▶ EngineEngine Manufacturer LS Mtron MHI Engine Model L4C25-T2 S3L2-W463GTAC Engine Type In-line vertical, Water cooled 4-cycle diesel, CRDI 3-cylinder, liquid-cooled, diesel, naturally aspirated, IDI No. of Cylinders 4 3 Displacement 152.86 in³ 80.4 in³ Rated Engine Speed 2500 rpm 2500 rpm Engine Power (Gross) 68 hp 24.6 hp PTO Power 60 hp 17.1 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry Dry Fuel System CRDI IDI (indirect injection) Alternator 70 A, 12 V 50 A, 12 V ▶ HydraulicsPump Type Gear type, engine drive Gear pump Implement Flow 9.9 gpm 7.1 gpm Steering Flow 4.6 gpm 4.6 gpm Total Hydraulic Flow 14.5 gpm 11.7 gpm Overall Hydraulic Pump Flow Not Published 11.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 0 (1 pair optional) No. of Optional Remote Valves Not Published 1 pair (optional) ▶ Fluid CapacityFuel Tank Capacity 21.1 gal 10.6 gal Coolant Capacity 2.4 gal Not Published Crankcase Capacity 1.8 gal Not Published Transmission / Hydraulic System Capacity 12.4 gal Not Published Front Axle Fluid Capacity 2.6 gal Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 (standard); 540 / 750 / 1,000 (optional 3-speed) Standard (540 rpm) Mid-PTO Availability Not Published Available (option) Category, 3-Point Hitch Category II Category I Hitch Lift Capacity 4,079 lb 1,808 lb Hitch Lift Capacity (at 24”) 3,483 lb 1433 lb Lift Control Type Position and draft control Position control ▶ Transmission & DrivetrainTransmission Type Synchro-shuttle (standard); Power shuttle (optional) HST No. of Speeds F16 x R16 (F32 x R16 with creeper, optional) 3 ranges Max Travel Speed (Forward) 17.99 mph Not Published Max Travel Speed (Reverse) 14.81 mph Not Published Clutch Dry single clutch (mechanical); wet clutch disks (power shuttle) Not Published Differential Lock & Limited Slip Options Mechanical pedal type differential lock Mechanical differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic power steering Brakes Wet disc Wet, multi-disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 138.6 in 119 in Overall Width 70 in 66 in Wheelbase 80.3 in 66 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 10.8 ft (with brake applied) 11.5 ft (3.5 m) Height to Top of ROPS 103 in 95 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 100.6 in Not Published ▶ WeightTractor Weight (Base) Roll-bar: 4,586 lb; Cabin: 5,049 lb 3,007 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag 9.5-20 / 16.9-24; Industrial 10.5/80-18 / 19.5L-24; Turf 36x13.5-15 / 16.9-24 R1 agricultural, R4 industrial, R3 turf and VT (versa turf); VT same size as R4 R1 Agricultural - Front 9.5-20 7-14 R1 Agricultural - Rear 16.9-24 11.2-24 R3 Turf - Front 36x13.5-15 25x8.50-14 R3 Turf - Rear 16.9-24 41x14.00-20 R4 Industrial - Front 10.5/80-18 27x8.50-15 R4 Industrial - Rear 19.5L-24 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System Not Published LL3001, LL3002: ISO 24410 Quick Attaching Coupler Loader Model LL5106 LL3002 Loader Lift Height LL5106: 116 in LL3002: 94.3 in Loader Lift Capacity (Full Height) LL5106: 3,351 lb (at pivot pin, 1.5 m height) LL3002: 1,599 lb Loader Breakout Force LL5106: 4,556 lb LL3002: 2,962 lb ▶ WarrantyWarranty Length & Coverage 6-year / 1,500-hour limited powertrain warranty; 2-year / 750-hour bumper-to-bumper warranty 6-year limited powertrain warranty; 2-year bumper-to-bumper warranty
