▶ EngineEngine Manufacturer LS Mtron LS Mtron Engine Model L3C19-T1 L3C19-T Engine Type 3-cylinder, turbocharged, common-rail, liquid-cooled diesel 3 Cylinder, Liquid-cooled, Diesel, TC, CRDI No. of Cylinders 3 3 Displacement 114.7 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 55 hp 52 hp PTO Power XR4155, XR4155C (gear): 47.3 hp; XR4155H, XR4155HC (HST): 44 hp 44.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry Dry Fuel System CRDI (common rail direct injection) Common rail direct injection (CRDI) Alternator 70 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Gear pump, engine driven Gear pump, engine drive Implement Flow XR4155, XR4155C (gear): 8.2 gpm; XR4155H, XR4155HC (HST): 7.3 gpm 8.2 gpm Steering Flow XR4155, XR4155C (gear): 4.1 gpm; XR4155H, XR4155HC (HST): 6.2 gpm 4.1 gpm Total Hydraulic Flow XR4155, XR4155C (gear): 12.3 gpm; XR4155H, XR4155HC (HST): 13.7 gpm 12.3 gpm Overall Hydraulic Pump Flow XR4155, XR4155C (gear): 12.3 gpm; XR4155H, XR4155HC (HST): 13.7 gpm 12.3 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 pairs 2 sets, with detent No. of Optional Remote Valves 2 or 6 quick couplers (optional) Not Published ▶ Fluid CapacityFuel Tank Capacity XR4155, XR4155H (ROPS): 10.6 gal; XR4155C, XR4155HC (cab): 12.4 gal PCT: 10.6 gal; PCTC: 12.4 gal Coolant Capacity 2.3 gal 2.3 gal Crankcase Capacity 1.6 gal 1.6 gal Transmission / Hydraulic System Capacity 11.4 gal 11.4 gal Front Axle Fluid Capacity 2.1 gal 2.2 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm (3-speed 540/750/1000 optional) 540 rpm Mid-PTO Availability Optional, 2000 rpm Optional (2,000 rpm) Category, 3-Point Hitch Category I Category II Hitch Lift Capacity 2,755 lb 2,755 lb Hitch Lift Capacity (at 24”) 2,469 lb 2,469 lb Lift Control Type Position and draft control Position & Draft ▶ Transmission & DrivetrainTransmission Type XR4155, XR4155C (gear): Synchro shuttle; XR4155H, XR4155HC (HST): HST Synchro shuttle / Power Clutch No. of Speeds XR4155, XR4155C (gear): F16 x R16; XR4155H, XR4155HC (HST): 3 ranges (HST) F16 x R16 Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Mechanical: dry single clutch; HST: not applicable Power clutch valve & lever (MPC) Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Mechanical pedal type ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic Power Steering Brakes Wet, multi-disc Wet, Multi-disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Mechanical front-wheel drive (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 62.5 in 62.5 in Wheelbase 73.2 in 73.2 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 9.5 ft (with brake applied) 10.3 ft Height to Top of ROPS 93 in PCT: 95 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 88.1 in PCTC: 90 in Overall Length 133 in (bumper to link) 133 in (frame to link) ▶ WeightTractor Weight (Base) ROPS: 3,770 lb; Cab: 4,210 lb PCT: 3,869 lb; PCTC: 4,380 lb Weight with ROPS and Loader Not Published 4,649 lb (3,869 + 780, computed); LL4106 loader without bucket Weight with Cab and Loader Not Published 5,160 lb (4,380 + 780, computed); LL4106 loader without bucket ▶ Tire OptionsTire Size & Options Ag, industrial or turf tires at no additional cost R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 9.5-16 9.5-16 R1 Agricultural - Rear 13.6-24 13.6-24 R3 Turf - Front 28x8.5-15 28x8.5-15 R3 Turf - Rear 41x14-20 41x14-20 R4 Industrial - Front 12-16.5 12-16.5 R4 Industrial - Rear 17.5L-24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System LL4104: quick attach, skid steer compatible LL4106, LL4001: 2-lever skid-steer coupler, fits universal skid-steer attachments Loader Model LL4104 LL4106; LL4001 Loader Lift Height LL4104: 96.3 in LL4106: 94.4 in; LL4001: 104.3 in Loader Lift Capacity (Full Height) LL4104: 2,713 lb (at pivot pin) LL4106: 2,680 lb (at pivot pin); LL4001: 2,998 lb (at pivot pin) Loader Breakout Force LL4104: 3,802 lb (at pivot pin) LL4106: 4,063 lb (at pivot pin); LL4001: 4,295 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 5-year limited warranty 6-year limited powertrain warranty
