▶ EngineEngine Manufacturer Mitsubishi Yanmar Engine Model MVL3E3 3TNE74 Engine Type Four Stroke, Naturally Aspirated, Indirect Injection, Water-Cooled Diesel 3-cylinder liquid-cooled diesel, indirect injection No. of Cylinders 3 3 Displacement 67.2 in³ 61.4 in³ Rated Engine Speed 3000 rpm 3000 rpm Engine Power (Gross) 22.9 hp 23 hp PTO Power 16.8 hp 17.7 hp Engine Emissions Constraints No DPF Not Published Cooling System Type Water-Cooled Liquid-cooled Air Cleaner Not Published Dry type with safety element Fuel System Indirect Injection Indirect injection, in-line fuel pump with solenoid shutoff Alternator 55 A, 12 V 20 A ▶ HydraulicsPump Type Not Published Not Published Implement Flow 7.6 gpm 3 gpm Steering Flow 3.8 gpm 2.5 gpm Total Hydraulic Flow 11.2 gpm 5.5 gpm Overall Hydraulic Pump Flow 11.2 gpm 5.5 gpm Hydraulic System Type Open Center, full-live hydraulic with position control Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Single or dual Not Published ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 5.0 gal Coolant Capacity Not Published 3.2 qt Crankcase Capacity Not Published 2.2 qt Transmission / Hydraulic System Capacity Not Published 3.4 gal Front Axle Fluid Capacity Not Published 2.6 qt ▶ PTO & HitchPTO Type Independent Wet Clutch Independent, wet disk clutch PTO Rear 540 rpm @ 2837 rpm 540 rpm Mid-PTO Availability Optional; 2500 rpm @ 2837 rpm Standard, 2100 rpm Category, 3-Point Hitch CAT I with check chains Category 1 Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 771 lb 701 lb Lift Control Type Position Control Not Published ▶ Transmission & DrivetrainTransmission Type HST - 2 Range 2-range hydrostatic No. of Speeds Infinite Infinite forward and reverse, 2 ranges Max Travel Speed (Forward) 7.3 mph 8.4 mph Max Travel Speed (Reverse) Not Published 6.3 mph Clutch Not Published Not Published Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post fixed ROPS; four-wheel drive Steering Hydrostatic Power Steering Power steering Brakes Single Pedal Wet disk Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published MFWD, standard, all ranges, on-the-go engagement Front Axle Rating Not Published 3,120 lb Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 46.3 in 47.2 in Wheelbase 55.1 in 57.1 in Ground Clearance 6.7 in 7.7 in (front axle) Min. Turn Radius without Brakes 7.2 ft (with brake applied) 88.6 in (MFWD off) Height to Top of ROPS Not Published 77.6 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 80.5 in Not Published Overall Length 100.4 in 104.3 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 1,962 lb (operating weight) 1,400 lb (with all fluids) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader 2,368 lb (1,962 operating weight + 406 loader shipping weight, computed) Not Published ▶ Tire OptionsTire Size & Options Turf, Industrial 18x8.5-10 front and 26x12.00-12 rear; R1 standard, R3 optional R1 Agricultural - Front Not Published 18x8.5-10 R1 Agricultural - Rear Not Published 26x12.00-12 R3 Turf - Front 18x8.5-10 18x8.5-10 R3 Turf - Rear 26x12-12 26x12.00-12 R4 Industrial - Front 18x8.5-10 18x8.50-10 R4 Industrial - Rear 26x12-12 26x12.00-12 ▶ Loader & AttachmentsQuick Attach Loader System L11: Front loader skid-steer couplers for superfast hookups Not Published Loader Model L11 210 Loader Lift Height L11: 68 in 210: 68.5 in (at pivot pin) Loader Lift Capacity (Full Height) L11: 794 lb (at pivot pin) 210: 622 lb (to max height at pivot point) Loader Breakout Force L11: 1,433 lb 210: 1,577 lbf (at pivot point) ▶ WarrantyWarranty Length & Coverage 7-Year Limited Powertrain Warranty Not Published
