▶ EngineEngine Manufacturer LS Mtron Kubota Engine Model L4C25-T2 V3307-CR-TE4 Engine Type In-line vertical, Water cooled 4-cycle diesel, CRDI Liquid-cooled, diesel, 4-cylinder, Turbocharged No. of Cylinders 4 4 Displacement 152.86 in³ 203 in³ Rated Engine Speed 2500 rpm 2400 rpm Engine Power (Gross) 68 hp 66.4 hp PTO Power 60 hp 56 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry Dry paper, dual element, 8 in diameter, with pre-cleaner Fuel System CRDI Common Rail System (CRS) Alternator 70 A, 12 V 45 A, 12 V ▶ HydraulicsPump Type Gear type, engine drive Gear Implement Flow 9.9 gpm 11.0 gpm Steering Flow 4.6 gpm 6.1 gpm Total Hydraulic Flow 14.5 gpm (9.9 + 4.6, computed) 17.1 gpm Overall Hydraulic Pump Flow Not Published 17.1 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published 11.0 gpm No. of Standard Remote Valves 2 1 (SCD) No. of Optional Remote Valves Not Published 2nd, 3rd (optional) ▶ Fluid CapacityFuel Tank Capacity 21.1 gal 18.5 gal Coolant Capacity 2.4 gal 8.5 qt Crankcase Capacity 1.8 gal 12.7 qt Transmission / Hydraulic System Capacity 12.4 gal 14.8 gal Front Axle Fluid Capacity 2.6 gal 5.8 qt (differential) plus 3.7 qt (each bevel gear case) ▶ PTO & HitchPTO Type Independent Live-independent PTO, electro-hydraulic clutch with brake PTO Rear 540 (standard); 540 / 750 / 1,000 (optional 3-speed) 540 rpm (540/540E optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II I / II Hitch Lift Capacity 4,079 lb 4,189 lb Hitch Lift Capacity (at 24”) 3,483 lb 3,307 lb Lift Control Type Position and draft control Position, Draft (Top Link Sensing) & Mixed Control ▶ Transmission & DrivetrainTransmission Type Synchro-shuttle (standard); Power shuttle (optional) Hydraulic-shuttle transmission (fully synchronized) No. of Speeds F16 x R16 F8/R8 Max Travel Speed (Forward) 17.99 mph 18.0 mph Max Travel Speed (Reverse) 14.81 mph 17.7 mph Clutch Dry single clutch (mechanical); wet clutch disks (power shuttle) Multiple wet disc Differential Lock & Limited Slip Options Mechanical pedal type differential lock Rear differential lock standard (mechanical) ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS Steering Hydrostatic Hydrostatic power steering Brakes Wet, multi-disc Mechanical wet disc Seat Suspension & Adjustability Not Published Suspension seat, adjustable (travel, suspension tension, backrest tilt, armrests); optional air-suspension seat on cab models Front Axle Type Not Published Bevel gear type with 55 degree turning angle (4WD) Front Axle Rating Not Published 5,290 lb (6,615 lb with loader) Drawbar Capacity Not Published 2,200 lb ▶ Dimensions & ManeuverabilityOverall Width 70 in 73.0 in Wheelbase 80.3 in 83.1 in Ground Clearance Not Published 18.1 in (crop clearance at front axle); 15.4 in (minimum ground clearance) Min. Turn Radius without Brakes 10.8 ft (with brake applied) 11.8 ft Height to Top of ROPS 103 in 96.9 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 100.6 in n/a (ROPS model) Overall Length 138.6 in (bumper to link) 138 in ▶ WeightTractor Weight (Base) Roll-bar: 4,674 lb; Cabin: 5,121 lb (without ballast) 5,005 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag 9.5-20 / 16.9-24; Industrial 10.5/80-18 / 19.5L-24; Turf 36x13.5-15 / 16.9-24 Standard: 9.5-24 front, 16.9-28 rear R1 Agricultural - Front 9.5-20 9.5-24 R1 Agricultural - Rear 16.9-24 16.9-28/14.9-28 R3 Turf - Front 36x13.5-15 LSW305-521 R3 Turf - Rear 16.9-24 LSW570-648 R4 Industrial - Front 10.5/80-18 12.5/80-18 R4 Industrial - Rear 19.5L-24 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published LA1154A: 2-Lever Quick Coupler Loader Model LL5106 LA1154A Loader Lift Height LL5106: 116.3 in Height position: 132.7 in; Power position: 117.2 in Loader Lift Capacity (Full Height) LL5106: 2,981 lb (at pivot pin) Height position: 2,469 lb; Power position: 2,928 lb Loader Breakout Force LL5106: 4,767 lb (at pivot pin) Height position: 4,230 lbf; Power position: 5,354 lbf ▶ WarrantyWarranty Length & Coverage General: 2 years or 750 hours (whichever occurs first). Extended powertrain: 6 years or 1,500 hours (whichever occurs first), for tractors retailed after January 1, 2017 Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
