▶ EngineEngine Manufacturer LS Mtron John Deere Engine Model L4C25-T2 John Deere PowerTech 3029 Engine Type In-line vertical, Water cooled 4-cycle diesel, CRDI Diesel, turbocharged, liquid-cooled No. of Cylinders 4 3 Displacement 152.86 in³ 179 in³ Rated Engine Speed 2500 rpm 2100 rpm Engine Power (Gross) 68 hp 67 hp PTO Power 60 hp 49 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry Dry type, dual element (primary and secondary) Fuel System CRDI Not Published Alternator 70 A, 12 V 40 A ▶ HydraulicsPump Type Gear type, engine drive Not Published Implement Flow 9.9 gpm 11.4 gpm Steering Flow 4.6 gpm 6.8 gpm Total Hydraulic Flow 14.5 gpm (9.9 + 4.6, computed) 18.2 gpm Overall Hydraulic Pump Flow Not Published 18.2 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 1 No. of Optional Remote Valves Not Published 2 ▶ Fluid CapacityFuel Tank Capacity 21.1 gal 19.6 gal Coolant Capacity 2.4 gal 10 qt Crankcase Capacity 1.8 gal 9 qt Transmission / Hydraulic System Capacity 12.4 gal 10.3 gal Front Axle Fluid Capacity 2.6 gal Dana axle: differential housing 1.18 gal, wheel hub (each) 0.21 gal; Carraro axle: differential housing 1.03 gal, reduction gear oil (each side) 0.15 gal ▶ PTO & HitchPTO Type Independent Independent; mechanical engagement (SyncShuttle); electrohydraulic engagement (PowrReverser) PTO Rear 540 (standard); 540 / 750 / 1,000 (optional 3-speed) 540 rpm (540E optional with PowrReverser) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II, convertible to I Hitch Lift Capacity 4,079 lb Not Published Hitch Lift Capacity (at 24”) 3,483 lb 3,192 lb Lift Control Type Position and draft control Position control with top link draft sensing ▶ Transmission & DrivetrainTransmission Type Synchro-shuttle (standard); Power shuttle (optional) SyncShuttle (standard); PowrReverser (optional) No. of Speeds F16 x R16 9F/3R (SyncShuttle); 12F/12R (PowrReverser optional) Max Travel Speed (Forward) 17.99 mph Not Published Max Travel Speed (Reverse) 14.81 mph Not Published Clutch Dry single clutch (mechanical); wet clutch disks (power shuttle) Dry (SyncShuttle); wet (12F/12R PowrReverser) Differential Lock & Limited Slip Options Mechanical pedal type differential lock Differential lock, standard; pedal-operated, mechanical ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power steering Brakes Wet, multi-disc Hydraulic wet disc brakes Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published 2WD or MFWD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,675 lb (fully extended); 2,470 lb (short position) ▶ Dimensions & ManeuverabilityOverall Width 70 in 57.3 in Wheelbase 80.3 in 80.7 in Ground Clearance Not Published 2WD: 18.8 in; MFWD: 13.4 in Min. Turn Radius without Brakes 10.8 ft (with brake applied) 11.5 ft (2WD); 15.3 ft (4WD); 12.8 ft (4WD, Carraro axle) Height to Top of ROPS 103 in 98.4 in Height to Top of ROPS (folded) Not Published 78.5 in Height to Top of Cab Model 100.6 in 95.6 in Overall Length 138.6 in (bumper to link) 137.8 in ▶ WeightTractor Weight (Base) Roll-bar: 4,674 lb; Cabin: 5,121 lb (without ballast) 2WD: 4,634 lb; MFWD: 5,621 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag 9.5-20 / 16.9-24; Industrial 10.5/80-18 / 19.5L-24; Turf 36x13.5-15 / 16.9-24 Not Published R1 Agricultural - Front 9.5-20 MFWD: 9.5-24; 280/85R24 (11.2R24) R1W Radial R1 Agricultural - Rear 16.9-24 16.9-28 R3 Turf - Front 36x13.5-15 9.5-16 (MFWD) R3 Turf - Rear 16.9-24 21.5L-16.1; 22.5LL-16.1 (Turf Special) R4 Industrial - Front 10.5/80-18 12.5/80-18 (MFWD) R4 Industrial - Rear 19.5L-24 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published 520M; H240 (NSL or MSL) Loader Model LL5106 H240NSL Loader Lift Height LL5106: 116.3 in 131 in Loader Lift Capacity (Full Height) LL5106: 2,981 lb (at pivot pin) 3,671 lb (H240NSL, at pivot) Loader Breakout Force LL5106: 4,767 lb (at pivot pin) 4,504 lb (H240NSL, at pivot) ▶ WarrantyWarranty Length & Coverage General: 2 years or 750 hours (whichever occurs first). Extended powertrain: 6 years or 1,500 hours (whichever occurs first), for tractors retailed after January 1, 2017 Not Published
