▶ EngineEngine Manufacturer LS Mtron LS Mtron Engine Model L3C19-T2 L3CRV-T8 Engine Type 4-stroke, vertical, water cooling, CRDI 3-cylinder, turbocharged, liquid-cooled diesel No. of Cylinders 3 3 Displacement 114.7 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 50 hp 50 hp PTO Power 43 hp Gear: 42.5 hp; HST: 40 hp Engine Emissions Constraints Not Published Tier 4B (final) Cooling System Type Water-cooled Liquid cooled Air Cleaner Dry Replaceable primary and inner elements Fuel System Delphi CRDI (Common Rail Direct Injection) Electronically controlled common rail direct injection Alternator 70 A, 12 V ROPS: 70 A; Cab: 85 A ▶ HydraulicsPump Type Gear pump type, engine drive Gear Implement Flow 8.2 gpm 8.2 gpm Steering Flow 4.1 gpm (mechanical); 6.2 gpm (HST) Gear: 4.2 gpm; HST: 5.3 gpm Total Hydraulic Flow 12.3 gpm Gear: 12.4 gpm; HST: 13.5 gpm Overall Hydraulic Pump Flow Not Published Gear: 12.4 gpm; HST: 13.5 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 pairs 1 No. of Optional Remote Valves Not Published Up to 2 (second valve optional) ▶ Fluid CapacityFuel Tank Capacity 10.6 gal (roll-bar); 12.4 gal (cabin) ROPS: 10.5 gal; Cab: 12.4 gal Coolant Capacity 2.3 gal 2.3 gal Crankcase Capacity 1.6 gal 5.8 qt Transmission / Hydraulic System Capacity 11.4 gal 11.4 gal Front Axle Fluid Capacity 2.1 gal 2.2 gal ▶ PTO & HitchPTO Type Independent PTO with wet disk clutch Independent, electro-hydraulic engagement PTO Rear 540 (standard); 540 / 750 / 1,000 (optional 3-speed) 540 rpm Mid-PTO Availability Optional, 2000 rpm Standard (2000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,756 lb 2,756 lb Hitch Lift Capacity (at 24”) 2,469 lb 2,116 lb Lift Control Type Position and draft control Position control (draft control optional) ▶ Transmission & DrivetrainTransmission Type Synchro-shuttle (mechanical) Gear: 16x16 synchronized shuttle shift (SSS); HST: 3-range hydrostatic, dual pedal No. of Speeds F16 x R16 (F32 x R16 with creeper, optional) Gear: 16F/16R; HST: 3-range Max Travel Speed (Forward) 16.8 mph Gear: 17.0 mph; HST: 17.9 mph Max Travel Speed (Reverse) 15.3 mph Gear: 15.3 mph; HST: 11.37 mph Clutch Dry single clutch (mechanical only) Gear: dry single disc (10.8 in); HST: n/a Differential Lock & Limited Slip Options Mechanical pedal type differential lock Mechanical rear differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power steering Brakes Wet, multi-disc Wet multi-disc Seat Suspension & Adjustability Not Published ROPS: adjustable suspension seat (fore/aft, weight and height adjustment); Cab: cloth suspension seat with weight control, fore/aft adjustment and adjustable armrests Front Axle Type Not Published Four-wheel drive (FWD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Short position: 2,317 lb; Regular position: 1,598 lb; Extended position: 1,091 lb ▶ Dimensions & ManeuverabilityOverall Width 62.5 in 69.1 in Wheelbase 73.2 in 73.2 in Ground Clearance Not Published 15 in Min. Turn Radius without Brakes 9.5 ft (with brake applied) 111.8 in (right turn); 123.2 in (left turn) (with brake applied) Height to Top of ROPS 93 in 97.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 88.1 in 94 in Overall Length 133 in (bumper to link) 128.1 in ▶ WeightTractor Weight (Base) Roll-bar: 3,770 lb; Cabin: 4,210 lb ROPS Gear: 3,424 lb; ROPS HST: 3,490 lb; Cab: 4,194 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag 9.5-16 / 13.6-24; Turf 28x8.5-15 / 41x14-20; Industrial 12-16.5 / 17.5L-24 R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 9.5-16 (6PR) 9.5-16 R1 Agricultural - Rear 13.6-24 (8PR) 13.6-24 R3 Turf - Front 28x8.5-15 28x8.50-15 R3 Turf - Rear 41x14-20 41x14.00-20 R4 Industrial - Front 12-16.5 12x16.5 R4 Industrial - Rear 17.5L-24 17.5Lx24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Tool-free loader mount; optional skid-steer quick-attach plates Loader Model LL4104 260TLA Loader Lift Height LL4104: 96.3 in 260TLA: 109 in (at pivot pin) Loader Lift Capacity (Full Height) LL4104: 2,713 lb (at pivot pin) 260TLA: 2,371 lb (at bucket pivot pin, max height) Loader Breakout Force LL4104: 3,802 lb (at pivot pin) 260TLA: 4,081 lb (at bucket pivot pin) ▶ WarrantyWarranty Length & Coverage General: 2 years or 750 hours (whichever occurs first). Extended powertrain: 6 years or 1,500 hours (whichever occurs first), for tractors retailed after January 1, 2017 Basic 2 years or 750 hours; powertrain 4 more years (6 years or 1,500 hours total)
