits universal skid-steer attachments Quick-change attachment carrier Loader Model LL4106; LL4001 300E Loader Lift Height LL4106: 94.4 in; LL4001: 104.3 in 84 in Loader Lift Capacity (Full Height) LL4106: 2,680 lb (at pivot pin); LL4001: 2,998 lb (at pivot pin) 1,186 lb (at pivot point, maximum height) Loader Breakout Force LL4106: 4,063 lb (at pivot pin); LL4001: 4,295 lb (at pivot pin) 1,704 lbf (at pivot point) ▶ WarrantyWarranty Length & Coverage 6-year limited powertrain warranty Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours
