▶ EngineEngine Manufacturer LS LS Mtron Engine Model L3C19-T5 Not Published Engine Type Vertical, water-cooled, 4-cycle diesel 3-cylinder, Tier 4 B/Final No. of Cylinders 3 3 Displacement 114.7 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 35 hp 35 hp PTO Power XR3135, XR3135C (gear): 29.7 hp; XR3135H, XR3135HC (HST): 28 hp 30.1 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Not Published Air Cleaner Dry Not Published Fuel System CRDI (common rail direct injection) Not Published Alternator 70 A, 12 V 85 A, 12 V ▶ HydraulicsPump Type Gear pump, engine driven Not Published Implement Flow 8.2 gpm 8.4 gpm Steering Flow XR3135, XR3135C (gear): 4.1 gpm; XR3135H, XR3135HC (HST): 5.5 gpm Not Published Total Hydraulic Flow XR3135, XR3135C (gear): 12.3 gpm; XR3135H, XR3135HC (HST): 13.7 gpm 13.3 gpm Overall Hydraulic Pump Flow XR3135, XR3135C (gear): 12.3 gpm; XR3135H, XR3135HC (HST): 13.7 gpm Not Published Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 pairs 0 No. of Optional Remote Valves Optional (2 or 6 quick couplers) 3 ▶ Fluid CapacityFuel Tank Capacity XR3135, XR3135H (ROPS): 10.6 gal; XR3135C, XR3135HC (cab): 12.4 gal 12.6 gal Coolant Capacity 1.9 gal Not Published Crankcase Capacity 1.5 gal Not Published Transmission / Hydraulic System Capacity 7.9 gal Not Published Front Axle Fluid Capacity 1.7 gal Not Published ▶ PTO & HitchPTO Type Independent Independent, electro-hydraulic engagement PTO Rear 540 rpm (3-speed 540/750/1000 optional) 540 rpm Mid-PTO Availability Optional, 2000 rpm Optional, 2,000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,808 lb Not Published Hitch Lift Capacity (at 24”) 1,433 lb 1,596 lb Lift Control Type Position and draft control Mechanical Draft Control (MDC) ▶ Transmission & DrivetrainTransmission Type XR3135, XR3135C (gear): Synchro shuttle; XR3135H, XR3135HC (HST): HST 3-range hydrostatic (optional) No. of Speeds XR3135, XR3135C (gear): F12 x R12; XR3135H, XR3135HC (HST): 3 ranges (HST) 3 ranges Max Travel Speed (Forward) Not Published 14.8 mph (with R4 tires) Max Travel Speed (Reverse) Not Published Not Published Clutch Mechanical: dry single clutch; HST: not applicable n/a (no clutch on hydrostatic) Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Mechanical differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Not Published Brakes Wet, multi-disc Not Published Seat Suspension & Adjustability Not Published Adjustable suspension seat Front Axle Type Not Published Mechanical Front Drive (MFD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 62 in 66.5 in Wheelbase 69 in 66.2 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 9.2 ft (with brake applied) 10.5 ft Height to Top of ROPS 94 in 96.2 in Height to Top of ROPS (folded) Not Published 74.2 in Height to Top of Cab Model 86.6 in Not Published Overall Length 128.3 in (bumper to link) 119.4 in ▶ WeightTractor Weight (Base) XR3135 (gear, ROPS): 3,175 lb; XR3135H (HST, ROPS): 3,285 lb; XR3135C (gear, cab): 3,589 lb; XR3135HC (HST, cab): 3,655 lb 3,042 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, industrial or turf tires at no additional cost R1 Agricultural, R3 Turf, or R4 Industrial R1 Agricultural - Front 7-14 7x14 R1 Agricultural - Rear 11.2-24 11.2x24 R3 Turf - Front 25x8.5-14 25x8.50-14 R3 Turf - Rear 41x14-20 41x14.00-20 R4 Industrial - Front 25x8.5-14 25x8.50-14 R4 Industrial - Rear 43x16-20 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System LL3106, LL3116: quick attach, skid steer compatible Not Published Loader Model LL3106; LL3116 L340A Loader Lift Height LL3106: 92.7 in; LL3116: 94.4 in 98 in Loader Lift Capacity (Full Height) LL3106: 2,178 lb; LL3116: 2,185 lb (at pivot pin) 890 lb at 31.5 in forward of pivot pin Loader Breakout Force LL3106: 3,450 lb; LL3116: 3,612 lb (at pivot pin) 1,900 lb ▶ WarrantyWarranty Length & Coverage 6-year limited warranty Basic 2 years; powertrain 4 additional years (6-year total)
