▶ EngineEngine Manufacturer Mitsubishi Yanmar Engine Model S3L2 3TNV88F-EPJT2 Engine Type 3-cylinder, indirect injection, water-cooled Diesel, naturally aspirated, direct injection No. of Cylinders 3 3 Displacement 80.4 in³ 100.2 in³ Rated Engine Speed 2500 rpm 2400 rpm Engine Power (Gross) 24.4 hp 24.4 hp PTO Power 18.5 hp 19.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Water pump Air Cleaner Dry Dry type with safety element Fuel System Indirect injection Direct injection Alternator 50 A, 12 V 55 A, 12 V ▶ HydraulicsPump Type Transmission drive Implement/steering pump: tandem gear pump; hydrostatic pump: PV axial-piston pump Implement Flow 5.9 gpm 5.3 gpm Steering Flow 2.6 gpm 4.0 gpm Total Hydraulic Flow 8.5 gpm 9.3 gpm Overall Hydraulic Pump Flow 8.5 gpm 9.3 gpm Hydraulic System Type Position control Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None Not Published No. of Optional Remote Valves 2 quick couplers (optional) Up to 2 (optional) ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 7.5 gal Coolant Capacity 1.0 gal 5.2 qt Crankcase Capacity 1.1 gal 4.5 qt Transmission / Hydraulic System Capacity 5.3 gal 5.5 gal Front Axle Fluid Capacity 0.8 gal 4 qt ▶ PTO & HitchPTO Type Independent (electro-hydraulic) Not Published PTO Rear Standard (540 rpm) 540 rpm Mid-PTO Availability Standard (2,000 rpm) Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,433 lb Not Published Hitch Lift Capacity (at 24”) 1,058 lb 1,356 lb Lift Control Type Manual position control Not Published ▶ Transmission & DrivetrainTransmission Type Hydrostatic Drive Hydrostatic transmission (HST) No. of Speeds 2 ranges Not Published Max Travel Speed (Forward) 11.5 mph Not Published Max Travel Speed (Reverse) 7.2 mph Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Mechanical pedal type Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Open operator station (OOS) Steering Hydrostatic power steering Power steering Brakes Wet, multi-disc Wet disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Front wheel mechanical assist (4WD) 4WD (MFWD) Front Axle Rating Not Published 1,760 lb Drawbar Capacity Horizontal load: 3,527 lb; Vertical load: 551 lb pulled / 882 lb pushed 880 lb (maximum vertical load) ▶ Dimensions & ManeuverabilityOverall Width 44.9 in 56.9 in (min. rear tread, standard R1 tires); 61.7 in (max. rear tread, larger R4 tires) Wheelbase 59 in 62.8 in Ground Clearance Not Published 12.7 in (R4 tires) Min. Turn Radius without Brakes 8.2 ft (with brake applied) Not Published Height to Top of ROPS 84.5 in 95.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 103 in (bumper to link) 115.9 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 1,609 lb 2,222 lb Weight with ROPS and Loader Not Published 2,972 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural, Turf, Industrial R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front 23X10.50-12 7-14 R1 Agricultural - Rear 255/75-15.3 11.2-24 R3 Turf - Front 23x8.5-12 27X8.50-15 R3 Turf - Rear 33x12-16.5 41X14-20 R4 Industrial - Front 23x8.5-12 25X8.50-14 or 27X8.50-15 R4 Industrial - Rear 33x12-16.5 15-19.5 or 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System LL2102: Bobcat-type quick attachment (ISO 24410), latch handle with latch pin Quick-change attachment carrier Loader Model LL2102 300E Loader Lift Height LL2102: 85.7 in 84 in (at pivot pin) Loader Lift Capacity (Full Height) LL2102: 1,091 lb (at pivot pin, max height) 1,186 lb (at pivot pin) Loader Breakout Force LL2102: 1,426 lb (at pivot pin) 1,704 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 6-year limited warranty Basic 24 months or 2,000 hours; powertrain 72 months or 2,000 hours
