▶ EngineEngine Manufacturer Shibaura (ISM) LS Engine Model N844L-F L3C19-T4 Engine Type 4-cylinder, indirect injection, water-cooled diesel 4-stroke, vertical, water cooling, CRDI No. of Cylinders 4 3 Displacement 135.2 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 40 hp 40 hp PTO Power XR4040, XR4040C (gear): 32.4 hp; XR4040H, XR4040HC (HST): 30.8 hp 34.4 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Water-cooled Water-cooled Air Cleaner Dry Dry Fuel System Indirect injection Delphi CRDI (Common Rail Direct Injection) Alternator 85 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Gear pump, engine driven Gear pump type, engine drive Implement Flow 8.2 gpm 8.2 gpm Steering Flow XR4040, XR4040C (gear): 4.2 gpm; XR4040H, XR4040HC (HST): 5.5 gpm 4.1 gpm (mechanical); 5.5 gpm (HST) Total Hydraulic Flow XR4040, XR4040C (gear): 12.4 gpm; XR4040H, XR4040HC (HST): 13.7 gpm 12.3 gpm Overall Hydraulic Pump Flow XR4040, XR4040C (gear): 12.4 gpm; XR4040H, XR4040HC (HST): 13.7 gpm Not Published Hydraulic System Type Not Published Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 pairs (4 front outlets, 4 rear outlets) 2 No. of Optional Remote Valves 1 or 3 optional (2 or 6 quick couplers) Not Published ▶ Fluid CapacityFuel Tank Capacity XR4040, XR4040H (ROPS): 10.5 gal; XR4040C, XR4040HC (cab): 12.4 gal 10.6 gal (roll-bar); 12.4 gal (cabin) Coolant Capacity 2.0 gal 2.3 gal Crankcase Capacity 1.5 gal 1.6 gal Transmission / Hydraulic System Capacity 11.4 gal 11.4 gal Front Axle Fluid Capacity 2.1 gal 2.1 gal ▶ PTO & HitchPTO Type Independent Independent PTO with wet disk clutch PTO Rear 540 rpm 540 (standard); 540 / 750 / 1,000 (optional 3-speed) Mid-PTO Availability Optional, 2000 rpm Yes, 2000 rpm mid-PTO Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,756 lb 2,756 lb Hitch Lift Capacity (at 24”) 2,469 lb 2,469 lb Lift Control Type Position and draft control Position and draft control ▶ Transmission & DrivetrainTransmission Type XR4040, XR4040C (gear): Synchro shuttle; XR4040H, XR4040HC (HST): HST Synchro-shuttle (mechanical) No. of Speeds XR4040, XR4040C (gear): F16 x R16; XR4040H, XR4040HC (HST): 3 ranges (HST) F16 x R16 (F32 x R16 with creeper, optional) Max Travel Speed (Forward) Not Published 16.8 mph Max Travel Speed (Reverse) Not Published 15.3 mph Clutch Mechanical: dry single clutch; HST: not applicable Dry single clutch (mechanical only) Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Mechanical pedal type differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic Brakes Wet, multi-disc Wet disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 129.4 in 133 in Overall Width 62.4 in 62.5 in Wheelbase 69.4 in 73.2 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 9.5 ft (with brake applied) 9.5 ft (with brake applied) Height to Top of ROPS 96.3 in 93 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 91.1 in 92 in ▶ WeightTractor Weight (Base) XR4040, XR4040H (ROPS): 3,870 lb; XR4040C, XR4040HC (cab): 4,330 lb Roll-bar: 3,770 lb; Cabin: 4,210 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, industrial or turf tires at no additional cost Ag 9.5-16 / 13.6-24; Turf 28x8.5-15 / 41x14-20; Industrial 12-16.5 / 17.5L-24 R1 Agricultural - Front 9.5-16 9.5-16 (6PR) R1 Agricultural - Rear 13.6-24 13.6-24 (8PR) R3 Turf - Front 28x8.5-15 28x8.5-15 R3 Turf - Rear 41x14-20 41x14-20 R4 Industrial - Front 12-16.5 12-16.5 R4 Industrial - Rear 17.5L-24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System LL4102: quick attach, skid steer compatible Not Published Loader Model LL4102 LL4104 Loader Lift Height LL4102: 96.1 in LL4104: 96.3 in Loader Lift Capacity (Full Height) LL4102: 2,500 lb LL4104: 2,713 lb Loader Breakout Force LL4102: 4,354 lb LL4104: 3,802 lb ▶ WarrantyWarranty Length & Coverage 5-year limited warranty 6-year / 1,500-hour limited powertrain warranty; 2-year / 750-hour bumper-to-bumper warranty
