▶ EngineEngine Manufacturer LS Mtron Yanmar Engine Model L4C25-T2 3TNV80F Engine Type In-line vertical, Water cooled 4-cycle diesel, CRDI 3-cylinder, indirect injection (swirl chamber), water-cooled No. of Cylinders 4 3 Displacement 152.86 in³ 77.3 in³ Rated Engine Speed 2500 rpm 3000 rpm Engine Power (Gross) 68 hp 24.7 hp PTO Power 60 hp 17.2 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled Water-cooled Air Cleaner Dry Dry Fuel System CRDI In-line injection pump Alternator 70 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Gear type, engine drive Gear pump, transmission driven Implement Flow 9.9 gpm 4.6 gpm Steering Flow 4.6 gpm 2.1 gpm Total Hydraulic Flow 14.5 gpm 6.7 gpm Overall Hydraulic Pump Flow Not Published 6.7 gpm Hydraulic System Type Open center Open center system, position control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 0 No. of Optional Remote Valves Not Published 1 pair (2 quick couplers) ▶ Fluid CapacityFuel Tank Capacity 21.1 gal 6.6 gal Coolant Capacity 2.4 gal 0.9 gal Crankcase Capacity 1.8 gal 0.8 gal Transmission / Hydraulic System Capacity 12.4 gal 3.0 gal (3.4 gal with front-end loader; 4.7 gal with front-end loader and backhoe) Front Axle Fluid Capacity 2.6 gal 0.5 gal ▶ PTO & HitchPTO Type Independent Independent (electro-hydraulic) PTO Rear 540 (standard); 540 / 750 / 1,000 (optional 3-speed) Standard (540 rpm) Mid-PTO Availability Not Published Standard (2,500 rpm) Category, 3-Point Hitch Category II Category I Hitch Lift Capacity 4,079 lb 970 lb Hitch Lift Capacity (at 24”) 3,483 lb 728 lb Lift Control Type Position and draft control Position control ▶ Transmission & DrivetrainTransmission Type Synchro-shuttle (standard); Power shuttle (optional) Hydrostatic Drive No. of Speeds F16 x R16 (F32 x R16 with creeper, optional) 2 ranges Max Travel Speed (Forward) 17.99 mph 8.70 mph Max Travel Speed (Reverse) 14.81 mph 5.22 mph Clutch Dry single clutch (mechanical); wet clutch disks (power shuttle) Not Published Differential Lock & Limited Slip Options Mechanical pedal type differential lock Mechanical pedal type ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic power steering Brakes Wet disc Wet, multi-disc Seat Suspension & Adjustability Not Published Forward/backward adjustable via seat F/R adjustment lever; reversible seat optional Front Axle Type Not Published Front wheel mechanical assist (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Hitch: 882 lb vertical, 3,527 lb horizontal; drawbar with clevis: 772 lb vertical, 3,527 lb horizontal ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 138.6 in 97 in Overall Width 70 in 47 in Wheelbase 80.3 in 56 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 10.8 ft (with brake applied) 7.87 ft Height to Top of ROPS 103 in 87 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 100.6 in Not Published ▶ WeightTractor Weight (Base) Roll-bar: 4,586 lb; Cabin: 5,049 lb 1,444 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag 9.5-20 / 16.9-24; Industrial 10.5/80-18 / 19.5L-24; Turf 36x13.5-15 / 16.9-24 Front 18x8.50-10, rear 26x12.0-12; offered in industrial or turf R1 Agricultural - Front 9.5-20 Not Published R1 Agricultural - Rear 16.9-24 Not Published R3 Turf - Front 36x13.5-15 18x8.50-10 R3 Turf - Rear 16.9-24 26x12.0-12 R4 Industrial - Front 10.5/80-18 18x8.50-10 R4 Industrial - Rear 19.5L-24 26x12.0-12 ▶ Loader & AttachmentsQuick Attach Loader System Not Published LL1101 Quick-Attach Front Loader Loader Model LL5106 LL1101; LL1100 Loader Lift Height LL5106: 116 in LL1101: 72.0 in; LL1100: 72.0 in (at pivot pin) Loader Lift Capacity (Full Height) LL5106: 3,351 lb (at pivot pin, 1.5 m height) LL1101: 966 lb; LL1100: 1,005 lb (at pivot pin, maximum height) Loader Breakout Force LL5106: 4,556 lb LL1101: 1,960 lb; LL1100: 2,083 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 6-year / 1,500-hour limited powertrain warranty; 2-year / 750-hour bumper-to-bumper warranty 6-year limited warranty
