▶ EngineEngine Manufacturer LS Mtron LS Mtron Engine Model L3C19-T2 L3C19-T Engine Type 4-stroke, vertical, water cooling, CRDI 3 Cylinder, Liquid-cooled, Diesel, TC, CRDI No. of Cylinders 3 3 Displacement 114.7 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 50 hp 52 hp PTO Power 43 hp 41.6 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry Dry Fuel System Delphi CRDI (Common Rail Direct Injection) Common rail direct injection (CRDI) Alternator 70 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Gear pump type, engine drive Not Published Implement Flow 8.2 gpm 8.2 gpm Steering Flow 4.1 gpm (mechanical); 6.2 gpm (HST) 4.1 gpm Total Hydraulic Flow 12.3 gpm 12.3 gpm Overall Hydraulic Pump Flow Not Published 12.3 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 pairs 2 Pair (1 Detent, 1 STD) No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 10.6 gal (roll-bar); 12.4 gal (cabin) 10.6 gal Coolant Capacity 2.3 gal Not Published Crankcase Capacity 1.6 gal 6.2 qt Transmission / Hydraulic System Capacity 11.4 gal Not Published Front Axle Fluid Capacity 2.1 gal Not Published ▶ PTO & HitchPTO Type Independent PTO with wet disk clutch Independent PTO Rear 540 (standard); 540 / 750 / 1,000 (optional 3-speed) 540 rpm Mid-PTO Availability Optional, 2000 rpm Optional (2,000 rpm) Category, 3-Point Hitch Category I Category II Hitch Lift Capacity 2,756 lb 2,755 lb Hitch Lift Capacity (at 24”) 2,469 lb 2,469 lb Lift Control Type Position and draft control Position & Draft ▶ Transmission & DrivetrainTransmission Type Synchro-shuttle (mechanical) Synchro shuttle No. of Speeds F16 x R16 (F32 x R16 with creeper, optional) F16 x R16 Max Travel Speed (Forward) 16.8 mph Not Published Max Travel Speed (Reverse) 15.3 mph Not Published Clutch Dry single clutch (mechanical only) Not Published Differential Lock & Limited Slip Options Mechanical pedal type differential lock Mechanical differential lock (pedal type) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic Power Steering Brakes Wet, multi-disc Wet, Multi-disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Mechanical front-wheel drive (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 62.5 in 62.5 in Wheelbase 73.2 in 73.2 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 9.5 ft (with brake applied) Not Published Height to Top of ROPS 93 in H: 95 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 88.1 in Not Applicable Overall Length 133 in (bumper to link) 133 in (frame to link) ▶ WeightTractor Weight (Base) Roll-bar: 3,770 lb; Cabin: 4,210 lb 3,869 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Applicable ▶ Tire OptionsTire Size & Options Ag 9.5-16 / 13.6-24; Turf 28x8.5-15 / 41x14-20; Industrial 12-16.5 / 17.5L-24 Agricultural, Turf, Industrial R1 Agricultural - Front 9.5-16 (6PR) 9.5-16 R1 Agricultural - Rear 13.6-24 (8PR) 13.6-24 R3 Turf - Front 28x8.5-15 28x8.5-15 R3 Turf - Rear 41x14-20 41x14-20 R4 Industrial - Front 12-16.5 12-16.5 R4 Industrial - Rear 17.5L-24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published LL4106, LL4001: 2-lever skid-steer coupler, fits universal skid-steer attachments Loader Model LL4104 LL4106; LL4001 Loader Lift Height LL4104: 96.3 in LL4106: 94.4 in; LL4001: 104.3 in Loader Lift Capacity (Full Height) LL4104: 2,713 lb (at pivot pin) LL4106: 2,680 lb (at pivot pin); LL4001: 2,998 lb (at pivot pin) Loader Breakout Force LL4104: 3,802 lb (at pivot pin) LL4106: 4,063 lb (at pivot pin); LL4001: 4,295 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage General: 2 years or 750 hours (whichever occurs first). Extended powertrain: 6 years or 1,500 hours (whichever occurs first), for tractors retailed after January 1, 2017 6-year limited powertrain warranty
