▶ EngineEngine Manufacturer Mitsubishi Kubota Engine Model MVL3E3 D1005 Engine Type Four Stroke, Naturally Aspired, Indirect Injection, Water-Cooled Diesel Engine Liquid cooled, 4-cycle, diesel No. of Cylinders 3 3 Displacement 67.2 in³ 61.1 in³ Rated Engine Speed 3000 rpm 3200 rpm Engine Power (Gross) 22.9 hp 23.3 hp PTO Power 16.8 hp 19.2 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Water-Cooled Water with pressurized radiator, reverse air-flow design Air Cleaner Not Published Dry element Fuel System Indirect Injection Direct injection Alternator 55 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Not Published Open center tandem pump gear type Implement Flow 7.6 gpm 5.2 gpm Steering Flow 3.8 gpm 1.0 gpm Total Hydraulic Flow 11.2 gpm 6.2 gpm Overall Hydraulic Pump Flow 11.2 gpm 6.2 gpm Hydraulic System Type Open Center, full-live hydraulic with position control Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 0 standard (2-valve rear remote coupler optional) No. of Optional Remote Valves Single or dual 2 (optional; ISO 7241-1 series A or B) ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 6.6 gal Coolant Capacity Not Published 3.5 qt Crankcase Capacity Not Published 4.2 qt Transmission / Hydraulic System Capacity Not Published 3.0 gal Front Axle Fluid Capacity Not Published 3.8 qt ▶ PTO & HitchPTO Type Independent Wet Clutch Live independent PTO (with hydraulic clutch) PTO Rear 540 rpm @ 2837 rpm STD (540 rpm) Mid-PTO Availability Optional; 2500 rpm @ 2837 rpm STD (2500 rpm) Category, 3-Point Hitch CAT 1 with check chains SAE Category I Optional Hitch Lift Capacity Not Published 1,213 lb Hitch Lift Capacity (at 24”) 771 lb 680 lb Lift Control Type Position Control Quarter-inching valve ▶ Transmission & DrivetrainTransmission Type HST - 2 Range Hydrostatic transmission No. of Speeds Infinite forward and reverse (2 ranges) 2 Range (Low-High) Max Travel Speed (Forward) 7.3 mph 8.4 mph Max Travel Speed (Reverse) Not Published 6.5 mph Clutch Not Published Dry type single plate - Main clutch 9.45 in. Differential Lock & Limited Slip Options Not Published Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS Steering Hydrostatic Power Steering Integral power steering Brakes Single Pedal Mechanical, wet disc type Seat Suspension & Adjustability Not Published High-back deluxe seat with armrests; fore/aft slide and backrest tilt adjustment Front Axle Type Not Published 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Max. drawbar load @ hitch: 550 lb. ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 100.4 in 95.5 in (without 3-point hitch) Overall Width 46.3 in 45.1 in Wheelbase 55.1 in 55.1 in Ground Clearance 6.7 in 6.5 in (minimum; 8.9 in at front axle) Min. Turn Radius without Brakes 7.2 ft (with brake applied) 7.5 ft Height to Top of ROPS Not Published 83.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 80.5 in Not Published ▶ WeightTractor Weight (Base) 1962 lb 1521 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader 2368 lb Not Published ▶ Tire OptionsTire Size & Options R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front Not Published 18X8.5-10 R1 Agricultural - Rear Not Published 26X12-12 R3 Turf - Front 18x8.5-10 18X8.5-10 R3 Turf - Rear 26x12-12 26X12-12 R4 Industrial - Front 18x8.5-10 18X8.5-10 R4 Industrial - Rear 26x12-12 26X12-12 ▶ Loader & AttachmentsQuick Attach Loader System L11: Front loader skid-steer couplers for superfast hookups Swift-Tach Loader (LA344S - Two Lever Quick Attach Bucket) Loader Model L11 LA344S (standard, quick attach); LA344 (pin-on option) Loader Lift Height L11: 68 in 71.0 in Loader Lift Capacity (Full Height) L11: 794 lb 739 lb (LA344 pin-on); 613 lb (LA344S quick attach) Loader Breakout Force L11: 1433 lb 1,407 lbf (LA344 pin-on); 1,286 lbf (LA344S quick attach) ▶ WarrantyWarranty Length & Coverage 7-Year Limited Powertrain Warranty Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. ▶ ITC Company AccessoriesAccessories that fit None tagged yet
