▶ EngineEngine Manufacturer LS Mtron Kubota Engine Model L3C19-T V2403CR-T Engine Type 3 Cylinder, Liquid-cooled, Diesel, TC, CRDI Liquid-cooled, diesel, 4-cylinder, Turbocharged No. of Cylinders 3 4 Displacement 114.7 in³ 148.6 in³ Rated Engine Speed 2600 rpm 2700 rpm Engine Power (Gross) 57 hp 57 hp PTO Power 45.6 hp 46.5 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Dry-dual element Fuel System Common rail direct injection (CRDI) Common Rail System (CRS), direct injection Alternator 70 A, 12 V 45 A, 12 V ▶ HydraulicsPump Type Not Published Gear Implement Flow 8.2 gpm 9.5 gpm Steering Flow 4.1 gpm 4.9 gpm Total Hydraulic Flow 12.3 gpm 14.4 gpm (9.5 + 4.9, computed) Overall Hydraulic Pump Flow 12.3 gpm 14.4 gpm (9.5 + 4.9, computed) Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 Pair (1 Detent, 1 STD) Not Published No. of Optional Remote Valves Not Published Maximum 3 (opt) ▶ Fluid CapacityFuel Tank Capacity 10.6 gal 13.5 gal Coolant Capacity Not Published 6.9 qt Crankcase Capacity 1.6 gal 7.4 qt Transmission / Hydraulic System Capacity Not Published 11.6 gal Front Axle Fluid Capacity Not Published 8.9 qt ▶ PTO & HitchPTO Type Independent Live independent, hydraulic PTO with PTO brake, wet clutch PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional (2,000 rpm) Not Published Category, 3-Point Hitch Category II I & II Hitch Lift Capacity 2,755 lb 2,870 lb Hitch Lift Capacity (at 24”) 2,469 lb 2,310 lb Lift Control Type Position & Draft Position (std), Draft (opt) ▶ Transmission & DrivetrainTransmission Type Synchro shuttle 3-range hydrostatic (HST) No. of Speeds F16 x R16 3-range Max Travel Speed (Forward) Not Published DT (2WD/4WD): 17.3 mph; HST (4WD): 17.7 mph Max Travel Speed (Reverse) Not Published DT (2WD/4WD): 15.9 mph; HST (4WD): 16.0 mph Clutch Not Published No clutch Differential Lock & Limited Slip Options Mechanical pedal type Rear differential lock standard (mechanical) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power Steering Hydrostatic power steering Brakes Wet, Multi-disc Mechanical wet disc Seat Suspension & Adjustability Not Published High-back suspension seat (optional arm rests) Front Axle Type Mechanical front-wheel drive (4WD) Bevel gear type (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,650 lb ▶ Dimensions & ManeuverabilityOverall Width 62.5 in 69.7 in Wheelbase 73.2 in 74.6 in Ground Clearance Not Published 15.2 in Min. Turn Radius without Brakes Not Published 8.9 ft (with brake applied) Height to Top of ROPS 95 in 95.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Applicable Not Applicable Overall Length 133 in (frame to link) 125.9 in (without 3-point hitch) ▶ WeightTractor Weight (Base) 3,869 lb 3,734 lb (with ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Applicable Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial Standard ag: 9.5-16 / 14.9-26 R1 Agricultural - Front 9.5-16 9.5-16 R1 Agricultural - Rear 13.6-24 14.9-26 R3 Turf - Front 28x8.5-15 Not Published R3 Turf - Rear 41x14-20 Not Published R4 Industrial - Front 12-16.5 Not Published R4 Industrial - Rear 17.5L-24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System LL4106, LL4001: 2-lever skid-steer coupler, fits universal skid-steer attachments 1065A: 2-Lever Quick Coupler for Loader Attachment Loader Model LL4106; LL4001 LA1065 Loader Lift Height LL4106: 94.4 in; LL4001: 104.3 in 111.2 in (at pivot pin) Loader Lift Capacity (Full Height) LL4106: 2,680 lb (at pivot pin); LL4001: 2,998 lb (at pivot pin) 2,275 lb (at pivot pin) Loader Breakout Force LL4106: 4,063 lb (at pivot pin); LL4001: 4,295 lb (at pivot pin) 3,102 lbf ▶ WarrantyWarranty Length & Coverage 6-year limited powertrain warranty Residential: basic 24 months or 2,000 hours, powertrain 72 months or 3,000 hours; commercial: basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
