▶ EngineEngine Manufacturer LS Mtron Deutz Engine Model L4C25-T2 TCD 2.9 Engine Type In-line vertical, Water cooled 4-cycle diesel, CRDI 4-cylinder, turbocharged diesel No. of Cylinders 4 4 Displacement 152.86 in³ 177 in³ Rated Engine Speed 2500 rpm 2200 rpm Engine Power (Gross) 68 hp 68 hp PTO Power 60 hp 62.7 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry Dual dry Fuel System CRDI CRDI Alternator 70 A, 12 V 95 A, 12 V ▶ HydraulicsPump Type Gear type, engine drive Dual gear pump Implement Flow 9.9 gpm 10.3 gpm Steering Flow 4.6 gpm 5.8 gpm Total Hydraulic Flow 14.5 gpm (9.9 + 4.6, computed) 16.1 gpm Overall Hydraulic Pump Flow Not Published 16.1 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 6 (Floating/Regen); 4 (Spring/Floating) No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 21.1 gal 18.5 gal Coolant Capacity 2.4 gal 2.8 gal Crankcase Capacity 1.8 gal Not Published Transmission / Hydraulic System Capacity 12.4 gal 11.1 gal Front Axle Fluid Capacity 2.6 gal 4.3 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 (standard); 540 / 750 / 1,000 (optional 3-speed) 540/750 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 4,079 lb 4,270 lb Hitch Lift Capacity (at 24”) 3,483 lb 3,153 lb Lift Control Type Position and draft control Position/Draft ▶ Transmission & DrivetrainTransmission Type Synchro-shuttle (standard); Power shuttle (optional) Synchro or power shuttle No. of Speeds F16 x R16 Not Published Max Travel Speed (Forward) 17.99 mph 23 mph Max Travel Speed (Reverse) 14.81 mph Not Published Clutch Dry single clutch (mechanical); wet clutch disks (power shuttle) M: Dry Single Plate; PS: Wet Multi Plate Differential Lock & Limited Slip Options Mechanical pedal type differential lock Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic Brakes Wet, multi-disc Wet disc Seat Suspension & Adjustability Not Published Suspension seat Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 70 in 72.4 in Wheelbase 80.3 in 84.7 in Ground Clearance Not Published 17.1 in Min. Turn Radius without Brakes 10.8 ft (with brake applied) 162.2 in Height to Top of ROPS 103 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 100.6 in 103 in Overall Length 138.6 in (bumper to link) 155.6 in (with 3-point hitch) ▶ WeightTractor Weight (Base) Roll-bar: 4,674 lb; Cabin: 5,121 lb (without ballast) 5,556 lb (with cab) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag 9.5-20 / 16.9-24; Industrial 10.5/80-18 / 19.5L-24; Turf 36x13.5-15 / 16.9-24 Not Published R1 Agricultural - Front 9.5-20 9.5R20 R1 Agricultural - Rear 16.9-24 Not Published R3 Turf - Front 36x13.5-15 Not Published R3 Turf - Rear 16.9-24 Not Published R4 Industrial - Front 10.5/80-18 Not Published R4 Industrial - Rear 19.5L-24 18.4-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model LL5106 L5068SL Loader Lift Height LL5106: 116.3 in L5068SL: 124.8 in Loader Lift Capacity (Full Height) LL5106: 2,981 lb (at pivot pin) L5068SL: 3,122 lb (at pivot pin) Loader Breakout Force LL5106: 4,767 lb (at pivot pin) L5068SL: 5,225 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage General: 2 years or 750 hours (whichever occurs first). Extended powertrain: 6 years or 1,500 hours (whichever occurs first), for tractors retailed after January 1, 2017 Basic 24 months or 2,000 hours, parts and labor; non-commercial, 20 to 70 engine hp: powertrain 72 months or 3,000 hours; loaders, backhoes and mid-mount mowers 12 months
