▶ EnginePTO Power 16.8 hp 18.8 hp Alternator 55 A, 12 V 40 A, 12 V Air Cleaner Not Published Single element Engine Type Four Stroke, Naturally Aspired, Indirect Injection, Water-Cooled Diesel Engine Water cooled, 4-cycle Diesel Fuel System Indirect Injection Indirect Fuel Injection Displacement 67.2 in³ 77.3 in³ No. of Cylinders 3 3 Rated Engine Speed 3000 rpm 3000 rpm Cooling System Type Water-Cooled Water cooled, forced circulation Engine Manufacturer Mitsubishi Yanmar Engine Power (Gross) 22.9 hp 23.9 hp Engine Emissions Constraints No DPF Tier 4 Engine Model — 3TNV80F-SDKTFF ▶ WeightWeight with ROPS and Loader Not Applicable 2,091 lb Weight with Cab and Loader 2368 lb Not Published ▶ WarrantyWarranty Length & Coverage 7-Year Limited Powertrain Warranty Full-machine: 24 months/2,000 hours; Powertrain: 96 months/3,000 hours (whichever comes first) ▶ HydraulicsPump Type Not Published Gear Pump Steering Flow 3.8 gpm Not Published Implement Flow 7.6 gpm Not Published Total Hydraulic Flow 11.4 gpm 6.95 gpm Hydraulic System Type Open Center, full-live hydraulic with position control Hydrostatic Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 11.4 gpm 26.3 lpm (6.95 US gpm) No. of Optional Remote Valves Single or dual NOT FOUND — no source explicitly states the number of optional remote valves available for the RK24. Sources confirm 1 standard rear remote set is included, but do not specify optional add-on valve counts. No. of Standard Remote Valves Not Published 1 ▶ PTO & HitchPTO Rear 540 rpm @ 2837 rpm 540 rpm PTO Type Independent Wet Clutch Independent PTO Lift Control Type Position Control Position control Hitch Lift Capacity Not Published 1,323 lb Mid-PTO Availability Optional; 2500 rpm @ 2837 rpm Standard, 2,000 rpm @ 2,875 rpm Category, 3-Point Hitch CAT I with check chains Category I Hitch Lift Capacity (at 24”) 771 lb Not Published ▶ Tire OptionsR3 Turf - Rear 26X12-12 29X12.5-15 R3 Turf - Front 18X8.5-10 20X8-10 Tire Size & Options R3 Turf, R4 Industrial R4 Industrial (Std), R3 Turf (Opt) R1 Ag (Opt), Goodyear R14 (Opt) R4 Industrial - Rear 26X12-12 27X12.5-15 R4 Industrial - Front 18X8.5-10 20X8-10 R1 Agricultural - Rear Not Published 9.5-16 R1 Agricultural - Front Not Published 6-12 ▶ Fluid CapacityCoolant Capacity Not Published 3.6 ℓ (0.96US gal) Crankcase Capacity Not Published 2.7 ℓ ( 0.71 US gal) Fuel Tank Capacity 6.6 gal 5.81 gal Front Axle Fluid Capacity Not Published 3.2ℓ (0.85 US gal) Transmission / Hydraulic System Capacity Not Published 14.5ℓ (3.83 US gal) ▶ Loader & AttachmentsLoader Lift Height 68 in 75.3 Loader Breakout Force 1433 lb 1,680 lb Quick Attach Loader System L11: Skid-steer couplers (skid-steer style quick attach) for superfast hookups. Skid-Steer Compatible Quick-Attach Loader Lift Capacity (Full Height) 794 lb 947 lb ▶ Transmission & DrivetrainClutch Not Applicable Not Published No. of Speeds Infinite / 2 ranges 2 Range (High/Low) Transmission Type HST Hydraulic + Mechanical H/L with constant-mesh Max Travel Speed (Forward) 7.3 mph 10.5 mph Max Travel Speed (Reverse) Not Published Not Published Differential Lock & Limited Slip Options Not Published Differential lock (bevel gears with diff-lock) ▶ Chassis, Steering & ControlsBrakes Single Pedal Wet Disc, Foot operated, independent with provision of inter lock for simultaneous operation Steering Hydrostatic Power Steering Hydrostatic Power steering system Frame Type Not Published Not Published Front Axle Type Not Published Center-pivot, reverse Eliot type Drawbar Capacity Not Published Not Published Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Not Published Not Published ▶ Dimensions & ManeuverabilityWheelbase 55.1 in 57.5 in Overall Width 46.3 in 45.8 in Ground Clearance 6.7 in 9.4 in Height to Top of ROPS Not Applicable 91.3 in Height to Top of Cab Model 80.5 in Not Published Height to Top of ROPS (folded) Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Overall Length with 3-Point Hitch 100.4 in 100.5 in ▶ ITC Company AccessoriesAccessories that fit None tagged yet
