▶ EngineEngine Manufacturer LS Mtron Yanmar Engine Model L3C19-T 3TNV80F Engine Type 3 Cylinder, Liquid-cooled, Diesel, TC, CRDI 3-cylinder, indirect injection (swirl chamber), water-cooled No. of Cylinders 3 3 Displacement 114.7 in³ 77.3 in³ Rated Engine Speed 2600 rpm 3000 rpm Engine Power (Gross) 57 hp 24.7 hp PTO Power 48.4 hp 17.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry Dry Fuel System Common rail direct injection (CRDI) In-line injection pump Alternator 70 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Not Published Gear pump, transmission driven Implement Flow 8.2 gpm 4.6 gpm Steering Flow 4.1 gpm 2.1 gpm Total Hydraulic Flow 12.3 gpm 6.7 gpm Overall Hydraulic Pump Flow 12.3 gpm 6.7 gpm Hydraulic System Type Open center Open center system, position control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 3 Pair (2 Detent, 1 STD) 0 No. of Optional Remote Valves Not Published 1 pair (2 quick couplers) ▶ Fluid CapacityFuel Tank Capacity 10.6 gal 6.6 gal Coolant Capacity Not Published 0.9 gal Crankcase Capacity 6.2 qt 0.8 gal Transmission / Hydraulic System Capacity Not Published 3.0 gal (3.4 gal with front-end loader; 4.7 gal with front-end loader and backhoe) Front Axle Fluid Capacity Not Published 0.5 gal ▶ PTO & HitchPTO Type Independent Independent (electro-hydraulic) PTO Rear 540 rpm Standard (540 rpm) Mid-PTO Availability Optional (2,000 rpm) Standard (2,500 rpm) Category, 3-Point Hitch Category II Category I Hitch Lift Capacity 2,755 lb 970 lb Hitch Lift Capacity (at 24”) 2,469 lb 728 lb Lift Control Type Position & Draft Position control ▶ Transmission & DrivetrainTransmission Type Synchro shuttle Hydrostatic Drive No. of Speeds F16 x R16 2 ranges Max Travel Speed (Forward) Not Published 8.70 mph Max Travel Speed (Reverse) Not Published 5.22 mph Clutch Not Published Not Published Differential Lock & Limited Slip Options Mechanical rear differential lock Mechanical pedal type ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power Steering Hydrostatic power steering Brakes Wet, Multi-disc Wet, multi-disc Seat Suspension & Adjustability Not Published Forward/backward adjustable via seat F/R adjustment lever; reversible seat optional Front Axle Type Mechanical front-wheel drive (4WD) Front wheel mechanical assist (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Hitch: 882 lb vertical, 3,527 lb horizontal; drawbar with clevis: 772 lb vertical, 3,527 lb horizontal ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 133 in 97 in Overall Width 62.5 in 47 in Wheelbase 73.2 in 56 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published 7.87 ft Height to Top of ROPS 95 in 87 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 3,869 lb 1,444 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial Front 18x8.50-10, rear 26x12.0-12; offered in industrial or turf R1 Agricultural - Front 9.5-16 Not Published R1 Agricultural - Rear 13.6-24 Not Published R3 Turf - Front 28x8.5-15 18x8.50-10 R3 Turf - Rear 41x14-20 26x12.0-12 R4 Industrial - Front 12-16.5 18x8.50-10 R4 Industrial - Rear 17.5L-24 26x12.0-12 ▶ Loader & AttachmentsQuick Attach Loader System LL4106, LL4001: 2 lever skid steer coupler (universal skid steer attachments) Not Published Loader Model LL4106; LL4001 LL1101; LL1100 Loader Lift Height LL4106: 94.4 in; LL4001: 104.3 in LL1101: 72.0 in; LL1100: 72.0 in (at pivot pin) Loader Lift Capacity (Full Height) LL4106: 2,680 lb; LL4001: 2,998 lb LL1101: 966 lb; LL1100: 1,005 lb (at pivot pin, maximum height) Loader Breakout Force LL4106: 4,063 lb; LL4001: 4,295 lb LL1101: 1,960 lb; LL1100: 2,083 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 6-year limited powertrain warranty 6-year limited warranty
