▶ EngineEngine Manufacturer Shibaura (ISM) LS Mtron Engine Model N844L-F L3C19-T Engine Type 4-cylinder, indirect injection, water-cooled diesel 3 Cylinder, Liquid-cooled, Diesel, TC, CRDI No. of Cylinders 4 3 Displacement 135.2 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 40 hp 42 hp PTO Power XR4040, XR4040C (gear): 32.4 hp; XR4040H, XR4040HC (HST): 30.8 hp 35.7 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry Dry Fuel System Indirect injection Common rail direct injection (CRDI) Alternator 85 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Gear pump, engine driven Not Published Implement Flow 8.2 gpm 8.2 gpm Steering Flow XR4040, XR4040C (gear): 4.2 gpm; XR4040H, XR4040HC (HST): 5.5 gpm 4.1 gpm Total Hydraulic Flow XR4040, XR4040C (gear): 12.4 gpm; XR4040H, XR4040HC (HST): 13.7 gpm 12.3 gpm Overall Hydraulic Pump Flow XR4040, XR4040C (gear): 12.4 gpm; XR4040H, XR4040HC (HST): 13.7 gpm 12.3 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 pairs (4 front outlets, 4 rear outlets) 2 Pair (1 Detent, 1 STD) No. of Optional Remote Valves 1 or 3 optional (2 or 6 quick couplers) Not Published ▶ Fluid CapacityFuel Tank Capacity XR4040, XR4040H (ROPS): 10.5 gal; XR4040C, XR4040HC (cab): 12.4 gal 10.6 gal Coolant Capacity 2.0 gal Not Published Crankcase Capacity 1.5 gal 6.2 qt Transmission / Hydraulic System Capacity 11.4 gal Not Published Front Axle Fluid Capacity 2.1 gal Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional, 2000 rpm Optional (2,000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,756 lb 2,755 lb Hitch Lift Capacity (at 24”) 2,469 lb 2,469 lb Lift Control Type Position and draft control Position & Draft ▶ Transmission & DrivetrainTransmission Type XR4040, XR4040C (gear): Synchro shuttle; XR4040H, XR4040HC (HST): HST Synchro shuttle No. of Speeds XR4040, XR4040C (gear): F16 x R16; XR4040H, XR4040HC (HST): 3 ranges (HST) F16 x R16 Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Mechanical: dry single clutch; HST: not applicable Not Published Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic Power Steering Brakes Wet, multi-disc Wet, Multi-disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Mechanical front-wheel drive (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 129.4 in 133 in Overall Width 62.4 in 62.5 in Wheelbase 69.4 in 73.2 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 9.5 ft (with brake applied) Not Published Height to Top of ROPS 96.3 in 95 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 91.1 in Not Published ▶ WeightTractor Weight (Base) XR4040, XR4040H (ROPS): 3,870 lb; XR4040C, XR4040HC (cab): 4,330 lb 3,869 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, industrial or turf tires at no additional cost R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 9.5-16 9.5-16 R1 Agricultural - Rear 13.6-24 13.6-24 R3 Turf - Front 28x8.5-15 28x8.5-15 R3 Turf - Rear 41x14-20 41x14-20 R4 Industrial - Front 12-16.5 12-16.5 R4 Industrial - Rear 17.5L-24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System LL4102: quick attach, skid steer compatible LL4106, LL4001: 2 lever skid steer coupler (universal skid steer attachments) Loader Model LL4102 LL4106; LL4001 Loader Lift Height LL4102: 96.1 in LL4106: 94.4 in; LL4001: 104.3 in Loader Lift Capacity (Full Height) LL4102: 2,500 lb LL4106: 2,680 lb; LL4001: 2,998 lb Loader Breakout Force LL4102: 4,354 lb LL4106: 4,063 lb; LL4001: 4,295 lb ▶ WarrantyWarranty Length & Coverage 5-year limited warranty 6-year limited powertrain warranty
