▶ EngineEngine Manufacturer LS Mtron Kubota Engine Model L3C19-T V2403-CR-TE4-GL1 Engine Type 3 Cylinder, Liquid-cooled, Diesel, TC, CRDI Liquid-cooled, 4-cycle multi valve, diesel, Turbocharged No. of Cylinders 3 4 Displacement 114.7 in³ 148.5 in³ Rated Engine Speed 2600 rpm 2700 rpm Engine Power (Gross) 52 hp 52 hp PTO Power 44.2 hp 44 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Dry paper, dual element Fuel System Common rail direct injection (CRDI) Electronic Common Rail System (CRS) Alternator 70 A, 12 V 45 A, 12 V ▶ HydraulicsPump Type Not Published Tandem pump - gear type Implement Flow 8.2 gpm 9.8 gpm Steering Flow 4.1 gpm 4.9 gpm Total Hydraulic Flow 12.3 gpm 14.7 gpm Overall Hydraulic Pump Flow 12.3 gpm 14.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 3 Pair (2 Detent, 1 STD) Not Published No. of Optional Remote Valves Not Published Optional, up to 3: double-acting valve or float detent valve, any position ▶ Fluid CapacityFuel Tank Capacity 10.6 gal 13.5 gal Coolant Capacity Not Published 8.7 qt Crankcase Capacity 6.2 qt 9.9 qt Transmission / Hydraulic System Capacity Not Published 11.9 gal Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Live independent (hydraulic clutch) PTO Rear 540 rpm 540 rpm @ 2550 engine rpm Mid-PTO Availability Optional (2,000 rpm) Optional Category, 3-Point Hitch Category II SAE Category I & II Hitch Lift Capacity 2,755 lb 3,858 lb Hitch Lift Capacity (at 24”) 2,469 lb 2,976 lb Lift Control Type Position & Draft Position control ▶ Transmission & DrivetrainTransmission Type Synchro shuttle Glide Shift No. of Speeds F16 x R16 12Fx8R Max Travel Speed (Forward) Not Published 16.5 mph Max Travel Speed (Reverse) Not Published 15.8 mph Clutch Not Published Dry type single stage Differential Lock & Limited Slip Options Mechanical rear differential lock Rear differential lock, standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power Steering Hydrostatic power steering Brakes Wet, Multi-disc Wet disc type, mechanically activated Seat Suspension & Adjustability Not Published Suspension seat with swivel function Front Axle Type Mechanical front-wheel drive (4WD) 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,433 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 133 in 135.0 in Overall Width 62.5 in 67.3 in Wheelbase 73.2 in 75.4 in Ground Clearance Not Published 15.4 in Min. Turn Radius without Brakes Not Published 9.2 ft (with brake applied) Height to Top of ROPS 95 in 98.0 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 3,869 lb 3,979 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial Standard R1 (9.5-16 / 14.9-26); options: R1 (9.5-16 / 13.6-28), R4 (10-16.5 / 17.5L-24), R3 (29x12.50-15 / 44x18-20), LSW R3 (LSW305R343 / LSW610R470) R1 Agricultural - Front 9.5-16 9.5-16 R1 Agricultural - Rear 13.6-24 14.9-26; 13.6-28 R3 Turf - Front 28x8.5-15 29X12.50-15 R3 Turf - Rear 41x14-20 44X18-20 R4 Industrial - Front 12-16.5 10-16.5 R4 Industrial - Rear 17.5L-24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System LL4106, LL4001: 2-lever skid-steer coupler, fits universal skid-steer attachments 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) Loader Model LL4106; LL4001 LA1055 Loader Lift Height LL4106: 94.4 in; LL4001: 104.3 in 112.7 in Loader Lift Capacity (Full Height) LL4106: 2,680 lb; LL4001: 2,998 lb 2,361 lb Loader Breakout Force LL4106: 4,063 lb; LL4001: 4,295 lb 3,171 lbf (19.7 in forward of pivot pin) ▶ WarrantyWarranty Length & Coverage 6-year limited powertrain warranty Not Published
