▶ EngineEngine Manufacturer Mitsubishi Kubota Engine Model MVL3E3 D1703-M-DI-E4 / D1703-M-DI-E4K Engine Type Four Stroke, Naturally Aspired, Indirect Injection, Water-Cooled Diesel Engine Direct injection, vertical, water-cooled 4-cycle, diesel No. of Cylinders 3 3 Displacement 67.2 in³ 100.5 in³ Rated Engine Speed 3000 rpm 2200 rpm Engine Power (Gross) 22.9 hp 23.3 hp PTO Power 16.8 hp 18.4 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Water-Cooled Water-cooled Air Cleaner Not Published Dry type, single element Fuel System Indirect Injection Direct injection Alternator 55 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 7.6 gpm 5.2 gpm Steering Flow 3.8 gpm 3.1 gpm Total Hydraulic Flow 11.2 gpm 8.28 gpm (5.15 + 3.13, computed) Overall Hydraulic Pump Flow 11.2 gpm 8.28 gpm (5.15 + 3.13, computed) Hydraulic System Type Open Center, full-live hydraulic with position control Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Single or dual Not Published ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 11.1 gal Coolant Capacity Not Published 6.3 qt Crankcase Capacity Not Published 6.0 qt Transmission / Hydraulic System Capacity Not Published HST (4WD): 6.9 gal; DT (2WD): 7.4 gal; DT (4WD): 7.5 gal Front Axle Fluid Capacity Not Published 4.8 qt ▶ PTO & HitchPTO Type Independent Wet Clutch DT (2WD), DT (4WD): Transmission driven with overrunning clutch; HST (4WD): Live-independent hydraulic PTO with PTO brake, wet PTO Rear 540 rpm @ 2837 rpm 540 rpm Mid-PTO Availability Optional; 2500 rpm @ 2837 rpm Not Published Category, 3-Point Hitch CAT 1 with check chains SAE Category I Hitch Lift Capacity Not Published 1874 lb Hitch Lift Capacity (at 24”) 771 lb 1389 lb Lift Control Type Position Control Position control ▶ Transmission & DrivetrainTransmission Type HST - 2 Range DT (2WD), DT (4WD): Constant mesh with synchronized shuttle; HST (4WD): Hydrostatic transmission (3-range) No. of Speeds Infinite forward and reverse (2 ranges) DT (2WD), DT (4WD): 8 forward, 8 reverse; HST (4WD): 3-range Max Travel Speed (Forward) 7.3 mph DT (2WD), DT (4WD): 10.7 mph; HST (4WD): 11.5 mph Max Travel Speed (Reverse) Not Published DT (2WD), DT (4WD): 10.7 mph; HST (4WD): 10.3 mph Clutch Not Published DT (2WD), DT (4WD): Dry type single stage; HST (4WD): Not Applicable Differential Lock & Limited Slip Options Not Published Rear differential lock, pedal operated ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power Steering Integral type power steering Brakes Single Pedal Mechanical, wet disc type Seat Suspension & Adjustability Not Published Suspension seat with fore/aft travel adjustment and suspension tension adjustment Front Axle Type Not Published Cast-iron front axle Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 730 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 100.4 in DT (2WD): 110.6 in; DT (4WD), HST (4WD): 108.5 in (without 3-point hitch) Overall Width 46.3 in 55.1 in Wheelbase 55.1 in DT (2WD): 63.8 in; DT (4WD), HST (4WD): 63.4 in Ground Clearance 6.7 in DT (2WD): 13.6 in; DT (4WD), HST (4WD): 13.4 in Min. Turn Radius without Brakes 7.2 ft (with brake applied) DT (2WD): 7.9 ft; DT (4WD), HST (4WD): 8.2 ft (with brake applied) Height to Top of ROPS Not Published 91.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 80.5 in Not Published ▶ WeightTractor Weight (Base) 1962 lb DT (2WD): 2601 lb; DT (4WD): 2811 lb; HST (4WD): 2833 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader 2368 lb Not Published ▶ Tire OptionsTire Size & Options R3 Turf, R4 Industrial R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front Not Published DT (2WD): 5.0-15; DT (4WD), HST (4WD): 7.2-16 R1 Agricultural - Rear Not Published 11.2-24 R3 Turf - Front 18x8.5-10 DT (2WD): 23X8.50-12; DT (4WD), HST (4WD): 25X8.50-14 R3 Turf - Rear 26x12-12 13.6-16 R4 Industrial - Front 18x8.5-10 DT (2WD): Not Applicable; DT (4WD), HST (4WD): 27X8.50-15 R4 Industrial - Rear 26x12-12 DT (2WD): Not Applicable; DT (4WD), HST (4WD): 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System L11: Front loader skid-steer couplers for superfast hookups Front Loader (LA526 - 2 Lever Quick Coupler (OPT)) Loader Model L11 LA526 Loader Lift Height L11: 68 in LA526: 94.8 in Loader Lift Capacity (Full Height) L11: 794 lb LA526: 1,096 lb Loader Breakout Force L11: 1433 lb Not Published ▶ WarrantyWarranty Length & Coverage 7-Year Limited Powertrain Warranty Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
