▶ EngineEngine Manufacturer LS Mtron TYM Engine Model L3C19-T T2300N2 Engine Type 3 Cylinder, Liquid-cooled, Diesel, TC, CRDI 4-cylinder, naturally aspirated diesel No. of Cylinders 3 4 Displacement 114.7 in³ 139.5 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 47 hp 48 hp PTO Power 37.6 hp 38.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Dry element Fuel System Common rail direct injection (CRDI) IDI (indirect injection) Alternator 70 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Not Published Dual gear pump Implement Flow 8.2 gpm 11.4 gpm Steering Flow 4.1 gpm 5.2 gpm Total Hydraulic Flow 12.3 gpm 16.5 gpm Overall Hydraulic Pump Flow 12.3 gpm 16.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 Pair (1 Detent, 1 STD) 4 No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 10.6 gal 11.8 gal Coolant Capacity Not Published 8.3 qt Crankcase Capacity 1.6 gal 4.8 qt Transmission / Hydraulic System Capacity Not Published 4820C: 10.3 gal; 4820CH: 11.1 gal Front Axle Fluid Capacity Not Published 6.8 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540/750 rpm Mid-PTO Availability Optional (2,000 rpm) Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,755 lb 3,306 lb Hitch Lift Capacity (at 24”) 2,469 lb 2,425 lb Lift Control Type Position & Draft Position control ▶ Transmission & DrivetrainTransmission Type Synchro shuttle 4820C: Synchromesh; 4820CH: HST No. of Speeds F16 x R16 4820C: F16 x R16; 4820CH: 4-Range Max Travel Speed (Forward) Not Published 4820C: 16 mph; 4820CH: 19.5 mph Max Travel Speed (Reverse) Not Published 4820C: 15.2 mph; 4820CH: 19.5 mph Clutch Not Published 4820C: Dry single type; 4820CH: N/A (HST) Differential Lock & Limited Slip Options Mechanical rear differential lock Standard differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power Steering Hydrostatic Brakes Wet, Multi-disc Wet, multi-disc Seat Suspension & Adjustability Not Published Suspension seat Front Axle Type Mechanical front-wheel drive (4WD) 4WD (selectable 2WD/4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 62.5 in 64.9 in Wheelbase 73.2 in 71.1 in Ground Clearance Not Published 15.5 in Min. Turn Radius without Brakes Not Published L: 128.7 in; R: 126.0 in Height to Top of ROPS 95 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Applicable 97 in Overall Length 133 in (frame to link) 127.4 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 3,869 lb 4,349 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Applicable Not Published ▶ Tire OptionsTire Size & Options Agricultural, Turf, Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 9.5-16 9.5-16 R1 Agricultural - Rear 13.6-24 13.6-26 R3 Turf - Front 28x8.5-15 27x8.5-15 / 29x12.5-15 R3 Turf - Rear 41x14-20 41x14-20 / 44x18-20 R4 Industrial - Front 12-16.5 12-16.5 R4 Industrial - Rear 17.5L-24 17.5Lx24 ▶ Loader & AttachmentsQuick Attach Loader System LL4106, LL4001: 2-lever skid-steer coupler, fits universal skid-steer attachments BL200C: Quick attach mechanism Loader Model LL4106; LL4001 BL200C Loader Lift Height LL4106: 94.4 in; LL4001: 104.3 in BL200C: 106.6 in Loader Lift Capacity (Full Height) LL4106: 2,680 lb (at pivot pin); LL4001: 2,998 lb (at pivot pin) BL200C: 2,701 lb (at pivot pin) Loader Breakout Force LL4106: 4,063 lb (at pivot pin); LL4001: 4,295 lb (at pivot pin) BL200C: 3,660 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage 6-year limited powertrain warranty Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months ▶ ITC Company AccessoriesAccessories that fit None tagged yet
