▶ EngineEngine Manufacturer Shibaura (ISM) LS Mtron Engine Model N844L-F L3C19-T4 Engine Type 4-cylinder, indirect injection, water-cooled diesel 3-cylinder, turbocharged diesel, Tier 4 B/Final No. of Cylinders 4 3 Displacement 135.2 in³ 116 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 40 hp 40 hp PTO Power XR4040, XR4040C (gear): 32.4 hp; XR4040H, XR4040HC (HST): 30.8 hp 32 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Pressurized liquid cooling with recirculating bypass Air Cleaner Dry Not Published Fuel System Indirect injection High pressure common rail Alternator 85 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Gear pump, engine driven Gear Implement Flow 8.2 gpm 8.2 gpm Steering Flow XR4040, XR4040C (gear): 4.2 gpm; XR4040H, XR4040HC (HST): 5.5 gpm 5.3 gpm Total Hydraulic Flow XR4040, XR4040C (gear): 12.4 gpm; XR4040H, XR4040HC (HST): 13.7 gpm 13.5 gpm (8.2 + 5.3, computed) (8.2 + 4.2, computed) Overall Hydraulic Pump Flow XR4040, XR4040C (gear): 12.4 gpm; XR4040H, XR4040HC (HST): 13.7 gpm Not Published Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 pairs (4 front outlets, 4 rear outlets) 0 No. of Optional Remote Valves 1 or 3 optional (2 or 6 quick couplers) 1 ▶ Fluid CapacityFuel Tank Capacity XR4040, XR4040H (ROPS): 10.5 gal; XR4040C, XR4040HC (cab): 12.4 gal 7.4 gal Coolant Capacity 2.0 gal 7.5 qt Crankcase Capacity 1.5 gal 5.8 qt Transmission / Hydraulic System Capacity 11.4 gal 8.5 gal Front Axle Fluid Capacity 2.1 gal 6.9 qt ▶ PTO & HitchPTO Type Independent Independent, electro-hydraulic engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional, 2000 rpm Optional, 2,000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,756 lb 1,808 lb Hitch Lift Capacity (at 24”) 2,469 lb 1,433 lb Lift Control Type Position and draft control Mechanical Draft Control (MDC) ▶ Transmission & DrivetrainTransmission Type XR4040, XR4040C (gear): Synchro shuttle; XR4040H, XR4040HC (HST): HST 3-range hydrostatic (optional) No. of Speeds XR4040, XR4040C (gear): F16 x R16; XR4040H, XR4040HC (HST): 3 ranges (HST) infinite, 3 ranges Max Travel Speed (Forward) Not Published 14.8 mph Max Travel Speed (Reverse) Not Published 14.96 mph Clutch Mechanical: dry single clutch; HST: not applicable Dry clutch Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Mechanical differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Wet, multi-disc Wet disc, mechanical actuation Seat Suspension & Adjustability Not Published Adjustable suspension seat Front Axle Type Not Published Mechanical Front Drive (MFD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 129.4 in 145.2 in Overall Width 62.4 in 66.5 in Wheelbase 69.4 in 67.2 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 9.5 ft (with brake applied) 123 in Height to Top of ROPS 96.3 in 87.6 in Height to Top of ROPS (folded) Not Published 68.2 in Height to Top of Cab Model 91.1 in Not Published ▶ WeightTractor Weight (Base) XR4040, XR4040H (ROPS): 3,870 lb; XR4040C, XR4040HC (cab): 4,330 lb 3,067 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, industrial or turf tires at no additional cost R1 agricultural, R3 turf, or R4 industrial (R4 standard) R1 Agricultural - Front 9.5-16 7x14 R1 Agricultural - Rear 13.6-24 11.2x24 R3 Turf - Front 28x8.5-15 25x8.50-14 R3 Turf - Rear 41x14-20 41x14.00-20 R4 Industrial - Front 12-16.5 25x8.50-14 R4 Industrial - Rear 17.5L-24 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System LL4102: quick attach, skid steer compatible Not Published Loader Model LL4102 L340A Loader Lift Height LL4102: 96.1 in 98.4 in Loader Lift Capacity (Full Height) LL4102: 2,500 lb 1,250 lb Loader Breakout Force LL4102: 4,354 lb 1913 lb ▶ WarrantyWarranty Length & Coverage 5-year limited warranty 6-year extended warranty: 2 years bumper-to-bumper plus 4 additional years of powertrain protection
