▶ EngineEngine Manufacturer LS Mtron LS Mtron Engine Model L3C19-T L3C19-T Engine Type 3 Cylinder, Liquid-cooled, Diesel, TC, CRDI 3 Cylinder, Liquid-cooled, Diesel, TC, CRDI No. of Cylinders 3 3 Displacement 114.7 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 57 hp 52 hp PTO Power 48.4 hp 44.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Dry Fuel System Common rail direct injection (CRDI) Common rail direct injection (CRDI) Alternator 70 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Not Published Gear pump, engine drive Implement Flow 8.2 gpm 8.2 gpm Steering Flow 4.1 gpm 4.1 gpm Total Hydraulic Flow 12.3 gpm 12.3 gpm Overall Hydraulic Pump Flow 12.3 gpm 12.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 3 Pair (2 Detent, 1 STD) 3 Pair (2 Detent, 1 STD) No. of Optional Remote Valves Not Published 3 Pair (2 Detent, 1 STD) ▶ Fluid CapacityFuel Tank Capacity 10.6 gal PCT: 10.6 gal; PCTC: 12.4 gal Coolant Capacity Not Published 2.3 gal Crankcase Capacity 6.2 qt 1.6 gal Transmission / Hydraulic System Capacity Not Published 11.4 gal Front Axle Fluid Capacity Not Published 2.2 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional (2,000 rpm) Optional (2,000 rpm) Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 2,755 lb 2,755 lb Hitch Lift Capacity (at 24”) 2,469 lb 2,469 lb Lift Control Type Position & Draft Position & Draft ▶ Transmission & DrivetrainTransmission Type Synchro shuttle Synchro shuttle / Power Clutch No. of Speeds F16 x R16 F16 x R16 Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Power clutch (hydraulic clutch valve and lever) Differential Lock & Limited Slip Options Mechanical rear differential lock Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power Steering Hydrostatic Power Steering Brakes Wet, Multi-disc Wet, Multi-disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Mechanical front-wheel drive (4WD) Mechanical front-wheel drive (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 133 in 133 in Overall Width 62.5 in 62.5 in Wheelbase 73.2 in 73.2 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published 10.3 ft (3.1 m) Height to Top of ROPS 95 in PCT: 95 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published PCTC: 90 in ▶ WeightTractor Weight (Base) 3,869 lb PCT: 3,869 lb; PCTC: 4,380 lb Weight with ROPS and Loader Not Published 4,649 lb Weight with Cab and Loader Not Published 5,160 lb ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 9.5-16 9.5-16 R1 Agricultural - Rear 13.6-24 13.6-24 R3 Turf - Front 28x8.5-15 28x8.5-15 R3 Turf - Rear 41x14-20 41x14-20 R4 Industrial - Front 12-16.5 12-16.5 R4 Industrial - Rear 17.5L-24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System LL4106, LL4001: 2 lever skid steer coupler (universal skid steer attachments) LL4106, LL4001: 2 lever skid steer coupler (universal skid steer attachments) Loader Model LL4106; LL4001 LL4106; LL4001 Loader Lift Height LL4106: 94.4 in; LL4001: 104.3 in LL4106: 94.4 in; LL4001: 104.3 in Loader Lift Capacity (Full Height) LL4106: 2,680 lb; LL4001: 2,998 lb LL4106: 2,680 lb; LL4001: 2,998 lb Loader Breakout Force LL4106: 4,063 lb; LL4001: 4,295 lb LL4106: 4,063 lb; LL4001: 4,295 lb ▶ WarrantyWarranty Length & Coverage 6-year limited powertrain warranty 6-year limited powertrain warranty
