▶ EngineEngine Manufacturer FPT John Deere Engine Model F5G PowerTech PWL 4045 Engine Type 4-cylinder, CRDI, water-cooled Diesel, turbocharged, aftercooled No. of Cylinders 4 4 Displacement 206.7 in³ 276 in³ Rated Engine Speed 2200 rpm 2400 rpm Engine Power (Gross) 100.6 hp 100 hp PTO Power 85.5 hp 85 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Not Published Dry type with safety element Fuel System Not Published High Pressure Common Rail Alternator Not Published OOS: 90 A; Cab: 120 A ▶ HydraulicsPump Type Gear pump type, engine drive Tandem gear pump (implement + steering) Implement Flow 15.7 gpm 15.9 gpm Steering Flow 6.5 gpm 6.6 gpm Total Hydraulic Flow 22.2 gpm 22.5 gpm Overall Hydraulic Pump Flow 22.2 gpm 22.5 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 3 Pairs (Front), 2 Pairs (Rear) 2 No. of Optional Remote Valves Not Published 3 ▶ Fluid CapacityFuel Tank Capacity 30.4 gal OOS: 25 gal; Cab: 30 gal Coolant Capacity Not Published Cab: 3 gal; OOS: 2.5 gal Crankcase Capacity Not Published 3.2 gal (with filter) Transmission / Hydraulic System Capacity 14.5 gal 11.5 gal Front Axle Fluid Capacity Not Published MFWD differential housing: 1.3 gal; MFWD wheel hub (each): 0.74 qt ▶ PTO & HitchPTO Type Independent Independent, electrohydraulic engagement PTO Rear 540 / 750 / 1,000 540/540E rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 8,378 lb Not Published Hitch Lift Capacity (at 24”) Not Published 4,630 lb Lift Control Type Position & Draft Top link draft sensing; mechanical hitch controls ▶ Transmission & DrivetrainTransmission Type Power shuttle PowrReverser No. of Speeds 24 X 24 12F/12R (standard); 24F/12R (optional) Max Travel Speed (Forward) 23.1 mph 12F/12R: 21.7 mph; 24F/12R: 24.9 mph (electronically limited) Max Travel Speed (Reverse) Not Published Not Published Clutch Wet disks Wet traction clutch Differential Lock & Limited Slip Options Electro-Hydraulic Differential lock (EHD) Pedal-operated differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic power steering Brakes Wet, Multi-disc Hydraulic wet disc brakes, self-equalizing and self-adjusting Seat Suspension & Adjustability Air suspension seat Not Published Front Axle Type Not Published Mechanical front wheel drive (MFWD) Front Axle Rating Not Published 6,615 lb Drawbar Capacity Not Published Standard: 2,755 lb; 2,425 lb (350 and 15.7 in extended). Heavy-Duty: 3,195 lb; 2,645 lb (350 and 15.7 in extended) ▶ Dimensions & ManeuverabilityOverall Width 78.7 in Not Published Wheelbase 90 in 92.5 in Ground Clearance Not Published ROPS: 17 in; Cab: 15.2 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published 100.8 in Height to Top of ROPS (folded) Not Published 78.6 in Height to Top of Cab Model 107 in 101.2 in Overall Length 152.2 in (frame to link) 159.13 in ▶ WeightTractor Weight (Base) 7,985 lb OOS: 7,275 lb (shipping weight); Cab: 8,150 lb (shipping weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader 9,645 lb (7,985 + 1,660, computed; LL8100 loader without bucket) Not Published ▶ Tire OptionsTire Size & Options Ag 13.6-24 / 18.4-34; R14 340/70R28 / 460/75R38 Not Published R1 Agricultural - Front 13.6-24 12.4-24 R1 Agricultural - Rear 18.4-34 18.4-30 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published 12.5/80-18 R4 Industrial - Rear Not Published 19.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published 520M; 540M Loader Model LL8100 520M and 540M (previously H240 and H260) Loader Lift Height LL8100: 139.9 in 520M MSL: 132.0 in Loader Lift Capacity (Full Height) LL8100: 5,139 lb (at pivot pin) 520M MSL: 2,606 lb (to maximum height, measured at pivot) Loader Breakout Force LL8100: 5,313 lb (at pivot pin) 520M MSL: 4,793 lb (measured at pivot) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 750 hours; powertrain 5 years or 1,500 hours Not Published
