Compare Tractors

See horsepower, lift capacity, hydraulic flow, and the numbers that matter to your work. Up to 4 machines, side by side, in graphs built to show which tractor is better at what.

2 of 4 selected

—

LSTractorMT352

—

LSMT125

Comparison loaded for 2 tractors.

The headline numbers at a glance.

LS Tractor MT352LS Tractor MT125

Engine HPhp

—

24.7 hp

PTO HPhp

—

17.2 hp

Weightlb

—

1,444 lb

Loader Liftlb

—

1,007 lb

3-Pt Lift (24 in)lb

—

728 lb

Share↓ Image 𝕏 f ✉

Full Spec Sheet

Every published spec, side by side, including the details the graphs above don't chart.

Spec	LS TractorMT352	LS TractorMT125


PTO Power	—	17.2 hp
Alternator	—	40 A, 12 V
Air Cleaner	—	Dry
Engine Type	—	3-cylinder, Indirect-injection, Water-cooled
Fuel System	—	Indirect Injection
Displacement	—	77.3 in³
No. of Cylinders	—	3
Rated Engine Speed	—	3000 rpm
Cooling System Type	—	Water-cooled
Engine Manufacturer	—	Yanmar
Engine Power (Gross)	—	24.7 hp
Engine Emissions Constraints	—	Tier 4

Tractor Weight (Base)	—	1,444 lbs
Weight with ROPS and Loader	—	1444 lb
Weight with Cab and Loader	—	Not Published

Warranty Length & Coverage	—	6-Year Limited Warranty

Pump Type	—	Gear pump type, Transmission drive
Steering Flow	—	2.1 gpm
Implement Flow	—	4.6 gpm
Total Hydraulic Flow	—	6.7 gpm
Hydraulic System Type	—	Open center system, Position control
System Operating Pressure	—	12.7~13.2 MPa (1849~1920 psi)
Rear Remote Hydraulic Flow	—	NOT FOUND — No source explicitly lists a dedicated 'Rear Remote Hydraulic Flow' spec. The closest published figure is the implement pump flow of 4.6 gpm, but no source labels this specifically as 'Rear Remote' flow.
Overall Hydraulic Pump Flow	—	6.7 gpm
No. of Optional Remote Valves	—	1 Set
No. of Standard Remote Valves	—	0 (optional)

PTO Rear	—	540 rpm
PTO Type	—	Independent
Lift Control Type	—	Position Control
Hitch Lift Capacity	—	970 lbs. (At 24 in: 728)
Mid-PTO Availability	—	Standard (2,500 rpm)
Category, 3-Point Hitch	—	Category 1
Hitch Lift Capacity (at 24”)	—	728 lb

R3 Turf - Rear	—	26x12.0-12 4PR HSR82 (Turf)
R3 Turf - Front	—	18x8.50-10 4PR HS482 (Turf)
Tire Size & Options	—	Industrial Front/Rear 18×18.5 - 10/26 x 12.0 - 12; Versa Turf Front/Rear: 18×18.5 - 10/26 x 12.0 - 12
R4 Industrial - Rear	—	26x12.0-12 4PR HS610 (Industrial)
R4 Industrial - Front	—	18x8.50-10 4PR HS610 (Industrial)
R1 Agricultural - Rear	—	26 x 12.0 - 12
R1 Agricultural - Front	—	18×18.5 - 10

Coolant Capacity	—	0.9 gal (0.9U.S.gals)
Crankcase Capacity	—	0.8 gal (0.8U.S.gals)
Fuel Tank Capacity	—	6.6 gal.
Front Axle Fluid Capacity	—	0.5 gal (0.5U.S.gals)
Transmission / Hydraulic System Capacity	—	3 gal (3.0U.S.gals)

Loader Lift Height	—	72.0 in.
Loader Breakout Force	—	1,960 lbs.
Quick Attach Loader System	—	LL1101 Quick-Attach Front Loader
Loader Lift Capacity (Full Height)	—	1,007 lbs.

Clutch	—	Not Applicable
No. of Speeds	—	2 Ranges
Transmission Type	—	Hydrostatic Drive
Max Travel Speed (Forward)	—	0 ~ 14.0 Km/h (0 ~ 8.70 mph) [HIGH range]
Max Travel Speed (Reverse)	—	0 ~ 8.4 Km/h (0 ~ 5.22 mph) [HIGH range]
Differential Lock & Limited Slip Options	—	Mechanical pedal type

Brakes	—	Wet, Multi-disc
Steering	—	Hydrostatic Power Steering
Frame Type	—	Not Published
Front Axle Type	—	4WD (Front Wheel Mechanical Assist)
Drawbar Capacity	—	Vertical load: 881.8 lb (882lbs), Horizontal load: 1.6 tonnes (3527lbs) [Hitch]; Vertical load: 772 lb, Horizontal load: 1.6 tonnes (3527lbs) [Drawbar w/clevis]
Front Axle Rating	—	1433 lb
Seat Suspension & Adjustability	—	Forward/backward adjustable via seat F/R adjustment lever; reversible seat optional

Wheelbase	—	56 in.
Overall Width	—	47 in.
Overall Length	—	97 in
Ground Clearance	—	NOT FOUND
Height to Top of ROPS	—	87 in.
Height to Top of Cab Model	—	NOT FOUND
Height to Top of ROPS (folded)	—	NOT FOUND
Min. Turn Radius without Brakes	—	7.87 ft
Overall Length with 3-Point Hitch	—	97 in.
