▶ EngineEngine Manufacturer Shibaura (ISM) LS Engine Model N844L-F L3C19-T Engine Type 4-cylinder, indirect injection, water-cooled diesel 3-cylinder, liquid-cooled, diesel, naturally aspirated, CRDI No. of Cylinders 4 3 Displacement 135.2 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 40 hp 40 hp PTO Power XR4040, XR4040C (gear): 32.4 hp; XR4040H, XR4040HC (HST): 30.8 hp 34 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry Dry Fuel System Indirect injection CRDI (Delphi common rail direct injection) Alternator 85 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Gear pump, engine driven Gear pump, engine driven Implement Flow 8.2 gpm 8.2 gpm Steering Flow XR4040, XR4040C (gear): 4.2 gpm; XR4040H, XR4040HC (HST): 5.5 gpm 5.5 gpm Total Hydraulic Flow XR4040, XR4040C (gear): 12.4 gpm; XR4040H, XR4040HC (HST): 13.7 gpm 13.7 gpm Overall Hydraulic Pump Flow XR4040, XR4040C (gear): 12.4 gpm; XR4040H, XR4040HC (HST): 13.7 gpm 13.7 gpm Hydraulic System Type Not Published Open center system, position control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 pairs (4 front outlets, 4 rear outlets) 0 No. of Optional Remote Valves 1 or 3 optional (2 or 6 quick couplers) 1 or 2 pairs (optional) ▶ Fluid CapacityFuel Tank Capacity XR4040, XR4040H (ROPS): 10.5 gal; XR4040C, XR4040HC (cab): 12.4 gal 7.4 gal Coolant Capacity 2.0 gal 1.9 gal Crankcase Capacity 1.5 gal 1.5 gal Transmission / Hydraulic System Capacity 11.4 gal 8.5 gal Front Axle Fluid Capacity 2.1 gal 1.7 gal ▶ PTO & HitchPTO Type Independent Independent (wet disc clutch) PTO Rear 540 rpm Standard (540 rpm) Mid-PTO Availability Optional, 2000 rpm Optional (2,000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,756 lb 1,808 lb Hitch Lift Capacity (at 24”) 2,469 lb 1,433 lb Lift Control Type Position and draft control Position control ▶ Transmission & DrivetrainTransmission Type XR4040, XR4040C (gear): Synchro shuttle; XR4040H, XR4040HC (HST): HST Synchro Shuttle No. of Speeds XR4040, XR4040C (gear): F16 x R16; XR4040H, XR4040HC (HST): 3 ranges (HST) F12 x R12 Max Travel Speed (Forward) Not Published 14.33 mph Max Travel Speed (Reverse) Not Published 13.63 mph Clutch Mechanical: dry single clutch; HST: not applicable Dry single clutch Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Mechanical pedal type ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet, multi-disc Wet, multi-disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Front wheel mechanical assist (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 129.4 in 121 in Overall Width 62.4 in 54 in (R1); 66 in (R4) Wheelbase 69.4 in 69 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 9.5 ft (with brake applied) 10.79 ft (left); 11.02 ft (right) Height to Top of ROPS 96.3 in 88 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 91.1 in Not Published ▶ WeightTractor Weight (Base) XR4040, XR4040H (ROPS): 3,870 lb; XR4040C, XR4040HC (cab): 4,330 lb 2,881 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, industrial or turf tires at no additional cost R1 agricultural, R4 industrial or R3 turf at no extra cost R1 Agricultural - Front 9.5-16 7-14 R1 Agricultural - Rear 13.6-24 11.2-24 R3 Turf - Front 28x8.5-15 25x8.50-14 R3 Turf - Rear 41x14-20 41x14-20 R4 Industrial - Front 12-16.5 25x8.50-14 R4 Industrial - Rear 17.5L-24 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System LL4102: quick attach, skid steer compatible Not Published Loader Model LL4102 LL3302 Loader Lift Height LL4102: 96.1 in LL3302: 94 in Loader Lift Capacity (Full Height) LL4102: 2,500 lb LL3302: 2,153 lb (at pivot pin, full height) Loader Breakout Force LL4102: 4,354 lb LL3302: 3,579 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 5-year limited warranty 6-year limited warranty
