▶ EngineEngine Manufacturer LS Mtron KIOTI Engine Model L4C25-T 4H243T Engine Type In-line vertical, water cooled 4-cycle diesel, CRDI Turbocharged, common-rail, water-cooled diesel (4H243T) No. of Cylinders 4 4 Displacement 152.9 in³ 148.6 in³ Rated Engine Speed 2500 rpm 2600 rpm Engine Power (Gross) 73 hp 73.1 hp PTO Power 62 hp 60.9 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Water-cooled Air Cleaner Dry Not Published Fuel System Not Published Common Rail Direct Injection (CRDI) Alternator 70 A, 12 V Not Published ▶ HydraulicsPump Type Gear type, engine drive Tandem Gear Implement Flow 13.2 gpm 12.4 gpm Steering Flow 6.6 gpm 8.2 gpm Total Hydraulic Flow 19.8 gpm 20.6 gpm Overall Hydraulic Pump Flow 19.8 gpm 20.6 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 3 Pairs (Front), 3 Pairs (Rear) 1 No. of Optional Remote Valves Not Published 2 ▶ Fluid CapacityFuel Tank Capacity 26.4 gal 26.4 gal Coolant Capacity 2.6 gal 2.51 gal Crankcase Capacity 2.1 gal 2.83 gal Transmission / Hydraulic System Capacity 14.5 gal 11.75 gal Front Axle Fluid Capacity 1.5 gal 2.6 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 / 750 / 1,000 540 / 540E rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 6,614 lb 5,584 lb Hitch Lift Capacity (at 24”) 4,718 lb 4,328 lb Lift Control Type Position & Draft Electronic Control ▶ Transmission & DrivetrainTransmission Type MT573C: Synchro Shuttle; MT573CPS: Power Shuttle Manual: Power Shuttle No. of Speeds F20 x R20 12 forward / 12 reverse Max Travel Speed (Forward) 19.4 mph 23.9 mph (22.01 mph on AG tires) Max Travel Speed (Reverse) Not Published 23.3 mph (21.92 mph on AG tires) Clutch MT573C: Dry single clutch; MT573CPS: Wet clutch disks Wet Disc Differential Lock & Limited Slip Options Electro-hydraulic differential lock (EHD) Rear differential lock (standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic Power Steering Brakes Not Published Wet Multi Disc Seat Suspension & Adjustability Air suspension seat (10° swivel) Adjustable Air-Ride Seat Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,984 lb ▶ Dimensions & ManeuverabilityOverall Width 77.5 in 82.1 in Wheelbase 84.6 in 85.4 in Ground Clearance Not Published 15.7 in Min. Turn Radius without Brakes 13.0 ft 12.8 ft Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 104.4 in 105.3 in Overall Length 150 in (frame to link) 150.3 in (with 3-point hitch) ▶ WeightTractor Weight (Base) MT573C: 6,620 lb; MT573CPS: 6,669 lb 7,015 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader MT573C: 7,852 lb (6,620 + 1,232, computed); MT573CPS: 7,901 lb (6,669 + 1,232, computed) Not Published ▶ Tire OptionsTire Size & Options Ag 11.2-24 / 16.9-30; R14 W320/85R24 122D / W460/85R30 145D Agricultural and Industrial: front AG 11.2-24 (Industrial 12.5/80-18), rear AG 16.9-30 (Industrial 18.4-24/8) R1 Agricultural - Front 11.2-24 11.2-24 R1 Agricultural - Rear 16.9-30 16.9-30 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published 12.5/80-18 R4 Industrial - Rear Not Published 18.4-24/8 ▶ Loader & AttachmentsQuick Attach Loader System LL6100: Bobcat-type quick attachment (ISO 24410), latch handle with latch pin Built-in parking stand; quick attach and detach Loader Model LL6100 KL7340 Loader Lift Height LL6100: 126.5 in KL7340: 127.1 in (to pivot pin) Loader Lift Capacity (Full Height) LL6100: 3,626 lb (at pivot pin) KL7340: 3,384 lb (to full height) Loader Breakout Force LL6100: 6,644 lb (at pivot pin) KL7340: 5,875 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 750 hours; powertrain 6 years or 1,500 hours Non-commercial: basic 24 months, powertrain 48 months, parts and labor
