▶ EngineEngine Manufacturer LS Mtron KIOTI Engine Model L4C25-T2 4H243T Engine Type In-line vertical, Water cooled 4-cycle diesel, CRDI 4-cylinder, in-line vertical, water-cooled, 4-cycle turbo diesel, CRDI (4H243T) No. of Cylinders 4 4 Displacement 152.86 in³ 148.6 in³ Rated Engine Speed 2500 rpm 2600 rpm Engine Power (Gross) 68 hp 66.4 hp PTO Power 60 hp 54.9 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled Water-cooled Air Cleaner Dry Not Published Fuel System CRDI CRDI Alternator 70 A, 12 V Not Published ▶ HydraulicsPump Type Gear type, engine drive Tandem Gear Implement Flow 9.9 gpm 12.4 gpm Steering Flow 4.6 gpm 8.2 gpm Total Hydraulic Flow 14.5 gpm (9.9 + 4.6, computed) 20.6 gpm Overall Hydraulic Pump Flow Not Published 20.6 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 1 No. of Optional Remote Valves Not Published 2 ▶ Fluid CapacityFuel Tank Capacity 21.1 gal 26.4 gal Coolant Capacity 2.4 gal 2.51 gal Crankcase Capacity 1.8 gal 2.83 gal Transmission / Hydraulic System Capacity 12.4 gal 11.75 gal Front Axle Fluid Capacity 2.6 gal 2.6 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 (standard); 540 / 750 / 1,000 (optional 3-speed) 540 / 540E rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 4,079 lb 5,584 lb Hitch Lift Capacity (at 24”) 3,483 lb 4,328 lb Lift Control Type Position and draft control Electronic Control ▶ Transmission & DrivetrainTransmission Type Synchro-shuttle (standard); Power shuttle (optional) Manual: Power Shuttle No. of Speeds F16 x R16 12 forward / 12 reverse Max Travel Speed (Forward) 17.99 mph 23.9 mph (22.01 mph on AG tires) Max Travel Speed (Reverse) 14.81 mph 23.3 mph (21.92 mph on AG tires) Clutch Dry single clutch (mechanical); wet clutch disks (power shuttle) Wet Disc Differential Lock & Limited Slip Options Mechanical pedal type differential lock Rear differential lock (standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic Power Steering Brakes Wet, multi-disc Wet Multi Disc Seat Suspension & Adjustability Not Published Adjustable Air-Ride Seat Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,984 lb (max. drawbar vertical load) ▶ Dimensions & ManeuverabilityOverall Width 70 in 82.1 in Wheelbase 80.3 in 85.4 in Ground Clearance Not Published 15.7 in Min. Turn Radius without Brakes 10.8 ft (with brake applied) 12.8 ft Height to Top of ROPS 103 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 100.6 in 105.3 in Overall Length 138.6 in (bumper to link) 150.3 in (with 3-point hitch) ▶ WeightTractor Weight (Base) Roll-bar: 4,674 lb; Cabin: 5,121 lb (without ballast) 6,814 lb (with AG tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag 9.5-20 / 16.9-24; Industrial 10.5/80-18 / 19.5L-24; Turf 36x13.5-15 / 16.9-24 Agricultural, Industrial R1 Agricultural - Front 9.5-20 11.2-24 R1 Agricultural - Rear 16.9-24 16.9-30 R3 Turf - Front 36x13.5-15 Not Published R3 Turf - Rear 16.9-24 Not Published R4 Industrial - Front 10.5/80-18 12.5/80-18 R4 Industrial - Rear 19.5L-24 18.4-24/8 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Built-in parking stand; quick attach and detach Loader Model LL5106 KL7340 Loader Lift Height LL5106: 116.3 in KL7340: 127.1 in (to pivot pin) Loader Lift Capacity (Full Height) LL5106: 2,981 lb (at pivot pin) KL7340: 3,384 lb (to full height) Loader Breakout Force LL5106: 4,767 lb (at pivot pin) KL7340: 5,875 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage General: 2 years or 750 hours (whichever occurs first). Extended powertrain: 6 years or 1,500 hours (whichever occurs first), for tractors retailed after January 1, 2017 Non-commercial: basic 24 months, powertrain 48 months, parts and labor
