▶ EngineEngine Manufacturer LS Mtron AGCO Power Engine Model L4C25-T 33 AWIC Engine Type In-line vertical, water cooled 4-cycle diesel, CRDI 3-cylinder, intercooled turbocharged diesel No. of Cylinders 4 3 Displacement 152.9 in³ 201.4 in³ Rated Engine Speed 2500 rpm 2200 rpm Engine Power (Gross) 73 hp 75 hp PTO Power 62 hp 60 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid cooled Air Cleaner Dry Dual element (primary and secondary) Fuel System Not Published High-pressure common rail direct fuel injection Alternator 70 A, 12 V 80 A ▶ HydraulicsPump Type Gear type, engine drive Two-stage pump Implement Flow 13.2 gpm Not Published Steering Flow 6.6 gpm Not Published Total Hydraulic Flow 19.8 gpm Not Published Overall Hydraulic Pump Flow 19.8 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 17.2 gpm No. of Standard Remote Valves 3 Pairs (Front), 3 Pairs (Rear) 2 No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 26.4 gal 33 gal Coolant Capacity 2.6 gal 4.2 gal Crankcase Capacity 2.1 gal 3.3 gal Transmission / Hydraulic System Capacity 14.5 gal Power Shuttle: 10.6 to 11.4 gal; Mechanical: 8.5 to 9.2 gal Front Axle Fluid Capacity 1.5 gal Dana: 1.45 gal beam plus 0.24 gal per final drive; Carraro: 1.3 gal beam plus 0.21 gal per final drive ▶ PTO & HitchPTO Type Independent Independent, electrohydraulic engagement PTO Rear 540 / 750 / 1,000 540/540E standard; 540/1000 optional Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 6,614 lb Not Published Hitch Lift Capacity (at 24”) 4,718 lb 4,850 lb Lift Control Type Position & Draft Not Published ▶ Transmission & DrivetrainTransmission Type MT573C: Synchro Shuttle; MT573CPS: Power Shuttle 12x12 fully synchronized power shuttle, 6 gears x 2 ranges, electrohydraulic shuttle lever; optional Dyna-2 24x24 powershift No. of Speeds F20 x R20 12 forward and 12 reverse; 24 forward and 24 reverse with optional Dyna-2 Max Travel Speed (Forward) 19.4 mph 2WD: 18 mph; 4WD: 25 mph Max Travel Speed (Reverse) Not Published Not Published Clutch MT573C: Dry single clutch; MT573CPS: Wet clutch disks Wet clutch with easy shift knob and electrohydraulic power shuttle lever Differential Lock & Limited Slip Options Electro-hydraulic differential lock (EHD) Hydraulic, electronically controlled; rear axle engaged via electrohydraulic rocker switch; 4WD front axle: hydraulic differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Cab: tilt and telescopic steering column; Platform: tilt steering column Brakes Not Published Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Seat Suspension & Adjustability Air suspension seat (10° swivel) Cab: mechanical swiveling seat with armrests, air-suspension swivel seat optional; Platform: mechanical spring-suspension seat with armrests Front Axle Type Not Published Heavy-duty 2WD or 4WD front axle Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 77.5 in 60.3 in (minimum, with std. 420/85R30 rear tires) Wheelbase 84.6 in 88.5 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 13.0 ft Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 104.4 in Not Published Overall Length 150 in (frame to link) Not Published ▶ WeightTractor Weight (Base) MT573C: 6,620 lb; MT573CPS: 6,669 lb 2WD ROPS: 7,478 lb; 2WD Cab: 8,294 lb; 4WD ROPS: 7,734 lb; 4WD Cab: 8,644 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader MT573C: 7,852 lb (6,620 + 1,232, computed); MT573CPS: 7,901 lb (6,669 + 1,232, computed) Not Published ▶ Tire OptionsTire Size & Options Ag 11.2-24 / 16.9-30; R14 W320/85R24 122D / W460/85R30 145D Rear: 420/85R30 standard R1 Agricultural - Front 11.2-24 2WD: 9.5L-15; 4WD: 320/85R24 R1 Agricultural - Rear 16.9-30 420/85R30 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System LL6100: Bobcat-type quick attachment (ISO 24410), latch handle with latch pin 931X and 936X: universal skid steer type quick release Loader Model LL6100 FL.3522, FL.3615, 931X, 936X Loader Lift Height LL6100: 126.5 in FL.3522: 140 in; FL.3615: 140 in; 931X: 136 in; 936X: 136 in (at pivot pin) Loader Lift Capacity (Full Height) LL6100: 3,626 lb (at pivot pin) FL.3522: 2,760 lb; FL.3615: 3,420 lb; 931X: 2,140 lb; 936X: 3,340 lb (to full height, at 31.5 in forward of pivot pin) Loader Breakout Force LL6100: 6,644 lb (at pivot pin) Not Published ▶ WarrantyWarranty Length & Coverage Basic 2 years or 750 hours; powertrain 6 years or 1,500 hours Not Published
