▶ EnginePTO Power n/a 15 hp Alternator n/a 40 A, 12 V Air Cleaner n/a Replaceable paper elements Engine Type n/a 3-cylinder, Indirect-injection, Water-cooled Fuel System n/a Mechanical, in-line type Displacement n/a 68 in³ No. of Cylinders n/a 3 Rated Engine Speed n/a 3000 rpm Cooling System Type n/a Water-cooled Engine Manufacturer n/a Yanmar Engine Power (Gross) n/a 21.5 hp Engine Emissions Constraints n/a Tier 4 ▶ WeightTractor Weight (Base) n/a 1,433 lbs Weight with ROPS and Loader n/a Not Published Weight with Cab and Loader n/a Not Applicable ▶ WarrantyWarranty Length & Coverage n/a 6 Year Limited Warranty ▶ HydraulicsPump Type n/a Gear Steering Flow n/a 2.1 gpm Implement Flow n/a 4.6 gpm Total Hydraulic Flow n/a 6.7 gpm Hydraulic System Type n/a Open center system, Position control System Operating Pressure n/a 1,885.5 psi Rear Remote Hydraulic Flow n/a Not Published Overall Hydraulic Pump Flow n/a 6.7 gpm No. of Optional Remote Valves n/a 1 No. of Standard Remote Valves n/a 0 ▶ PTO & HitchPTO Rear n/a Standard (540 rpm) PTO Type n/a Independent Lift Control Type n/a Position Hitch Lift Capacity n/a 970 lbs. (At 24 in: 728) Mid-PTO Availability n/a Standard (2,500 rpm) Category, 3-Point Hitch n/a CAT I Hitch Lift Capacity (at 24”) n/a 728 lb ▶ Tire OptionsR3 Turf - Rear n/a 26 x 12.0 - 12 R3 Turf - Front n/a 18 x 8.5 - 10 Tire Size & Options n/a Front: 18x8.5-10 Industrial; Rear: 26x12.0-12 Industrial R4 Industrial - Rear n/a 26 x 12.0 - 12 R4 Industrial - Front n/a 18 x 8.5 - 10 R1 Agricultural - Rear n/a Not Published R1 Agricultural - Front n/a Not Published ▶ Fluid CapacityCoolant Capacity n/a 0.9 gal (0.9U.S.gals) Crankcase Capacity n/a 0.8 gal (0.8U.S.gals) Fuel Tank Capacity n/a 6.6 gal. Front Axle Fluid Capacity n/a 0.5 gal (0.5U.S.gals) Transmission / Hydraulic System Capacity n/a 3 gal (3.0U.S.gals) ▶ Loader & AttachmentsLoader Lift Height n/a 72.0 in. Loader Breakout Force n/a 1,960 lbs. Quick Attach Loader System n/a LL1101: Pin-Type Bucket (standard); Quick Attach Assembly (Optional) - Compact Type (dual-lever LH/RH); LL1700: Quick Attach Implement System Loader Lift Capacity (Full Height) n/a 1,007 lbs. ▶ Transmission & DrivetrainClutch n/a Not Applicable No. of Speeds n/a 2 Ranges Transmission Type n/a Hydrostatic Drive Max Travel Speed (Forward) n/a 0 ~ 14.0 Km/h (0 ~ 8.70 mph) Max Travel Speed (Reverse) n/a 0 ~ 8.4 Km/h (0 ~ 5.22 mph) Differential Lock & Limited Slip Options n/a Mechanical pedal type ▶ Chassis, Steering & ControlsBrakes n/a Wet, Multi-disc Steering n/a Hydrostatic Power Steering Frame Type n/a Not Published Front Axle Type n/a Front Wheel Mechanical Assist (4WD) Drawbar Capacity n/a Vertical load: 881.8 lb (882lbs), Horizontal load: 1.6 tonnes (3527lbs) Front Axle Rating n/a 1433 lb Seat Suspension & Adjustability n/a High-Back Seat with Foldable Armrest and Retractable Seatbelt; fore/aft adjustable ▶ Dimensions & ManeuverabilityWheelbase n/a 56 in. Overall Width n/a 47 in. Overall Length n/a 97 in. Ground Clearance n/a Not provided in source Height to Top of ROPS n/a 87 in. Height to Top of Cab Model n/a Not Applicable Height to Top of ROPS (folded) n/a Not Published Min. Turn Radius without Brakes n/a 7.87 ft Overall Length with 3-Point Hitch n/a 97 in.
