▶ EngineEngine Manufacturer LS Mtron Yanmar Engine Model L4C25-T2 3TNV80F-ZXKLST Engine Type In-line vertical, Water cooled 4-cycle diesel, CRDI 3-cylinder, indirect injection (swirl chamber), liquid-cooled No. of Cylinders 4 3 Displacement 152.86 in³ 77.3 in³ Rated Engine Speed 2500 rpm 2800 rpm Engine Power (Gross) 68 hp 24.7 hp PTO Power 60 hp 19.3 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry Dry Fuel System CRDI In-line injection pump Alternator 70 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Gear type, engine drive Gear pump, engine driven Implement Flow 9.9 gpm 5.6 gpm Steering Flow 4.6 gpm 3.7 gpm Total Hydraulic Flow 14.5 gpm 9.3 gpm Overall Hydraulic Pump Flow Not Published 9.3 gpm Hydraulic System Type Open center Open center system, position control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 0 No. of Optional Remote Valves Not Published 1 pair (optional) ▶ Fluid CapacityFuel Tank Capacity 21.1 gal 6.79 gal Coolant Capacity 2.4 gal 0.9 gal Crankcase Capacity 1.8 gal 0.8 gal Transmission / Hydraulic System Capacity 12.4 gal 4.5 gal Front Axle Fluid Capacity 2.6 gal 0.8 gal ▶ PTO & HitchPTO Type Independent Independent (electro-hydraulic) PTO Rear 540 (standard); 540 / 750 / 1,000 (optional 3-speed) Standard (540 rpm) Mid-PTO Availability Not Published Optional (2,500 rpm) Category, 3-Point Hitch Category II Category I Hitch Lift Capacity 4,079 lb 1,896 lb Hitch Lift Capacity (at 24”) 3,483 lb 1,323 lb Lift Control Type Position and draft control Position control ▶ Transmission & DrivetrainTransmission Type Synchro-shuttle (standard); Power shuttle (optional) Hydrostatic Drive No. of Speeds F16 x R16 (F32 x R16 with creeper, optional) 3 ranges Max Travel Speed (Forward) 17.99 mph 12.86 mph Max Travel Speed (Reverse) 14.81 mph 8.45 mph Clutch Dry single clutch (mechanical); wet clutch disks (power shuttle) Not Published Differential Lock & Limited Slip Options Mechanical pedal type differential lock Mechanical differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic power steering Brakes Wet disc Wet, multi-disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Front wheel mechanical assist (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 138.6 in 111.9 in Overall Width 70 in 48.7 in Wheelbase 80.3 in 63.4 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 10.8 ft (with brake applied) 8.2 ft (with brake applied) Height to Top of ROPS 103 in 86.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 100.6 in Not Published ▶ WeightTractor Weight (Base) Roll-bar: 4,586 lb; Cabin: 5,049 lb 1,764 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag 9.5-20 / 16.9-24; Industrial 10.5/80-18 / 19.5L-24; Turf 36x13.5-15 / 16.9-24 R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 9.5-20 7-12 R1 Agricultural - Rear 16.9-24 11.2-16 R3 Turf - Front 36x13.5-15 22x8.50-12 R3 Turf - Rear 16.9-24 31x15.50-15 R4 Industrial - Front 10.5/80-18 23x8.50-12 R4 Industrial - Rear 19.5L-24 12-16.5 ▶ Loader & AttachmentsQuick Attach Loader System Not Published LL2300: Bobcat-type (skid-steer style) quick attach bucket carrier; LL2001: Not Published Loader Model LL5106 LL2300; LL2001 Loader Lift Height LL5106: 116 in LL2300: 84.4 in; LL2001: 84.4 in Loader Lift Capacity (Full Height) LL5106: 3,351 lb (at pivot pin, 1.5 m height) LL2300: 1,067 lb; LL2001: 1,127 lb (at pivot pin) Loader Breakout Force LL5106: 4,556 lb LL2300: 2,290 lb; LL2001: 1,744 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 6-year / 1,500-hour limited powertrain warranty; 2-year / 750-hour bumper-to-bumper warranty 6-year limited warranty
