▶ EngineEngine Manufacturer LS YANMAR Engine Model L3C19-T5 3TNV88C-MLST Engine Type Vertical, water-cooled, 4-cycle diesel 3-cylinder, liquid-cooled, diesel, naturally aspirated, CRDI No. of Cylinders 3 3 Displacement 114.7 in³ 100.2 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 35 hp 31.7 hp PTO Power XR3135, XR3135C (gear): 29.7 hp; XR3135H, XR3135HC (HST): 28 hp 26.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry Dry Fuel System CRDI (common rail direct injection) CRDI (common rail direct injection) Alternator 70 A, 12 V 55 A, 12 V ▶ HydraulicsPump Type Gear pump, engine driven Gear pump Implement Flow 8.2 gpm 6.7 gpm Steering Flow XR3135, XR3135C (gear): 4.1 gpm; XR3135H, XR3135HC (HST): 5.5 gpm 5.0 gpm Total Hydraulic Flow XR3135, XR3135C (gear): 12.3 gpm; XR3135H, XR3135HC (HST): 13.7 gpm 11.7 gpm Overall Hydraulic Pump Flow XR3135, XR3135C (gear): 12.3 gpm; XR3135H, XR3135HC (HST): 13.7 gpm 11.7 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 pairs 1 pair No. of Optional Remote Valves Optional (2 or 6 quick couplers) Not Published ▶ Fluid CapacityFuel Tank Capacity XR3135, XR3135H (ROPS): 10.6 gal; XR3135C, XR3135HC (cab): 12.4 gal 10.6 gal Coolant Capacity 1.9 gal Not Published Crankcase Capacity 1.5 gal Not Published Transmission / Hydraulic System Capacity 7.9 gal Not Published Front Axle Fluid Capacity 1.7 gal Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm (3-speed 540/750/1000 optional) Standard (540 rpm) Mid-PTO Availability Optional, 2000 rpm Available (option) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,808 lb 1,808 lb Hitch Lift Capacity (at 24”) 1,433 lb 1,433 lb Lift Control Type Position and draft control Position control ▶ Transmission & DrivetrainTransmission Type XR3135, XR3135C (gear): Synchro shuttle; XR3135H, XR3135HC (HST): HST HST No. of Speeds XR3135, XR3135C (gear): F12 x R12; XR3135H, XR3135HC (HST): 3 ranges (HST) 3 ranges Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Mechanical: dry single clutch; HST: not applicable Not Published Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Mechanical differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet, multi-disc Wet, multi-disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 62 in 66 in Wheelbase 69 in 69 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 9.2 ft (with brake applied) 11.5 ft (3.5 m) Height to Top of ROPS 94 in 95 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 86.6 in Not Published Overall Length 128.3 in (bumper to link) 125 in (frame to link) ▶ WeightTractor Weight (Base) XR3135 (gear, ROPS): 3,175 lb; XR3135H (HST, ROPS): 3,285 lb; XR3135C (gear, cab): 3,589 lb; XR3135HC (HST, cab): 3,655 lb 3,254 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, industrial or turf tires at no additional cost Ag, Industrial, VT and Turf; VT same size as Industrial R1 Agricultural - Front 7-14 7-14 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 25x8.5-14 25x8.50-14 R3 Turf - Rear 41x14-20 41x14.00-20 R4 Industrial - Front 25x8.5-14 27x8.50-15 R4 Industrial - Rear 43x16-20 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System LL3106, LL3116: quick attach, skid steer compatible LL3003: ISO 24410 Quick Attaching Coupler Loader Model LL3106; LL3116 LL3003, LL3004 Loader Lift Height LL3106: 92.7 in; LL3116: 94.4 in LL3003, LL3004: 94.3 in Loader Lift Capacity (Full Height) LL3106: 2,178 lb; LL3116: 2,185 lb (at pivot pin) LL3003, LL3004: 2,063 lb (at pivot pin, maximum height) Loader Breakout Force LL3106: 3,450 lb; LL3116: 3,612 lb (at pivot pin) LL3003, LL3004: 3,723 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 6-year limited warranty Two-year bumper to bumper; six-year limited powertrain
