▶ EngineEngine Manufacturer LS LS Mtron Engine Model L3C19-T4 Not Published Engine Type 4-stroke, vertical, water cooling, CRDI 3-cylinder, turbocharged diesel, Tier 4 B/Final No. of Cylinders 3 3 Displacement 114.7 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 40 hp 40 hp PTO Power Not Published 34.8 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled Not Published Air Cleaner Dry Not Published Fuel System Delphi CRDI (Common Rail Direct Injection) Not Published Alternator 70 A, 12 V 85 A, 12 V ▶ HydraulicsPump Type Gear pump type, engine drive Not Published Implement Flow 7.8 gpm 8.4 gpm Steering Flow 4.1 gpm (mechanical); 5.5 gpm (HST) Not Published Total Hydraulic Flow Not Published 13.3 gpm Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 0 No. of Optional Remote Valves Not Published 3 ▶ Fluid CapacityFuel Tank Capacity 10.6 gal (roll-bar); 12.4 gal (cabin) 12.6 gal Coolant Capacity 1.9 gal Not Published Crankcase Capacity 1.5 gal Not Published Transmission / Hydraulic System Capacity 7.9 gal Not Published Front Axle Fluid Capacity 1.7 gal Not Published ▶ PTO & HitchPTO Type Independent PTO with wet disk clutch Independent, electro-hydraulic engagement PTO Rear 540 (standard); 540 / 750 / 1,000 (optional 3-speed) 540 rpm Mid-PTO Availability Optional, 2000 rpm Not available Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,808 lb Not Published Hitch Lift Capacity (at 24”) 1,433 lb 1,596 lb Lift Control Type Position and draft control Mechanical Draft Control (MDC) ▶ Transmission & DrivetrainTransmission Type Synchro-shuttle (mechanical) 3-range hydrostatic (optional) No. of Speeds F12 x R12 3 ranges Max Travel Speed (Forward) 14.33 mph 14.8 mph (with R4 tires) Max Travel Speed (Reverse) 13.63 mph Not Published Clutch Dry single clutch (mechanical only) n/a (no clutch on hydrostatic) Differential Lock & Limited Slip Options Mechanical pedal type differential lock Mechanical differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Not Published Brakes Wet disc Not Published Seat Suspension & Adjustability Not Published Adjustable suspension seat Front Axle Type Not Published Mechanical Front Drive (MFD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 62 in 66.5 in Wheelbase 69 in 66.2 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 9.2 ft (with brake applied) 10.5 ft Height to Top of ROPS Not Published 96.2 in Height to Top of ROPS (folded) Not Published 74.2 in Height to Top of Cab Model 86.6 in Not Published Overall Length 128.3 in (bumper to link) 119.4 in ▶ WeightTractor Weight (Base) Roll-bar: 3,175 lb; Cabin: 3,615 lb 3,053 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag 7-14 / 11.2-24; Turf 25x8.5-14 / 41x14-20; Industrial 25x8.5-14 / 43x16-20 R1 Agricultural, R3 Turf, or R4 Industrial R1 Agricultural - Front 7-14 (4PR) 7x14 R1 Agricultural - Rear 11.2-24 (8PR) 11.2x24 R3 Turf - Front 25x8.5-14 25x8.50-14 R3 Turf - Rear 41x14-20 41x14.00-20 R4 Industrial - Front 25x8.5-14 25x8.50-14 R4 Industrial - Rear 43x16-20 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model LL3106 L340A Loader Lift Height LL3106: 92.7 in 98 in Loader Lift Capacity (Full Height) LL3106: 2,178 lb (at pivot pin) 890 lb at 31.5 in. forward of pivot pin Loader Breakout Force LL3106: 3,450 lb (at pivot pin) 1,900 lb ▶ WarrantyWarranty Length & Coverage General: 2 years or 750 hours (whichever occurs first). Extended powertrain: 6 years or 1,500 hours (whichever occurs first), for tractors retailed after January 1, 2017 Basic 2 years; powertrain 4 additional years (6-year total)
