▶ EngineEngine Manufacturer Mitsubishi (MHI) Yanmar Engine Model S3L2 3TNV88F-EPJT Engine Type Indirect injection, swirl chamber diesel 4-cycle, inline, water-cooled diesel, naturally aspirated No. of Cylinders 3 3 Displacement 80.4 in³ 100.1 in³ Rated Engine Speed 2500 rpm 2400 rpm Engine Power (Gross) 24.4 hp 24.4 hp PTO Power XG3025 (gear): 19.2 hp; XG3025H (HST): 17.1 hp 20.7 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid Air Cleaner Dry Dual element Fuel System Indirect injection Direct injection Alternator 50 A, 12 V 55 A, 12 V ▶ HydraulicsPump Type Gear pump, engine driven Two single-section external gear pumps, one each side of engine timing-gear cover Implement Flow 7.9 gpm 4.8 gpm Steering Flow 4.6 gpm 3.6 gpm Total Hydraulic Flow 12.5 gpm Not Published Overall Hydraulic Pump Flow 12.5 gpm 8.9 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None standard Not Published No. of Optional Remote Valves 1 or 2 optional (double-acting, 2 or 4 quick couplers) Up to two (optional) ▶ Fluid CapacityFuel Tank Capacity 7.4 gal 10.0 gal Coolant Capacity 1.3 gal 1.2 gal Crankcase Capacity 1.1 gal 1.1 gal Transmission / Hydraulic System Capacity 8.5 gal 9.2 gal Front Axle Fluid Capacity 1.7 gal 1.0 gal ▶ PTO & HitchPTO Type Independent Not Published PTO Rear 540 rpm 540 rpm at 2400 rpm engine (rated) Mid-PTO Availability Optional Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,808 lb Not Published Hitch Lift Capacity (at 24”) 1,433 lb 2,081.2 lb @ 24 in behind link arms Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type XG3025 (gear): Synchro shuttle; XG3025H (HST): HST 8F/8R synchromesh shuttle shift gear transmission No. of Speeds XG3025 (gear): F12 x R12; XG3025H (HST): 3 ranges (HST) 8F/8R Max Travel Speed (Forward) Not Published 11.1 mph Max Travel Speed (Reverse) Not Published 11.6 mph Clutch XG3025 (gear): dry single clutch; XG3025H (HST): not applicable Not Published Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Wet, multi-disc Not Published Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published MFWD (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1102 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 118 in 111.2 in Overall Width 54 in 57.3 in Wheelbase 66 in 62.6 in Ground Clearance Not Published 13.0 in Min. Turn Radius without Brakes 10.5 ft 6.9 ft (with brakes) (with brake applied) Height to Top of ROPS 88 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) XG3025 (gear): 2,434 lb; XG3025H (HST): 2,469 lb 2987 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, industrial or turf tires R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front 7-14 7-14 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 25x8.5-14 27X8.50-15 R3 Turf - Rear 41x14-20 41X14-20 R4 Industrial - Front 25x8.5-14 25X8.50-14 R4 Industrial - Rear 43x16-20 15.00-19.5 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Quick-change attachment carrier Loader Model LL3110 D160 Loader Lift Height LL3110: 94.3 in 84.0 in Loader Lift Capacity (Full Height) LL3110: 1,600 lb 1,186 lb Loader Breakout Force LL3110: 2,637 lb 1,704 lb ▶ WarrantyWarranty Length & Coverage Not Published 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)
